User Manual
IWA (IW008A IW012A IW016A)
IWA-R (IW008A-R IW012A-R IW016A-R)
The colour and the appearance may differ depending on the product, and the content in the
manual is subject to change without prior notice to improve the performance.
An administration fee may be charged in the following situations:
(a) An engineer is called out at your request, but it is found that the product has no defect (i.e.,
where the user manual has not been read).
(b) You bring the unit to a repair centre, but it is found that the product has no defect (i.e.,
where the user manual has not been read).
You will be informed of the administration fee amount before a technician visits.
© Samsung
Samsung owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited. Trademarks other than Samsung are property of their respective owners.

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for Samsung IWA-R Series

  • Page 1 You will be informed of the administration fee amount before a technician visits. © Samsung Samsung owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited. Trademarks other than Samsung are property of their respective owners.
  • Page 2: Table Of Contents

    Table of contents Before Using the Product Connecting to cabinets Supported resolutions per installation Safety Precautions Connecting the Power Cable Safety symbols Electricity and Safety Installation Operation Specifications Cleaning General Preparations Appendix Ports IWA (IW008A IW012A IW016A) Responsibility for the Pay Service (Cost to IWA-R (IW008A-R IW012A-R IW016A-R) Customers) Not a product defect...
  • Page 3: Before Using The Product

    Chapter 01 Before Using the Product Safety Precautions The following safety instructions are to ensure your personal safety and prevent property CAUTION damage. Please read the following to ensure the proper use of the product. RISK OF ELECTRIC SHOCK. DO NOT OPEN. Safety symbols CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 4: Electricity And Safety

    Warning The product may become damaged by an electric shock. Only use the power cord provided with your product by Samsung. Do not use the power Do not use a damaged power cord or plug, or a loose power socket.
  • Page 5: Installation

    Have a technician install the wall-mount hanger. seriously affect its performance. • Installation by an unqualified person can result in an injury. Be sure to consult Samsung Customer Service Centre if you want to install the • Only use approved cabinets. product at such a place.
  • Page 6: Operation

    Be sure to power off the product and disconnect the power cord when water Warning or other foreign substances have entered the product. Then contact Samsung Customer Service Centre. There is a high voltage inside the product. Never disassemble, repair or modify the •...
  • Page 7: Cleaning

    For IW008A / IW008A-R: 0.84 x 3.5 m = a distance of at least 2.9 m is (The installation manual is available for download at www.samsung.com/displaysolutions.) recommended Do not use humidifiers or stoves around the product. Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be charged).
  • Page 8: Preparations

    Chapter 02 Preparations Ports " The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. IWA (IW008A IW012A IW016A) Parts Description SERVICE Dedicated to service technicians. Connects to the port on the next cabinet.
  • Page 9: Iwa-R (Iw008A-R Iw012A-R Iw016A-R)

    IWA-R (IW008A-R IW012A-R IW016A-R) Parts Description SERVICE Dedicated to service technicians. Connects to the port on the next cabinet. DATA DATA Enters factory mode (press and hold for 5 seconds) or factory reset SWITCH mode (press and hold for 10 seconds). Connects to the port on an interface gender or on the DATA...
  • Page 10: Connecting Devices

    Chapter 03 Connecting Devices Precautions when handling the cabinets [Caution to prevent external shock and dropping of the [Caution to prevent damage to the LED] product] After removing the protective brackets, do not place After removing the protective brackets, be careful not the product on the floor with the LED facing down.
  • Page 11: Installing The Cabinets

    For more information about how to install the frame kit, refer to the user manual that comes with it. • Samsung shall not be liable for any damage to the product and any injury to the users or others that may be incurred while the users install the product by themselves.
  • Page 12: Removing The Protective Brackets

    Removing the protective brackets Lowering the protective cap before connection of the power cable Remove the safety bracket before proceeding to installation. IWA (IW008A IW012A IW016A) Be sure to lower the protective cap before installation of the cabinet, in order to connect the power cable.
  • Page 13: Arranging The Upper Docking Port At The Top Of The Cabinet

    Arranging the upper docking port at the top of the IWA-R (IW008A-R IW012A-R IW016A-R) cabinet main frame For detailed information, visit the install guide. IWA (IW008A IW012A IW016A) module frame main frame Place the product on the packaging cushion and then remove the module frame from the main frame.
  • Page 14: Connecting To Cabinets

    Connecting to cabinets Connect the S-Box (SNOW-AAE) and the cabinet to the installed cabinet for video signal transmission. " Connect the S-Box to the external device before connecting the S-Box to the cabinet. " Before connecting power to the cabinets, connect the I/G card to the cabinets first. "...
  • Page 15: Supported Resolutions Per Installation

    Supported resolutions per installation Resolution 480 x 270 640 x 360 960 x 540 1920 x 1080 3840 x 2160 7680 x 4320 (8K) IW008A / IW008A-R 2 x 2 4 x 4 8 x 8 IW012A / IW012A-R 3 x 3 6 x 6 12 x 12 IW016A / IW016A-R...
  • Page 16: Connecting The Power Cable

    Make sure that the Do not use number of connected devices does not exceed the recommended maximum number. " Samsung is not liable for any problems incurred by connecting devices that exceed the recommended maximum number. AC/DC rectifier...
  • Page 17: Specifications

    1.68 mm settings if desired. LED pixel configuration Flip Chip LED " For detailed device specifications, visit the Samsung website. Cabinet Pixels (Row x Column) 960 x 540 pixels 640 x 360 pixels 480 x 270 pixels Aspect ratio (W:H) 16:9 (806.4 x 453.6)
  • Page 18: Appendix

    External impact or drop. " When the service is requested, in spite of in warranty, we may charge you for a visit from a • Use of supplies or separately sold product unspecified by Samsung. service technician in the following cases. •...
  • Page 19: Licence

    To prevent possible harm to the environment or human health from You may find a copy of the source at following website. uncontrolled waste disposal, please separate these items from other types http://opensource.samsung.com of waste and recycle them responsibly to promote the sustainable reuse of material resources.
