Electronic Control Unit - LIFE home integration PROBO PR60 R Instructions And Warnings For Use

7 – Electronic control unit
Terminal connection:
1- Output + 28 Vdc Max 200 mA
2- Output - 28 Vdc (Common Commands)
3- Input STOP
4- Input STEP
- 5 - Input PHOTOCELLS
6- Output FLASHING Led 28Vdc Max 2W
+
-
COMMON
COMMANDS
N.C.
STOP
N.O.
STEP
N.C.
PHOTOCELLS
2W 28Vdc
FLASHING LED
STEP
4
STOP
3
Exit 28 Vdc
max 100 mA
1
2
3
4
5
6
X
A
B
N.O.
2
2
5
2 -
N.C.
2
1 +
FUSE F2
5X20 0.2mA T
FUSE
FUSE2
RELAY1
MICRO
DIODE
MOS
RES.
PHOTOCELLS
TX
RX
FUSE F1
5X20 4A T
F
U
RELAY2
SE
COND.
7805
LM317
RES. COND.
FLASHING LED
28 Vdc Max 2W
1 +
6 -
of the control unit
Exit
P.11
