VIESMANN
Service instructions
for contractors
Vitocrossal 300
Type CU3A, 13 to 60 kW
Gas condensing boiler with MatriX gas burner
and Lambda Pro Control,
Natural gas and LPG version
Open flue and room sealed operation
VITOCROSSAL 300
Please keep safe.
6192251 GB
4/2024
