Complete Set - DNIPRO M ML-330R Safety And Operation Manual

Protection degree III against electric
shock
Symbol of compliance with technical
regulations (Ukraine)
A special symbol certifies that
the device complies with basic
requirements of EU directives and
harmonized EU standards
A unified symbol of product turnover
on the market of the member states
of the Eurasian Economic Union
Separate collection of electrical
and electronic equipment (in order
to prevent possible environmental
damage, one should separate
electrical and electronic equipment
from other wastes and dispose of in
the safest possible way)

COMPLETE SET

1 Laser level
2 Textile casing (for ML-330R model) 1 pce.
3 Plastic casing (for ML-335G model) 1 pce.
4 Power supply unit
5 Type-C cable
6 Safety glasses
7 Target cell
8 Li-Ion battery
9 Microfiber
Original safety and operation
10
manual
INTENDED PURPOSE AND
APPEARANCE
Intended purpose
The laser level is a modern and functional
product designed for projecting visible laser
planes when carrying out indoor and outdoor
operations. This allows to build horizontal and
vertical planes.
Functionality:
– pendulum mechanism lock for safe transpor-
tation;
– OUTDOOR function for operating the laser
beam receiver indoors or outdoors;
– the device emits up to two vertical lines,
as well as one horizontal line and the pendu-
lum point on the floor. The easy-to-use base
equipped with a micrometer screw allows 360°
30
smooth rotation of the device around its axis;
– quick self-aligning: laser beams are deacti-
vated, the alarm buzzer sounds, and the bub-
ble level starts to flash when the device is set
with a vertical/horizontal inclination above 3°,
which exceeds the aligning range;
– bubble level with a backlit;
– intermediate locking of a pendulum mech-
anism for building planes with an inclination.
The laser level meets the requirements of DSTU
EN 60825-1, DSTU EN 61010-1 and DSTU EN
61326-1.
Appearance
1 Adjustable feet
2 Micrometer screw
3 Activation knob (compensator bar lock)
4 Vertical emitter window
5 Horizontal emitter window
6 Control panel
7 Battery compartment
1 pce.
8 5/8-inch tripod mount
The device has three adjustable feet (Fig.
2). Those feet allow to adjust the vertical/
horizontal position of the laser level. Vertical/
1 pce.
horizontal line helps to set the built-in bubble
1 pce.
level.
1 pce.
Basic controls (Fig. 3)
1 pce.
1 pce. Vertical lines activation/deactivation
1
button
1 pce.
Horizontal lines activation/deactivation
2
1 pce.
button
Laser level activation/deactivation
3
button
Outdoor/indoor mode selection button
4 (short pressing) and sound enable/
disable button (long pressing)
5 Bubble level
Knob for laser level activation/
6 deactivation and pendulum mechanism
lock/unlock
Schematic representation of projected beams
(Fig. 4).
