EVENT-28A / EVENT-118A
www.dasaudio.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the event Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for D.A.S. event Series

Summary of Contents for D.A.S. event Series

  • Page 1 EVENT-28A / EVENT-118A www.dasaudio.com...
  • Page 2 Before operating the device, please read the “Safety precautions” section of this manual. Retain this manual for future reference. Event Series User's Manual...
  • Page 3 Event Series | Index 1. Safety precautions 8. Rigging system 2. Declaration of conformity 4 or 6 units mounting on a PL-EV28S flatbed dolly 3. Warranty Array mounting of groups of 4 units on a flatbed dolly 4. Introduction EVENT-118A array mounting 5.
  • Page 4 Event Series User's Manual...

  • Page 5: Safety Precautions

    If the fuse needs to be replaced, please pay attention to correct type and ratings. The outer wiring connected to the device requires installation by an instructed person or the use of a flexible cable already prepared. Event Series User's Manual...

  • Page 6: Declaration Of Conformity

    Electromagnetic compatibility of multimedia equipment. Emission requirements. • EN 55035:2017 + A11:2020 Electromagnetic compatibility of multimedia equipment. Immunity requirements. • EN IEC 63000:2018 Technical documentation for the assessment of electrical and electronic products with respect to the restriction of hazardous substances. Event Series User's Manual...
  • Page 7 Event Series | Warranty products warrantied against manufacturing defect for a period of 24 months from date of purchase. The warranty excludes damage from incorrect use of the product. All warranty repairs must be exclusively undertaken by the factory or any of its authorised service centers.
  • Page 8 Event Series | Introduction EVENT-28A The EVENT-28A is an advanced symmetrical, compact, two-way powered Installation and deployment of EVENT-28A arrays are streamlined with line array system. Designed to provide outstanding performance and ease the innovative Fast Set Splay (FSS™) rigging system, which allows for of use, this system features a stylish and portable polypropylene cabinet quick angle selection while stacked on dollies.
  • Page 9 Event Series | Introduction EVENT-118A The EVENT-118A is a robust powered subwoofer system that incorporates • Active front-loaded subwoofer system a frontloaded 18” lowfrequency transducer developed by DAS, designed • 1 x 18″ DAS 18FW4N loudspeaker to deliver profound and accurate bass reinforcement. As the companion •...
  • Page 10 Event Series | Configurations 2 x EVENT-28A + 2 x EVENT-118A AXS-EV28 AXC-ZT TDR-7 Event Series User's Manual...
  • Page 11 Event Series | Configurations 8 x EVENT-28A + 2 x EVENT-118A AX-EV28 P P O O W W E E R R P P O O W W E E R R S S U U P P P P L L Y Y...
  • Page 12 Event Series | Configurations 8 x EVENT-28A+ 4 x EVENT-118A AX-EV28 P P O O W W E E R R P P O O W W E E R R S S U U P P P P L L Y Y...
  • Page 13 Event Series | Configurations 12 x EVENT-28A + 6 x EVENT-118A P P O O W W E E R R P P O O W W E E R R S S U U P P P P L L Y Y...
  • Page 14 Event Series | Configurations 16 x EVENT-28A + 8 x EVENT-118A P P O O W W E E R R P P O O W W E E R R S S U U P P P P L L Y Y...
  • Page 15 Event Series | Configurations 24 x EVENT-28A + 12 x EVENT-118A P P O O W W E E R R P P O O W W E E R R S S U U P P P P L L Y Y...
  • Page 16 Event Series | Configurations 12 x EVENT-28A + 4 x EVENT-118A P P O O W W E E R R P P O O W W E E R R S S U U P P P P L L Y Y...
  • Page 17 Event Series | Specifications Model EVENT-28A EVENT-118A Nominal LF Power Amplifier 1000W peak - 500 W continuous 2000W peak - 1000 W continuous Class D Amplifier Class D Amplifier Nominal HF Power Amplifier 300W peak - 150 W continuous Class D Amplifier...
  • Page 18 Event Series | Line Drawing Event-28A Event Series User's Manual...
  • Page 19 Event Series | Line Drawing Event-118A Event Series User's Manual...
  • Page 20 Event Series | Amplifiers Event-28A Amplifier 1. Input XLR socket-type input signal connector. This is a balanced connector just like the OUTPUT connector with the following pin assignments: 1 or S =GND (ground) 2 or T =(+) Non inverted input 3 or R =(-) Inverted input 2.
  • Page 21 Event Series | Amplifiers 5. AC INPUT: PowerCon NAC3FCA mains connector (inserted, rotated and locked for ON). Only use this equipment with an appropriate mains cord. 6. AC OUTPUT: PowerCon NAC3FCB connector for AC loop thru (see unit’s label)). Only use this equipment with an appropriate mains cord.
  • Page 22 Event Series | DAScontrol and display navigation OPTIONS MENU BACK BRIGHT: +10 CONTRAST: FW v1.19 2910 MAIN MENUM AIN MENU OPTIONS MENU No.of U: BACK Delay: 0.0m DIMMING: <on> No.of U: 1U OPTIONS MENU LOCK: off DownFill: off dark DownFill: off...
  • Page 23 Event Series | DAScontrol and display navigation OPTIONS MENU BACK BRIGHT: 118A CONTRAST: 0 FW v1.1 2905 OPTIONS MENU BACK MAIN MENU MAIN MENU 0 dB BRIGHT: +10 BACK Delay: 0.0m CONTRAST: PRESET: loud OPTIONS 0.0m loud LPF: Top BACK...
  • Page 24 Event Series | Recommendations of use ON / OFF A sound system should be switched on sequentially. Switch on the self-powered units last in your sound system (switch on the subwoofer before the mid-high system). Switch on the sound sources such as CD players or turntables, then the mixer, then the processors, and finally the selfpowered unit.
  • Page 25 Event Series | Recommendations of use Overheating This equipment does not normally overheat during normal conditions of use. When overheating occurs, the FAN will automatically start working reducing the temperature of the unit. Make sure that the rain protectors are properly separated from the amplifier´s back plate in order to not block the air flux thru the fan.
  • Page 26 Event Series | Troubleshooting Problem Cause Solution No sound from the unit. The DISPLAY does not light 1 - No power to the unit. 1 - Check all the connections and the power distro. 2 - Defective cable / connector.
  • Page 27 Event Series | Rigging system Warning This manual offers all the necessary information for flying or stacking EVENT Line Array Absolutely no risks should be taken with regards to public safety. When flying enclosures series systems of DAS Audio. This information is illustrated with drawings and required from ceiling support structures, extreme care should be taken to assure the load bearing safety precautions.
  • Page 28 Event Series | Rigging system 4 or 6 units mounting on a PL-EV28S flatbed dolly Groups of four or six units are easy to transport by truck as we will see in this manual. The next figure shows the detail of the label...
  • Page 29 Event Series | Rigging system 4 or 6 units mounting on a PL-EV28S flatbed dolly Repeat the process shown in the previous Finally, the rigging bumper, AX-EV28 can be At his point the cover for 4 units could be placed figures with the rest of the cabinets.
  • Page 30 Event Series | Rigging system Array mounting of groups of 4 units on a flatbed dolly Groups of to 4 or 6 units are easy to transport by truck. We will see in this section the assembly position. (pin point of the central bar).
  • Page 31 Event Series | Rigging system Rise the system and splay angles between cabient will be set automatically: NOTE: To rig the system the simplest approach is using three pins (two at the front and one at the rear). With this method the splay angle between units is set automatically while the cabinets are lifted up.
  • Page 32 Event Series | Rigging system 0º Repeat the process with the second dolly. Lower the first four units, set splay angle in the ones stacked on the dolly, attach the two groups and rise it. In the sample shown only three pins per cabinet are used: 1º...
  • Page 33 Event Series | Rigging system EVENT-118A Array mounting Fig. 12 Fig. 13 Fig. 14 Fig. 15 Event Series User's Manual...
  • Page 34 Event Series | Rigging system EVENT-28A Array mounting “one by one” Set splay Set splay Set splay Fig. 16 Fig. 17 Fig. 18 Fig. 19 Event Series User's Manual...
  • Page 35 Event Series | Rigging system EVENT-118A + EVENT-28A Array mounting First step will be assembling the subwoofers with the AX-EV28. follow the process shown on previous pages. Next step, before hanging the EVENT-28A units is to fix to the bottom EVENT-118A the joining plate JP-EV28.
  • Page 36 Event Series | Rigging system Set splay Fig. 23 Fig. 24 Event Series User's Manual...
  • Page 37 Event Series | Rigging system Stacking EVENT-28A on EVENT-118A JP-EV28 joining plate is needed to stack the systems. Fig. 26 Fig. 27 Fig. 25 Event Series User's Manual...
  • Page 38 Event Series | Rigging system Angle between first EVENT-26A and EVENT-115A: Cam link Hole - real splay angle 9º= +4º 8º= +4º 7º= +2º 6º= +2º 5º= 0º 4º= 0º 3º= -2º 2º= -2º 1º= -3º 0º= -3º Fig. 28 Fig.
  • Page 39 Event Series | Rigging system Stacking EVENT-28A on AXS-EV28 When using the AXS-EV28 to stack the system on a When using the AXS-EV28 to stack the system on a First step, fix the EVENT-28A to the AXS-EV28 tripod TRD-2 or TRD-7 pole mount, AXC-ZT accessoty is EVENT-118A, AXC-ZT accessory is also needed.
  • Page 40 Event Series | Transport As a compact system, tops and subs can be transported: event event event event event event event event 118A 118A event event 118A 118A Event Series User's Manual...
  • Page 41 Event Series | Annex Line connections: unbalanced and balanced There are two basic ways to transport an audio signal with microphone or line level: Balanced XLR (Cannon) to Balanced XLR Unbalanced line: Utilising a two conductor cable, it transports the signal as the voltage between them.
  • Page 43 DAS Audio Group, S.L. DAS Audio of America, Inc. DAS Audio Asia PTE. LTD. C/ Islas Baleares, 24 6900 NW 52nd Street Miami, FL 9 Gray Lane 03-01 46988. Fuente del Jarro 33166 – U.S.A Signature Crest Valencia - Spanien Tel.
  • Page 44 Event Series User's Manual...
