7 - TROUBLE SHOOTING:
Some models may use R-290 (Propane) as a refrigerant. Service and repair must be performed by qualified re-
frigeration technicians familiar with applicable safety standards for flammable refrigerants. Technicians must use appropriate
personal protective equipment and follow applicable safely precautions to avoid risk of fire or explosion. Service and repair
must be performed in well ventilated and unconfined area, away from any ignition sources. All system components must be
replaced with like components. Factory recommends to use exact make and models to assure the consistent performance and
to minimize the risk of possible ignition due to incorrect parts. In case of uncertainty or parts unavailability, contact Traulsen
technical assistance at 800-825-8220.
PROBLEM
1. Condensing unit fails to start. a. Check if cord & plug has been disconnected.
2. Condensing unit operates for prolonged a. Are door(s) or drawer(s) closing properly?
periods or continuously. b. Dirty condenser or filter. Clean properly.
c. Evaporator coils iced. Needs to defrost.
3. Food Compartment is too warm. a. Check door(s) or drawer(s) and gasket(s) for proper seal.
b. Check if a large quantity of warm food was recently added or the door was kept open for a long period of
time.
c. Microprocessor control setting is too high, readjust.
4. Food Compartment is too cold. a. Check if a large quantity of very cold or frozen food has recently been added. Allow adequate time for the
cabinet to recover its normal operating temperature.
b. Adjust the microprocessor control to warmer setting, readjust.
5. Condensation on exterior surface. a. Check door(s) or drawer(s) alignment & gaskets for proper seal.
b. Condensation on the exterior surface of the unit is perfectly normal during periods of high humidity.
c. Check perimeter heat setting and increase setting if <100.
8 - SERVICE/WARRANTY INFORMATION:
Amp Plate
Before making contact at 800-825-8220, please make sure you have model and serial number of your
unit. Amp plate with information needed is located inside the unit.
Please visit our website at www.traulsen.com for additional service, literature and parts information. From our home page click on
the SERVICE tab, and select one of the following:
SERVICE FINDER
OWNER'S MANUALS
PARTS PRICING
SERVICE & PARTS MANUALS
WARRANTY REGISTRATION
HOURS OF OPERATION:
Monday thru Friday 7:30 am - 4:30 pm CST
T
raulsen
4401 Blue Moud Road Fort Worth, TX 76106
Phone (800) 825-8220 Service Fax (817) 740-6757
www.traulsen.com
Quality Refrigeration
© 2017 Traulsen - All Rights Reserved
POSSIBLE SOLUTION
:
Quality Refrigeration
Quick Start Guide
1. RECEIPT & SUPPORT INSTALLATION:
You should carefully inspect your Traulsen unit for damage during delivery. If damage is detected, you should save all the crating
materials and make note on the carrier's Bill Of Lading describing this. A freight claim should be filed within 5 days.
After uncrating the unit, select a level location for final placement. Install the casters (or optional leg supports) as shown below.
Supports: "Stem" type casters (standard). "Stem" type legs (optional).
Some models may use R-290 (Propane) as a refrigerant. If flammable refrigerant is present, follow instructions
as labeled on the unit. Proper care must be taken to avoid any damage to refrigeration system including refrigerant tubing, con-
denser, evaporator coils during handling, moving, installation and cleaning as it may cause risk of fire or explosion. If damaged,
unit must be moved to well ventilated area away from any sources of ignition.
Further service and repair must be performed by qualified refrigeration technicians familiar with applicable safety standards
for flammable refrigerants. Technicians must use appropriate personal protective equipment and follow applicable safety pre-
cautions to avoid risk of fire or explosion.
All models (except compact undercounter) should be installed to allow at least 12" of clear space above the unit. In all cases the
louvers must be free of any obstruction which could prevent proper air-flow.
Most units are supplied with a cord and plug, which can simply be plugged into a dedicated appropriately sized outlet. For those
requiring hard-wiring directly to the power supply, this should be done by a qualified electrician only.
2. CONTROL OVERVIEW:
Most Traulsen equipment is plug and play, such as G Series and most Compacts. However, once power is supplied to the unit, you
may make minor adjustments to your Traulsen unit.
2A- CONTROLLER DISPLAY
Unlock symbol Status icons + or Next key
Cabinet Temp
- or Previous key
Instructions for the installation, use and care of:
G Series Reach-In & Pass-Thru
Compact Undercounter
Compact Prep-Table
Esc or Back key
Unlock or Modify
key
Display or Enter
key
TR36058 P/N 375-60352-00 (09-15-17)
