Page 1
User's Manual Sound Force : Distributed Systems SF-10 / SF-26 / SF-158 / SF-212 / SF-218 Antes de utilizar el equipo, lea la sección “Precauciones de seguridad” de este manual. Conserve este manual para futuras consultas. Before operating the device, please read the “Safety precautions”...
CONTENTS SAFETY PRECAUTIONS WARRANTY DECLARATION OF CONFORMITY 6 - 7 INTRODUCTION CONFIGURATIONS 8 - 11 4 x SF-221 + 4 x SF-158 (4 WAY) + D series 4 x SF-221 + 4 x SF-158 (3 WAY) + D series 4 x SF-221 + 4 x SF-158 (4 WAY) + DX series 4 x SF-221 + 4 x SF-158 (3 WAY) + DX series 2 x SF-212 + 4 x SF-10 2 x SF-212 + 6 x SF-26...
Precauciones de Seguridad SF-10 / SF-26 / SF-158 / SF-212 / SF-218 Safety Precautions Cajas acústicas pasivas / Passive loudspeaker enclosures Conserve y lea todas estas instrucciones. Keep these instructions. Siga todas las advertencias. Heed all warnings. Follow all instructions. El signo de exclamación dentro de un triángulo indica la The exclamation point inside an equilateral triangle indicates the existencia de componentes internos cuyo reemplazo puede...
GARANTÍA Todos nuestros productos están garantizados por un periodo de 24 meses desde la fecha de compra. Las garantías sólo serán válidas si son por un defecto de fabricación y en ningún caso por un uso incorrecto del producto. reparaciones garantía pueden realizadas,...
INTRODUCTION The Sound Force (SF) series has been designed for today´s high-level dance venues where exceptional sound, imposing power and impressive looks are key requisites. Thanks to the modularity of the series, the designers of the rooms have a variety of combinations to mid- high, medium-low and subwoofers that can be adapted to specific local needs.
Page 7
SF-158 - Three-way full-range system – 1 x 15GNR horn loaded bass loudspeaker – 1 x 8AN horn loaded mid-range loudspeaker – M-75N neodymium compression driver – Selectable biamp/triamp operating modes – Tight 40º x 30º coverage angles – Rotatable horn for vertical or horizontal positioning The SF-158 3-way, full-range system is designed to provide the Sound Force series with a powerful stand-alone solution.
CONFIGURATIONS (cont’d) 2 x SF-212 + 4 x SF-10 ±1 ±1 CONNECTOR NL4 CONNECTOR NL4 DX SERIES DSP PROTECTION BRIDGE 1+2 PROCESSING POWER AMPLIFIER BRIDGE 3+4 BACK MENU NEXT STBY MUTE ADJUST CLIP G.R. REMOTE AUX 1-4 DIGITAL IN IN A-D NETWORK AUDIO QUIT ENTER...
CONFIGURATIONS (cont’d) 2 x SF-218 + 8 x SF-10 ±1 ±1 CONNECTOR NL4 CONNECTOR NL4 DX SERIES DSP PROTECTION PROCESSING POWER AMPLIFIER BRIDGE 1+2 BRIDGE 3+4 BACK MENU NEXT STBY MUTE ADJUST CLIP G.R. REMOTE AUX 1-4 DIGITAL IN IN A-D NETWORK AUDIO QUIT ENTER...
INSTALLATION Connectors The D.A.S. SF series is designed to facilitate the connection for installations, so it has been provided with two types of connectors: the NL4 type (NL8 in SF-158) is standard for professional audio equipment. These terminals are connected in parallel, so that we can carry the amplified audio signal up to a device and we can forward it to the next box, very easily.
Page 15
Coverages The SF-10, SF-26 and SF-158 models are designed with trapezoid enclosures to very easily achieve the desired coverages in fixed installations. Next, we show the horizontal coverage with three units of SF-158, as example (enclosures seen from above) : SF-158 Manual del Usuario / SF series / User’s Manual...
Page 16
As examples, next, you will see three coverages with Sound Force series models. Angle between SF-10: 80º (separate cabinets at the front 40cm) Total Horizontal Coverage angle: 160º Shown SPL Map at 4kHz Angle between SF-158: 30º (side to side) Total Horizontal Coverage angle: 90º...
Page 17
Angle between SF-158: 30º (side to side) Total Horizontal Coverage angle: 100º Shown SPL Map at 4kHz Note: This example as shown on page 15. Manual del Usuario / SF series / User’s Manual...
ACCESSORIES To perform any operations related to flying the system, read the present document first, and act on the warnings and advice given. The goal is to allow the user to become familiar with the mechanical elements required to fly the acoustic system, as well as the safety measures to be taken during set-up and teardown.
Page 19
To hang the units, the Allen-head screws must be removed and replaced by M10 eyebolts on one side of the enclosure. Each rigging point has 200 kg (440 lb) working load limit. Then choose the slings or chains of required load resistance and length, bearing in mind that the length difference between the front and back slings or chains will determine the vertical orientation.
Page 20
Rear view Frontal view Side view Vertical Array Stacked Systems However, the most common will be the stacking systems. Below is an example (2x SF-158 upon 2x SF-221), step by step. First, we will stack 2x SF-221 as shown below, joining the boxes with 4x AX-SF2. Manual del Usuario / SF series / User’s Manual...
Page 21
Now, we will screw the AX-SF2158 over them. Next, we will screw 2x SF-158 to the AX-SF2158. Manual del Usuario / SF series / User’s Manual...
Page 22
Finally, we will join the SF-158 units with 2x AX-SF2. As can be seen, the result is a solid stacked system. Manual del Usuario / SF series / User’s Manual...
ANNEX : Table for cable selection This table shows the power loss in % and dB, for different cable lengths and sections shown. It is recommended that the losses do not exceed 30% in any case (around 3dB). Although it is recommended minimizing losses, the maximum acceptable losses are usually around 15% (approximately 1.4dB).
Page 24
www.dasaudio.com D.A.S. AUDIO, S.A. D.A.S. AUDIO OF AMERICA, INC. D.A.S. AUDIO ASIA PTE. LTD. C/. Islas Baleares, 24 6900 NW 52th Street 3 Temasek Avenue, Centennial Tower #34-36 46988 Fuente del Jarro Miami, FL. 33166 - U.S.A. Singapore 039190 Valencia, SPAIN TOLL FREE: 1 888 DAS 4 USA Tel.
