Trejon OPTIMAL 1802H Instructions For Use And Maintenance Manual

Hydraulic driven snow blower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions for Use and
Maintenance
Hydraulic driven
1802H, 2002H, 2202H, 2402H
TREJON FÖRSÄLJNING AB
Företagsvägen 9
SE-911 35 VÄNNÄSBY
SWEDEN
Tel: + 46 (0)935 39 900
Webb: trejon.se
Snow blower
Note!
Read instructions before use
Edition: 2024–10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPTIMAL 1802H and is the answer not in the manual?

Questions and answers

Related Manuals for Trejon OPTIMAL 1802H

Summary of Contents for Trejon OPTIMAL 1802H

  • Page 1 Edition: 2024–10 Instructions for Use and Maintenance Hydraulic driven Snow blower 1802H, 2002H, 2202H, 2402H Note! Read instructions before use TREJON FÖRSÄLJNING AB Företagsvägen 9 SE-911 35 VÄNNÄSBY SWEDEN Tel: + 46 (0)935 39 900 Webb: trejon.se...
  • Page 2 Instructions for Use and Maintenance 1802H-2402H (2410) Breddningsving en monteras på insidan av maskinen...

  • Page 3: Table Of Contents

    Instructions for Use and Maintenance 1802H-2402H (2410)  TABLE OF CONTENTS Introduction....................7 Foreword ....................7 Description ....................7 Breddningsving Working stages ..................7 en monteras på insidan av Detailed description ................... 8 maskinen Technical data ................... 9 Safety instructions ..................10 Safety precautions ...................

  • Page 4: Safety Symbols

    Instructions for Use and Maintenance 1802H-2402H (2410) SAFETY SYMBOLS Note! This warning symbol is used throughout this instruction manual to call attention to safety precautions that you, your employees or any other people that may come near the implement Breddningsving must read and understand.
  • Page 5 Instructions for Use and Maintenance 1802H-2402H (2410) Dear Customer, You have made a good choice. We congratulate you to your selection of an TREJON OPTIMAL product that offers quality and performance with reliable service. By reading the manual and following its recommendations you will ensure the long and effective use of the equipment.
  • Page 6 Having gone through and explained to the customer, with the help of the manual, the startup, use and maintenance of the equipment and it’s accessories. Fill out the guarantee form with the customer and register at trejon.se Instruction manual given to the customer.

  • Page 7: Introduction

    Oil flow and working pressure at tractors hydraulic system is the factors that decide which effect the hydraulic motor will deliver. TREJON deliver snow blower with a hydraulic motor that will suit the figures about tractors hydraulic system given at order of new machine.

  • Page 8: Detailed Description

    Instructions for Use and Maintenance 1802H-2402H (2410) 1.4 Detailed description Frame Ejector tube (long or short tube) Twin flap Discharge rotor Breddningsving Auger en monteras på Flap control insidan av Turntable gear maskinen Reversible wearing edge Gearbox Tool box with holder for additional shear bolts Hydraulic motor, axial pistol type Open able shields, break coupling auger Connection for leak-oil lead, 2 pcs...

  • Page 9: Technical Data

    Instructions for Use and Maintenance 1802H-2402H (2410) 1.5 Technical data Specifikationer / 1802H 2002H 2202H 2402H Modell Working width, mm 1820 1950 2150 2350 Breddningsving en monteras på insidan av Frame height, mm maskinen Cutting screws, quantity Cutting screws,  mm 2x 340 2x 340 2x 340...

  • Page 10: Safety Instructions

    Breddningsving for the first time. If any hesitation, ask your Trejon dealer about advise. It is forbidden to use the equipment if user don’t know the risk factors at handling, and don’t know how to act in an en monteras på...
  • Page 11 Instructions for Use and Maintenance 1802H-2402H (2410) Lifting and lowering machine. Be careful when lifting or lowering the machine. Stability. The machine should not be mounted on a tractor with insufficient front shaft /back shaft weight when the tractor becomes unstable and difficult to operate. When using a unit, a minimum 20% of tractor and equipment weight must be on tractor front wheels.
  • Page 12 Instructions for Use and Maintenance 1802H-2402H (2410) Safety during maintenance and repairing. Apply hand brake and place the machine on a hard level surface when maintaining or adjusting it. Always stop the tractor, set brake, shut off the tractor engine, remove the ignition key, and allow machines moving parts to come to a complete stop before dismounting tractor.

  • Page 13: Explanation Of The Symbols

    Instructions for Use and Maintenance 1802H-2402H (2410) 2.2 Explanation of the symbols The warning symbol must always be recognizable. If the warning symbols are missing from your equipment or if they are damaged, replace them at once. The signs to the right have the following meaning: Breddningsving en monteras på...
  • Page 14 Instructions for Use and Maintenance 1802H-2402H (2410) Warning! Decal 4: Keep body parts away from the feeding wings when the machine is running. In case of stoppage, Breddningsving apply hand brake, turn off the engine, place the en monteras på fling on the ground and disconnect the power unit.

  • Page 15: Operating The Machine

    Instructions for Use and Maintenance 1802H-2402H (2410) 3 Operating the machine 3.1 Assembly Breddningsving Caution! en monteras på No persons is allowed to be in danger area during lifting insidan av maskinen Be carefully when cutting bands and wire because they can be very tensed. They can also be very sharp.
  • Page 16 Instructions for Use and Maintenance 1802H-2402H (2410) Connections on the hydraulic motor The snow blower’s motor is available in different sizes in order to fit the tractor’s hydraulic power (flow and working pressure). The type of the motor can be found on the type plate of the motor. Breddningsving en monteras på...
  • Page 17 Instructions for Use and Maintenance 1802H-2402H (2410) Port. B Pressure: Oil to the hydraulic motor port B is supplied through available outlet on the tractor that delivers the recommended oil flow and pressure. The oil flow from the outlet must be controllable from the tractor cab.

  • Page 18: Before Starting Up

    Instructions for Use and Maintenance 1802H-2402H (2410) 3.3 Before starting up Warning! The hydraulic hoses on the machine contain oil under high pressure. Never touch the Breddningsving hoses or other hydraulic components while there is still pressure in the system. Relieve en monteras på...
  • Page 19 Instructions for Use and Maintenance 1802H-2402H (2410) Support pads The height of the equipment is adjusted with two supporting pads located at the back. The angle of the equipment is adjusted by the tilt function of the tractor’s loader. This determines the how well the equipment follows the variations in the surface.

  • Page 20: Operating The Machine

    Instructions for Use and Maintenance 1802H-2402H (2410) Breddningsving en monteras på insidan av maskinen Optional mounting holes for the ejector tube. The height of the equipment is adjusted with two supporting pads located at the back. The angle of the equipment is adjusted with the top link. This determines the how well the equipment follows the variations in the surface.
  • Page 21 Instructions for Use and Maintenance 1802H-2402H (2410) Place the snow blower on the surface which is to be cleared. Start the snow blower by slowly releasing the oil flow while the tractor’s engine is at idle speed. Change to a higher gear. If you want to turn off the snow blower, perform the above procedure in reverse order.

  • Page 22: Service And Maintenance

    Instructions for Use and Maintenance 1802H-2402H (2410) 4 Service and maintenance Warning! Always turn off the engine and wait until the machine has completely stopped before performing any kind of service or maintenance on the machine. Remove the ignition key Breddningsving from the ignition switch.

  • Page 23: Maintenance Schedule

    Instructions for Use and Maintenance 1802H-2402H (2410) 4.2 Maintenance schedule Position Interval Type Number Note The whole Check that all screws and bolts are All screws and bolts Check equipment properly tightened and not loose. Check the wearing edge for wear. Wearing edge Daily Check...

  • Page 24: Dismounting / Mounting Of Hydraulic Motor

    Instructions for Use and Maintenance 1802H-2402H (2410) Breddningsving Breather/filler plug Inspection glass for the oil level. en monteras på insidan av maskinen Oil change The oil in the gearbox must be changed after the first 50 hours of service and the again every 500 hours or at least once a year.
  • Page 25 Instructions for Use and Maintenance 1802H-2402H (2410) Dismounting: 1. Dismount the hydraulic lines to the hydraulic motor, plug connections on motor and hoses with suitable caps. This is done to prevent pollution and oil spills. Breddningsving en monteras på insidan av maskinen 2.

  • Page 26: Troubleshooting

    Instructions for Use and Maintenance 1802H-2402H (2410) 5 Troubleshooting Warning! Before any maintenance, service, repairs or adjustments are carried out, the machine must be lowered to the ground and the engine of the tractor must be stopped. The key Breddningsving must be removed from the starter switch.

  • Page 27: Mounting Of Extension Wing (Accessories)

    Instructions for Use and Maintenance 1802H-2402H (2410) 6 Mounting of extension wing (accessories) Snow blower 1800-2400: art. No 42450 Snow blower 1802-2402: art. No 42450-1 Extension wings are available as accessories for the Optimal 1800-2402 series. The installation is easy and is performed with customary tools and a drill machine. Before installing the Breddningsving implement, make sure that the delivery is complete.
  • Page 28 Instructions for Use and Maintenance 1802H-2402H (2410) 6. Mount the triangular plates to the side wing with screws (M10x30). Place the plates against the snow blower’s frame, mark and drill holes (10,5mm) through the frame. Start drilling with a 5-mm drill, then continue with a 10,5mm. Install the screws (M10x30). 2 st M10x30 Breddningsving 2 st M10x30...

  • Page 29: Spare Parts

    Guaranteed availability through the TREJON sales partners The TREJON original spare parts are specifically made for this equipment. The fitting and/or use of non-original parts and accessories may change the technical qualities of your equipment in a negative way. The manufacturer does not give any guarantee for damages caused by using non-original parts or accessories.
  • Page 30 Instructions for Use and Maintenance 1802H-2402H (2410) Notes Breddningsving en monteras på insidan av maskinen...
  • Page 31 Instructions for Use and Maintenance 1802H-2402H (2410) Notes Breddningsving en monteras på insidan av maskinen...
  • Page 32 Instructions for Use and Maintenance 1802H-2402H (2410) Breddningsving en monteras på insidan av maskinen...
  • Page 33 Instructions for Use and Maintenance 1802H-2402H (2410) Breddningsving en monteras på insidan av maskinen...
  • Page 34 TREJON AB reserves the right to change or to improve shown models using technical or commercial reasons, without demands to carry out the same improvements on equipment already delivered. Pictures in the manual do not necessarily show the equipment as delivered.
  • Page 35 Instructions for Use and Maintenance 1802H-2402H (2410) Breddningsving en monteras på insidan av maskinen TREJON FÖRSÄLJNING AB Företagsvägen 9 SE-911 35 VÄNNÄSBY SWEDEN Tel: + 46 (0)935 39 900 Webb: trejon.se...

This manual is also suitable for:

Optimal 2002hOptimal 2202hOptimal 2402h
