Chapter 1. Introduction
1.4. Terminology
The nShield Connect is referred to as the nShield Connect, the Hardware Security Module,
or the HSM.
1.5. Handling an nShield Connect
An nShield Connect contains solid-state devices that can withstand normal handling.
However, do not drop the module or expose it to excessive vibration.
If you are installing the module in a 19" rack, make sure that you follow the nShield Connect
Slide Rails Instructions provided with the rails. In particular, be careful of sharp edges.
Only experienced personnel should handle or install an nShield Connect. Always consult
your company health and safety policy before attempting to lift and carry the module. Two
competent persons are required if it is necessary to lift the module to a level above head
height (for example, during installation in a rack or when placing the module on a high shelf).
1.6. Weight and Dimensions
Weight: 11.5kg
Dimensions: 43.4mm x 430mm x 690mm
The module is compatible with 1U 19" rack systems.
Measurements given are height x width x length/depth. If the inner slide rails are attached,
the width of the unpackaged module is 448mm.
1.7. Environmental requirements
To ensure good air flow through and around the module after installation, do not obstruct
either the fans and vents at the rear or the vent at the front. Ensure that there is an air gap
around the module, and that the rack itself is located in a position with good air flow.
1.7.1. Temperature and humidity recommendations
Entrust recommends that your module operates within the following environmental
conditions.
nShield Connect v13.4.5 Install Guide
3/72
