- Page 1 TR P-S E RIE S P R EP TA BL ES 4401 Blue Mound Road Fort Worth, Texas 76106 (USA) Phone: 800.825.8220 | Service Fax: 817.740.6757 | E-mail: service@traulsen.com | Website: traulsen.com Hours Of Operation: Monday - Friday 7:30 a.m. - 4:30 p.m. (CST)
-
Page 2: Table Of Contents
This Traulsen unit is built to our highest quality standards. We build our refrigerators this way as a matter of pride. This philosophy has made Traulsen the leader in commercial refrigeration since 1938. We thank you for your choice and confidence in Traulsen equipment and we know you will receive many years of utility from this equipment. -
Page 3: The Serial Tag
1A – SERIAL TAG & LOCATION: The serial tag is a permanently affixed label on which is recorded vital electrical and refrigeration data about your Traulsen product, as well as the model and serial number. This tag is located inside the lower storage cabinet on the right hand wall on all standard TRP models. -
Page 4: C Installing Parts Shipped Loose-Cutting Board
Be careful not to catch the filter on sharp edges when installing. Replace louvered panel by installing top of panel into track and pushing in the bottom so that the locking clips fit inside the opening (See Fig. 3). Fig. 3 TRP SERIES Page 4... -
Page 5: E Installing Parts Shipped Loose-Electric Condensate Evaporator
PROPER GROUNDING TYPE, CONTACT AN ELECTRI- If no holding charge is evident upon opening lines, contact CIAN. Traulsen Service and Parts Department at (800) 825-8220 immediately. PERMANENTLY WIRED UNITS (Remote models) A junction box located on back of the machine near bottom is Cut refrigeration tubing with tube cutter (not a hacksaw) and provided for electrical field connections. -
Page 6: Prestart Checks
6A - DEFROST TIME CLOCK SETTINGS (FOR PAN CHILLERS): Never apply power to a Traulsen unit without setting the time clock to the correct time of day. (Note: All time clocks are preset at the factory to turn the Pan Chiller "off at 12:00 midnight and back on at 5:00 a.m." unless otherwise instructed by customer). -
Page 7: D Temperature Control Settings
“Base Refrigerator” should be set at 37°F (2.7°C) with a 3° differential. This display should read between 34°F (1.1°C) and 40°F (4.4°C). The temperature control settings are “locked” to avoid unauthorized adjustments. Therefore, adjustments to the set point must be made by an authorized service technician. TRP SERIES Page 7... -
Page 8: Operation
DO NOT HOSE DOWN OR POUR WATER OR LIQUID CLEANERS IN THE PAN CHILLER COMPARTMENT AS THIS COULD CAUSE DAMAGE TO THE PAN CHILLER AND REQUIRE AN AUTHORIZED SERVICE TECHNICIAN TO REPAIR. FAILURE TO FOLLOW THIS INSTRUCTION WILL VOID WARRANTY. (FOR PROPER CLEANING PROCE- DURES SEE “MAINTENANCE PROCEDURES”). TRP SERIES Page 8... -
Page 9: Maintenance Procedures
Liner Locks to drop away from the top of the liner. The entire frame assembly is now free to slide out of cabinet (See Figs. 12 & 13). Fig. 13 Fig. 12 DRAWER MODULE LINER LOCK CROSS RAIL LOCK BACK BACK CLAMPING CLAMPING KNOB KNOB CROSS RAIL LOCK (1 EACH SIDE) TRP SERIES Page 9... -
Page 10: C Cleaning: Pan Chiller
Condenser fins that are clogged with dirt and debris greatly reduce required airflow. Failure to keep the coil fins and the air filter clean may cause premature compressor failure, which will not be covered by warranty. (On models that contain filters, operating unit without filter will void warranty). TRP SERIES Page 10... -
Page 11: E Evaporator Coils
Carefully clean dirt and lint from the condenser coil using a vacuum cleaner or soft brush; do not use a wire brush. These units do not have a removable filter. Replace slotted access panel. Reconnect electrical supply. Replacement filters are available through the Traulsen Parts and Service Department: (800) 825-8220. 8E - CLEANING: EVAPORATOR COILS: WARNING: DISCONNECT ELECTRICAL POWER SUPPLY BEFORE CLEANING ANY PARTS ON THE UNIT. -
Page 12: Tips
11. SERVICE For additional information, contact the Traulsen Parts and Service Department: (800) 825-8220 between 7:30 am – 4:30 pm CST, Monday thru Friday. You may also log onto www.traulsen.com for further information. Traulsen QR Code... -
Page 13: Wiring Diagram
DEFROST WHITE TIMER CONTROL BLACK PAN CHILLER SOLENOID VALVE WHITE WHITE BLACK BLACK BLUE WHITE CONTROL REFRIGERATED BASE SOLENOID VALVE WHITE REFRIGERATED BASE FAN BLACK BLACK CONDENSING UNIT BLACK BLACK WHITE PRESSURE CONTROL (SUCTION) OPTIONAL 379-60553-00 TRP SERIES Page 13... -
Page 14: Warranties
Purchaser. In the case of a nonconforming part, Purchaser must return the part to Traulsen within 30 days from the date of repair. Failure to return a claimed defective part to Traulsen within the 30 days will waive the right to the warranty claim. - Page 15 NOTES TRP SERIES Page 15...
- Page 16 Quality Refrigeration 4401 Blue Mound Road Fort Worth, Texas 76106 (USA) Phone: 800.825.8220 | Service Fax: 817.740.6757 | E-mail: service@traulsen.com | Website: traulsen.com Form Number: TR36012 | Part Number: 375-60350-00 | Revision Date: 01-23-17 Traulsen © All Rights Reserved...
