Karma KS-545-2 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KARMA MEDICAL PRODUCTS CO., LTD.
POWER SCOOTER SERIES
KS-747 2
KS-737 2
GMP
GMP
GMP
AS
AS
AS
KS-646 2
KS-545 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS-545-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Karma KS-545-2

Summary of Contents for Karma KS-545-2

  • Page 1 KARMA MEDICAL PRODUCTS CO., LTD. POWER SCOOTER SERIES KS-747 2 KS-737 2 KS-646 2 KS-545 2...

  • Page 2: General Warning

    THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. WARNING: As a manufacturer of power scooters, KARMA endeavors to supply a wide variety of power scooters to meet the many needs of the user. However, the responsibility of final selection of the...
  • Page 3 It is the position of Karma that users of power scooters should be transferred into appropriate seating in vehicles for transportation and make use of the restraints made available by the auto industry.
  • Page 4 For individuals with balance problems, practice mounting and dismounting activities WITH AN ASSISTANT in the presence of a qualified healthcare professional. If so equipped, DO NOT operate the scooter without anti-tippers being installed. Anti-tippers MUST BE attached at all times. DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees as this may cause loss of balance.
  • Page 5 DO NOT use parts, accessories or adapters other than those authorized by Karma. Before attempting to sit in or exit the power scooter, REMOVE the key from the ignition. This will ensure that the POWER is OFF and the power scooter will not drive. Remove the key from the ignition while the scooter is not in use.
  • Page 6 The warranty and performance specifications contained in this manual are based on the use of deep cycle gel cell or sealed lead acid batteries. KARMA strongly recommends their use as the power source for this unit. Carefully read the battery and charger information prior to installing, servicing or operating your scooter.
  • Page 7 Extreme caution is advised when it is necessary to move an UNOCCUPIED power scooter up or down the stairs. Karma recommends disassembling the scooter and transporting the six components independently up or down the stairs. Make sure to use ONLY secure, non-detachable parts on each component for hand-hold supports.

  • Page 8: Table Of Contents

    TABLE OF CONTENTS 1. PREFACE 2. SAFETY 2.1 Before Driving 2.2 While Driving 2.3 Labeling 3. EMI 4. PARTS 5. OPERATION 5.1 Control Panel 5.2 How to Operate Your Scooter 5.3 How to Set the Freewheel Mode 6. BATTERIES AND CHARGER 6.1 Charging the Batteries 6.2 Charger 6.3 Batteries...

  • Page 9: Preface

    This owner's manual is written for Karma Scooters: KS-545 2, KS-646 2, KS-737 2 and KS-747 2. The symbols used in this manual are explained below. Pay special attention to the parts marked with these symbols.

  • Page 10: Safety

    2. SAFETY 2. SAFETY 2.1 Before Driving The user must be familiar with the use and operation of this vehicle before driving. Therefore, please always keep these safety guidelines in mind. Traffic Rules Pedestrian traffic rules apply to this vehicle. Please be safe. Drive only on pedestrian areas such as the sidewalk.

  • Page 11: While Driving

    2. SAFETY No Passengers KARMA Scooters are limited to one driver. Do not carry passengers (including children) on your scooter. No Hauling Heavy Goods Do not use this vehicle to carry or haul heavy goods. The maximum weight that can be carried, including goods, is stated beside "Max.
  • Page 12 2. SAFETY Do not drive in a gale, at night or in rainy/snowy/foggy/misty weather. These conditions may cause you scooter to rust. Do not drive in a figure 8, S curve, do doughnuts or make sudden turns. Do not take an escalator. Mobile Phones and Other Electric Equipment Do not use a mobile phone or other wireless communication devices while driving.

  • Page 13: Labeling

    2. SAFETY Maximum User Weight Limit Refer to "Max. Capacity" in section 9. SPECIFICATIONS. Loads exceeding maximum capacity can damage your scooter and cause malfunctions yielding a safety hazard. The warranty does not cover damage caused by improper operation of the scooter. 2.3 Labeling Please carefully read all the labeling on the scooter before driving it.
  • Page 14 3. If the electric vehicle acts abnormally or the brake system fails, turn off the power source as soon as safely possible. 4. Remember that the installation of non-genuine KARMA parts makes it difficult to predict what effects radio waves will have on the vehicle.

  • Page 15: Emi

    CAUTION: It is very important that you read this information regarding the possible effects of electromagnetic interference on your electric KARMA Scooter. Electromagnetic Interference From Radio Wave Sources Powered vehicles may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy...
  • Page 16 3. EMI There are a number of sources of relatively intense electromagnetic fields in our everyday environment. Some of these sources are obvious and easy to avoid. Others are not apparent and exposure could be unavoidable. However, we believe that by following the warnings listed below, your risk to EMI can be greatly minimized.
  • Page 17 3. EMI Powered Vehicle Electromagnetic Interference (EMI) Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy too close to the powered vehicle's control system while using these devices.
  • Page 18 There is no easy way to evaluate their effect on the overall immunity of the powered vehicle. 5. Report all incidents of unintended movement or brake release to your powered vehicle dealer or KARMA, and note whether there was a source of EMI nearby. Important Information 1.

  • Page 19: Parts

    4. PARTS 4. PARTS Parts Description 1. Headrest 8 . Slide & Swivel 14. Basket 2. Back Rest Levers 15. Steering Column 3. Armrests 9 . Rear View Mirrors Adjustment 4. Driver's Seat 10. Control Panel 16. Headlight 5. Rear Casing 11.
  • Page 20 4. PARTS Circuit Breaker Press To Reset BRAKE (Figure 4.2) 21. Circuit Breaker 22. Turn Signal 23. Taillight 24. Freewheel Lever 25. Anti-tippers...

  • Page 21: Operation

    5. OPERATION 5. OPERATION 5.1 Control Panel 1. Speed Dial 2. Horn Button 3. Turn Signal Buttons 4. Headlight/Taillight Button 5. Variable Speed Levers 6. Battery Indicator 7. Status Indicator 8. Battery & Diagnostics Indicator KS-747 2/KS-737 2 KS-646 2/KS-545 2 (Figure 5.1) (Figure 5.2) 5.2 How to Operate Your Scooter...
  • Page 22 5. OPERATION KS-747 2/KS-737 2 KS-646 2 KS-545 2 (Figure 5.3) (Figure 5.4) (Figure 5.5) Speed Dial Allows you to set various forward and reverse speeds. The settings are not traditional gears, but are a percentage of maximum power. This is gross power, while the variable speed levers help you to fine tune your speed and act similar to an accelerator.
  • Page 23 5. OPERATION Turn Signal Buttons The signal light will flash and a small speaker will make a "beep-beep" sound if you press either the right or left button. Press the button again to turn off the turn signal. Horn Button The horn will sound for the duration of time the button is pressed.
  • Page 24 5. OPERATION Headrest Adjustment 1. To raise headrest, lift headrest up to desired position. 2. To lower headrest, push release button and lower headrest to desired position. Headrest is locked in position when an audible "click" is heard. If the "click" cannot be heard, consult an authorized technician for safety.
  • Page 25 5. OPERATION CAUTION: Be sure to rotate the seat to the forward position and the seat locks into place before driving. Battery Indicator For KS -737 2/KS-747 2 When the ignition is turned on, the battery indicator will light up with a possible total of three red, four orange and three green lines indicating the remaining power of the batteries.
  • Page 26 5. OPERATION SUGGESTION: 1. It is recommended that you charge the batteries immediately when the battery indicator shows only three or less red lines (KS-737 2/KS-747 2) or when only the red light is lit (KS-646 2/KS-545 2). 2. After charging or replacing new batteries, drive the vehicle for 2-3 minutes to make sure the batteries are fully charged.

  • Page 27: How To Set The Freewheel Mode

    5. OPERATION 5.3 How to Set the Freewheel Mode Drive Mode: lift the lever up completely and the scooter can be driven by motor power. (See Figure 5.14) Freewheel Mode: push the lever down completely and the scooter can be pushed manually. Again, the electromagnetic brake does not work in freewheel mode.
  • Page 28 5. OPERATION (Figure 5.16) (Figure 5.17) Starting and Driving 1. Make sure the driver's seat is installed properly. 2. Make sure the steering column has been secured properly. 3. Make sure the armrests have been returned to the proper down position.
  • Page 29 5. OPERATION 3. Do not set the speed dial on high while driving indoors. 4. Do not adjust the speed dial while driving. A sudden change to the highest speed may endanger you and cause failure to your scooter. 5. Do not place magnetic devices near the control panel as this may affect the operation of your scooter.
  • Page 30 5. OPERATION To Stop 1. Release the variable speed lever completely and the electromagnetic brake will stop the vehicle. 2. Come to a complete stop before turning the ignition OFF. 3. Remove the key from the ignition for safety reasons. CAUTION: 1.

  • Page 31: Batteries And Charger

    6. BATTERIES AND CHARGER 6.1 Charging the Batteries Be sure to precisely follow the procedures listed below. 1. Turn the scooter OFF and remove the key. 2. Connect the charger's cord to a power outlet. 3. Open the charging socket cap on the steering column. Then connect the charger's round plug to the charging socket.
  • Page 32 CAUTION: Please follow the guidelines below to avoid accidents while charging. 1. Be sure to only use a KARMA Scooter charger and charge the battery completely every time. The battery can be damaged if a non-genuine charger is used. 2. Never disassemble or modify the charger. This will negate the warranty.
  • Page 33 6. BATTERIES AND CHARGER WARNING: 1. Keep your scooter away from flammable objects while charging, as it may lead to fire or explosion of the battery. 2. Since the battery may produce hydrogen, do not smoke while charging and charge in a well-ventilated area. 3.
  • Page 34 6. BATTERIES AND CHARGER 6.2 Charger Both the charger's red and orange LEDs will be ON during charging. The orange LED will turn green when the charging is completed. WARNING: The fan inside the charger will be activated accordingly when you turn on the charger.

  • Page 35: Power Supply Switch

    6. BATTERIES AND CHARGER Charger Indicator and Status ON/OFF Indicator Status Solid Red Charger ON LED (OFF) Charger OFF Charging Indicator Status LED (OFF) Abnormal Wiring Orange Charging Blinking Orange and Almost fully charged Green Solid Green Fully Charged Front 1.

  • Page 36: Batteries

    6. BATTERIES AND CHARGER 6.3 Batteries Do not expose the batteries to temperatures below -10 C (14 F) or above 50 C (122 F) when charging or storing the vehicle. Exceeding the specified temperature range can lead to either freezing or overheating of the batteries. This will damage the batteries and shorten their lives.
  • Page 37 The warranty and performance specifications contained in this manual are based on the use of deep cycle gel cell or sealed lead acid batteries. Karma strongly recommends their use as the power source for this unit. We also recommend you go to an authorized Karma dealer to have a qualified technician perform this work.
  • Page 38 KS-747 2 NOTE: Charge batteries daily. It is critical not to let them run low at any time. NOTE: Karma recommends that both batteries be replaced if one battery is defective. WARNING: NEVER allow any of your tools and/or battery cables to contact BOTH terminal posts at the same time.
  • Page 39 6. BATTERIES AND CHARGER 6. Remove the batteries and cable assemblies from the scooter. 7. If necessary, lift the battery cable connector/boot off the battery terminal. 8. Position and secure battery cables onto new battery terminals. Connect the black cable to the negative (-) terminal. Connect the red cable to the positive (+) terminal.
  • Page 40 6. BATTERIES AND CHARGER 9. Repeat steps 7-8 for the other battery. 10. Verify that all connections are correct and terminals are secure. 11. Install the new batteries with cable assemblies onto the scooter. 12. Charge the batteries. Battery Wiring Connector Battery Cable Battery Handle Battery Cable Connector...
  • Page 41 5. Take out the battery; and 6. Clean the battery with a clean cloth. SUGGESTION: If necessary, ask for help from your KARMA Scooter dealer for cleaning and replacing the batteries. SUGGESTION: 1. Do not use the battery to charge telecom equipment or other items.
  • Page 42 6. BATTERIES AND CHARGER WARNING: 1. Do NOT allow conductive material such as a wrench to join the two (2) battery terminals. This will result in a dead short that can cause burns to you and damage to the battery. 2.

  • Page 43: Inspection And Maintenance

    7. INSPECTION AND MAINTENANCE 7. INSPECTION AND MAINTENANCE 7.1 Daily Check Check the following items before driving. If you find anything abnormal, visit your KARMA Scooter dealer for further inspection before using it. Inspection Content Item Are they loose and/or making noise?

  • Page 44: Regular Maintenance Record

    Visit a KARMA Scooter dealer for inspection and maintenance if you find anything abnormal. 7.2 Regular Maintenance Record To make sure your scooter is in good condition, visit your KARMA Scooter dealer regularly for maintenance (and keep records accordingly) every six months after purchasing.

  • Page 45: Batteries, Fuses And Tires

    7. INSPECTION AND MAINTENANCE Item/Period Loose or Corroded Terminals Connection to the Electrical System Batteries Damage to the Electrical Cord/Cable Charging Function and LED Lights Charger Socket, Plug and Cords Fan Functions Properly Driver's Slide, Swivel and Recline Levers Seat Steering Turns Smoothly Column...

  • Page 46: General Maintenance

    PC circuit board. Please clean the vehicle by wiping it with either a dry or moist cloth. Please take the vehicle to an authorized KARMA Scooter dealer for repairs and adjustments. Improper adjustments could lead to scooter...
  • Page 47 7. INSPECTION AND MAINTENANCE Please use a soft and dry cloth to keep your scooter clean. Use moderate or mild detergent to clean the scooter, if necessary. CAUTION: Before performing any maintenance, be sure to turn the ignition OFF and unplug the charger if connected. DO NOT over-tighten hardware.

  • Page 48: Transporting And Storing

    Please store the scooter in a location where it is out of direct sunlight, rain and dew. When stored for a long time, please charge the batteries to full and then disconnect the battery terminals. For more details, consult your KARMA Scooter dealer. Disassembling the Scooter NOTE: To reassemble the scooter, reverse the following procedure.
  • Page 49 7. INSPECTION AND MAINTENANCE Rear Frame Battery Wiring Connector Central Relay Box Wiring Connector (Figure 7.1) Seat Assembly Batteries Basket Frame Assembly (Figure 7.2) Removing/Installing the Seat Headrest Back Rest Armrest Seat Cushion Seat Post (Figure 7.3)
  • Page 50 7. INSPECTION AND MAINTENANCE Removing the Seat 1. Remove the stability knob located under the seat on the frame post. 2. Lift the seat up and remove it from the frame post. Seat Post Stability Knob Frame Post (Figure 7.4) Installing the Seat 1.
  • Page 51 7. INSPECTION AND MAINTENANCE CAUTION: CAREFULLY remove the rear casing because the wiring connector for the taillights is connected to the batteries connectors. Otherwise, damage may result. Taillight Wiring Connector Rear Casing Battery Connector (Figure 7.5)

  • Page 52: Troubleshooting

    Charge the batteries. Is the charger plugged into the scooter? Unplug the charger and put it away. If you cannot solve the problem by yourself, contact your KARMA Scooter dealer for help. Status Indicator (LED) and Battery & Diagnostics Indicator The status indicator (KS-545.2 and KS-646.2 only) shows you that...
  • Page 53 8.TROUBLESHOOTING If you do not push the variable speed lever (throttle) as you switch the scooter on and the status indicator flashes rapidly, then there may be a fault. If a fault occurs and you have a scooter model fitted with a TruCharge (Battery &...
  • Page 54 8.TROUBLESHOOTING Motor Disconnected Motor Disconnected There is a bad connection to the motor. Check all connections between the motor and the central relay Bar/Flash box. Motor Wiring Trip Motor Wiring Trip The motor has a short circuit to a battery connection. Bar/Flash Contact your service agent.
  • Page 55 The connection between the motor and the batteries may have short circuited. Contact an authorized Karma technician. The scooter does not drive. The charger may still be connected to the scooter or the seat may not be correctly positioned.
  • Page 56 The battery connections are probably poor. Check all connections between the central relay box and the batteries. 3. After following the above guidelines and eliminating improper operations, if the scooter still does not function, contact an authorized Karma technician immediately.

  • Page 57: Specifications

    9. SPECIFICATIONS 9. SPECIFICATIONS KS-737 2 Model Dimensions 1230 x 640 x 1120mm (L x W x H) 48 x 25 x 44 inches 98.4kg (216lbs) Weight W/ Batteries Weight W/O Batteries 70.6kg (156lbs) Motor 550W* Battery 12V, 50Ah x2 (sealed lead acid) Charger DC24V 5A Front Tire...
  • Page 58 9. SPECIFICATIONS KS-747 2 Model Dimensions 1260 x 680 x 1120mm (L x W x H) 50 x 27 x 44 inches 97.9kg (216lbs) Weight W/ Batteries Weight W/O Batteries 70.1kg (155lbs) Motor 550W* Battery 12V, 50Ah x2 (sealed lead acid) Charger DC24V 5A Front Tire...
  • Page 59 9. SPECIFICATIONS KS-646 2 Model Dimensions 1200 x 640 x 1120mm (L x W x H) 47 x 25 x 44 inches 79.6kg (175lbs) Weight W/ Batteries Weight W/O Batteries 58.2kg (128lbs) Motor 550W* Battery 12V, 36Ah x2 (sealed lead acid) Charger DC24V 5A Front Tire...
  • Page 60 9. SPECIFICATIONS KS-545 2 Model Dimensions 1200 x 590 x 940mm (L x W x H) 48 x 23 x 37 inches 75kg (165lbs) Weight W/ Batteries Weight W/O Batteries 58.6kg (129lbs) Motor 350W* Battery 12V, 36Ah x2 (sealed lead acid) Charger DC24V 5A Front Tire...

  • Page 61: Cleaning And Recycling

    10. CLEANING & RECYCLING 10. CLEANING & RECYCLING CLEANING In order to lengthen the life of your scooter, it is suggested that you clean the scooter periodically (if not daily), especially after it is used in the rain or snow. We suggest that you don't use your scooter in the rain or snow.
  • Page 62 10. CLEANING & RECYCLING POST-CONSUMER RECYCLING A post-consumer recycling plan should follow the Environmental Protection Administration's regulations. The items listed below are for reference only as local law and regulation may vary. Part Name Material Method Frame Steel Recyclable Casing Recyclable Battery Various...

  • Page 63: Warranty

    (a repair of this kind will hereafter be called warranty repair). 2. The warranty repair can be performed by authorized KARMA Scooter dealers only. 3. KARMA is not responsible for the transportation costs for repair and replacement. 4. Replaced parts will be the property of KARMA.
  • Page 64 Problems caused by the following reasons are not covered: 1. Failure to carry out the regular inspection and maintenance recommended by this owner's manual; 2. Improper storage; 3. Tampering by changing or adding components to the vehicle, which are not approved by KARMA;...
  • Page 65 11. WARRANTY 4. Damage caused by using non-KARMA genuine parts or other parts not recommended by KARMA; 5. Abuse or misuse of the vehicle such as driving over curbs and overloading the scooter with passengers or goods; 6. Driving in places where the vehicle should not normally be driven or used;...
  • Page 66 11. WARRANTY 11.2.5 Transfer of Warranty Rights If you purchase a second-hand KARMA Scooter while it is still with in the warranty period, bring the Owner's Manual and the vehicle to the dealership where the scooter was purchased for registration.
  • Page 67 Service Record Dealer & Technician's Date Record Name...
  • Page 68 Always growing, our offices in the United Kingdom, U.S. and Taiwan continue to expand the distribution of our products in the global market under the brand names of Karma's second generation KS 2 Series features upgraded mechanical and electrical integration, a highly efficient transaxle, a multi-level shock absorbing platform, adjustable wide-angle...
