Page 1: Snow Blower
Edition: 2018-10 Instructions for Use and Maintenance Snow Blower 1800HD-2402HD Note! Read instructions before use TREJON FÖRSÄLJNINGS AB Företagsvägen 9 SE-911 35 VÄNNÄSBY SWEDEN Tel: + 46 (0)935 39 900 Webb: trejon.se... - Page 2 00HD-2402HD (1810) Instructions for Use and maintenance 18 Breddningsvinge n monteras på insidan av maskinen...
-
Page 3: Table Of Contents
00HD-2402HD (1810) Instructions for Use and maintenance 18 TABLE OF CONTENT Introduction....................7 Foreword ....................7 Description....................7 Breddningsvinge n monteras på Working stages ..................7 insidan av maskinen Detailed description ................... 8 Technical data ................... 9 Safety instructions ..................10 Safety precautions ................... -
Page 4: Safety Symbols
00HD-2402HD (1810) Instructions for Use and maintenance 18 SAFETY SYMBOLS Breddningsvinge Note! This warning symbol is used throughout this instruction manual to call attention to safety n monteras på precautions that you, your employees or any other people that may come near the implement insidan av must read and understand. - Page 5 Instructions for Use and maintenance 18 Dear Customer, You have made a good choice. We congratulate you to your selection of a TREJON OPTIMAL product that offers quality and performance with reliable service. By reading the manual and following its recommendations you will ensure the long and effective use of the equipment.
- Page 6 Having gone through and explained to the customer, with the help of the manual, the startup, use and maintenance of the equipment and it’s accessories. Fill out the guarantee form with the customer and register at trejon.se Instruction manual given to the customer.
-
Page 7: Introduction
1 Introduction 1.1 Foreword Thank you for choosing this TREJON OPTIMAL machine. We have concentrated our efforts in order to develop a sturdy machine that will operate trouble-free for many years. The working life of the machine, however, depends not only on us but also on you. We have compiled this... -
Page 8: Detailed Description
00HD-2402HD (1810) Instructions for Use and maintenance 18 1.4 Detailed description Chassie Ejector tube (long or short tube) Twinflap Ejecting rotor Feeding augers (1pcs at 1800 and 2000HD) Breddningsvinge Flap control n monteras på Turntable gear insidan av Reversible wearing edge maskinen Gearbox Drive shaft for frontal mounting, 1000 rpm... -
Page 9: Technical Data
00HD-2402HD (1810) Instructions for Use and maintenance 18 1.5 Technical data Technical data / model 1800HD 2000HD 2002HD 2202HD 2402HD Breddningsvinge Working width, mm 1820 1950 1950 2150 2350 n monteras på Frame height, mm insidan av Cutting auger, units maskinen Cutting auger, ... -
Page 10: Safety Instructions
If any hesitation, ask your Trejon dealer about advise. It is forbidden to use the equipment if user don’t know the risk factors at handling, and don’t know how to act in an Breddningsvinge n monteras på... - Page 11 00HD-2402HD (1810) Instructions for Use and maintenance 18 PTO-shaft. When changing tractor always check the length of the PTO-shaft, a to long shaft can damage both tractor and machine. It is forbidden to use PTO-shaft that does not fulfill requirements from manufacture. Make sure that PTO-shields are in good condition and fastened securely to the tractor.
- Page 12 00HD-2402HD (1810) Instructions for Use and maintenance 18 Safety during maintenance and repairing. Apply hand brake and place the machine on a hard level surface when maintaining or adjusting it. Always stop the tractor, set brake, shut off the tractor engine, remove the ignition key, and allow machines moving parts to come to a complete stop before dismounting tractor.
-
Page 13: Explanation Of The Symbols
00HD-2402HD (1810) Instructions for Use and maintenance 18 2.2 Explanation of the symbols The warning symbol must always be recognizable. If the warning symbols are missing from your equipment or if they are damaged, replace them at once. The symbol to the right shows: Breddningsvinge n monteras på... - Page 14 00HD-2402HD (1810) Instructions for Use and maintenance 18 Warning! Do not touch the feed blades or the feed screws as long as the tractor’s engine is running and the PTO shaft is Breddningsvinge engaged. n monteras på Maintain the safety distance. insidan av maskinen Warning!
-
Page 15: Using The Equipment
00HD-2402HD (1810) Instructions for Use and maintenance 18 3 Using the equipment 3.1 Assembly Breddningsvinge Caution! n monteras på No persons is allowed to be in danger area during lifting insidan av maskinen Be carefully when cutting bands and wire because they can be very tensed. They can also be very sharp. -
Page 16: Attaching Machine To The Tractor
00HD-2402HD (1810) Instructions for Use and maintenance 18 Breddningsvinge n monteras på insidan av maskinen Machine front mounted to a tractor using the A-frame connection. If the equipment is mounted on the front, or is to be used on a reversing machine, one should strive to mount the towing frame so low that the lifting arms of the tractor steers the equipment as low as possible. - Page 17 00HD-2402HD (1810) Instructions for Use and maintenance 18 Attach the machine at a hard level surface. Attach tractors lifting arms to lower connection points at machine, and there after the top link, (choose connection points that make lifting arms and top link as parallel as possible, all to make machine levelled during lifting) Turn of tractor’s engine and apply the hand brake.
-
Page 18: Before Starting Up
00HD-2402HD (1810) Instructions for Use and maintenance 18 3.3 Before starting up Before starting up, following items must be checked. Check the screws and bolts at the machine and tighten if necessary. See table with recommended torque settings in section “Service and maintenance”. Breddningsvinge Check that all protective devices are undamaged and correctly attached to the equipment. - Page 19 00HD-2402HD (1810) Instructions for Use and maintenance 18 Screws that must be taken away, when the height is adjusted at the support pads. Breddningsvinge n monteras på insidan av maskinen Ejector tube The equipment comes fitted with a hydraulically turntable ejector tube as standard. At the end of the tube is a flap that regulates the distance the snow is thrown.
-
Page 20: Operating The Machine
00HD-2402HD (1810) Instructions for Use and maintenance 18 The ejector tube has two mounting holes. These will enable you to regulate the distance the ejected snow is thrown. Breddningsvinge n monteras på insidan av maskinen Optional mounting holes for the ejector tube. - Page 21 00HD-2402HD (1810) Instructions for Use and maintenance 18 Keep the specified PTO 540 / 1000 rpm’s all through the run. Try to keep the line of the PTO shaft as straight as possible when running the equipment. A standard PTO shaft must not operate at angles exceeding 35 degrees.
-
Page 22: Service And Maintenance
00HD-2402HD (1810) Instructions for Use and maintenance 18 4 Service and maintenance Warning! Breddningsvinge At any time when performing repairs and maintenance, the engine must be switched off n monteras på and the PTO shaft disconnected. Withdraw the ignition key from the switch. insidan av maskinen No work is allowed unless the equipment is safely secured. -
Page 23: Maintenance Schedule
00HD-2402HD (1810) Instructions for Use and maintenance 18 4.2 Maintenance schedule Position Interval Type Number Note PTO shaft Grease 2 pieces NLGI2 EP Universal joint NLGI2 EP, separate the two PTO shaft Breddningsvinge Grease 1 piece halves of the shaft and grease Profiled tubes n monteras på... -
Page 24: After The Snowy Season
00HD-2402HD (1810) Instructions for Use and maintenance 18 4.4 After the snowy season After the season, the equipment must be thoroughly cleaned, and then greased and serviced. When the machine is dry, we suggest that you cover the parts were the paint has worn away with a thin coating of oil. -
Page 25: Troubleshooting
00HD-2402HD (1810) Instructions for Use and maintenance 18 5 Troubleshooting Warning! Before any maintenance, service, repairs or adjustments are carried out, the equipment must be lowered to the ground and the engine of the tractor must be stopped. The key Breddningsvinge must be removed from the starter switch. -
Page 26: Options
6.1 Mounting of extension wing (accessories) Snow blower 2000HD-2402HD: art. No 42450 Breddningsvinge Extension wings are available as accessories for the Trejon Optimal HD-series. The installation n monteras på is easy and is performed with customary tools and a drill machine. Before installing the insidan av implement, make sure that the delivery is complete. - Page 27 00HD-2402HD (1810) Instructions for Use and maintenance 18 2 pcs M10x30 2 pcs M10x30 Breddningsvinge n monteras på insidan av maskinen 7. Tighten all screws thoroughly. Tighten the screws again after the first hour of operation. Caution! Be careful not to strike obstacles during work as this may damage the wing and fling.
-
Page 28: Spare Parts
• Guaranteed availability through the TREJON sales partners The TREJON original spare parts are specifically made for this equipment. The fitting and/or use of non-original parts and accessories may change the technical qualities of your equipment in a negative way. The manufacturer does not give any guarantee for damages caused by using non-original parts or accessories. - Page 29 00HD-2402HD (1810) Instructions for Use and maintenance 18 Notes Breddningsvinge n monteras på insidan av maskinen...
- Page 30 00HD-2402HD (1810) Instructions for Use and maintenance 18 Notes: Breddningsvinge n monteras på insidan av maskinen...
-
Page 31: Ec-Certificate Of Conformity
(full address of company – where this concerns authorized agents within the Common Market, also state the company name and manufacturer) declare in sole responsibility, that the product Snow blower TREJON OPTIMAL 1800HD Snow blower TREJON OPTIMAL 2000HD Snow blower TREJON OPTIMAL 2002HD... - Page 32 00HD-2402HD (1810) Instructions for Use and maintenance 18 Breddningsvinge n monteras på insidan av maskinen...
- Page 33 00HD-2402HD (1810) Instructions for Use and maintenance 18 Breddningsvinge n monteras på insidan av maskinen...
- Page 34 00HD-2402HD (1810) Instructions for Use and maintenance 18 Breddningsvinge n monteras på insidan av maskinen...
- Page 35 TREJON AB reserves the right to change or to improve shown models using technical or commercial reasons, without demands to carry out the same improvements on equipment already delivered. Pictures in the manual do not necessarily show the equipment as delivered.
- Page 36 00HD-2402HD (1810) Instructions for Use and maintenance 18 Breddningsvinge n monteras på insidan av maskinen TREJON FÖRSÄLJNINGS AB Företagsvägen 9 SE-911 35 VÄNNÄSBY SWEDEN Tel: + 46 (0)935 39 900 Webb: trejon.se...
