TECHNICAL MANUAL
WI-200 TS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Starline WI-200 TS and is the answer not in the manual?

Questions and answers

Summary of Contents for Washtech Starline WI-200 TS

  • Page 1 TECHNICAL MANUAL WI-200 TS...
  • Page 2: General Warnings

    This document is subject to change without prior notice. Information supplied in this manual is copyright. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical without the express permission of Washtech. 10/25/2024...
  • Page 3: Table Of Contents

    Operating Instructions Installation Installation 10. Installation 11. Programs and User Settings 12. Operating Settings 13. Technical Settings 14. Technical Settings 15. Technical Settings 16. Advanced Settings 17. Error Messages 18. Software Updates 19. Software Updates 10/25/2024 Washtech WI200 Technical Manual...
  • Page 4: Safety Instructions

    Installation and servicing must be carried out by a suitably qualified person in compliance with all local codes and standards including AS/NZS 3500.1. 10/25/2024 Washtech WI200 Technical Manual...
  • Page 5: Wi200 Controller

    Loom LCD Interface 0.7 m 600 30425 Loom LCD Interface 2.5 m 600 30426 TFT Display PCBA WI200 600 30624 Loom Low Voltage Interface 3-way 0.7m 600 30486 Loom Kit AC High Voltage 600 30422 10/25/2024 Washtech WI200 Technical Manual...
  • Page 6: Detailed Layouts

    DETAILED LAYOUTS Connector for programming Connector for Display Cable 10/25/2024 Washtech WI200 Technical Manual...
  • Page 7: Operating Instructions

    The default setting of this is 15,000 cycles which can be adjusted. The warning and spanner icon will be removed once the Technical Settings have been accessed. 10/25/2024 Washtech WI200 Technical Manual...
  • Page 8: Installation

    DEFAULT SETTINGS – STANDARD MODELS GM, GL, GLV, UD, UL M2, M2C AL, ALC Models Default program COMPATIBILITY • Suitable as a replacement for the electronic controller in current model Washtech M-Type and A-Type electronic glasswashers and dishwashers. 10/25/2024 Washtech WI200 Technical Manual...
  • Page 9: Installation

    • Suitable as a replacement for the electronic controller in current model Washtech M-Type and A-Type electronic glasswashers and dishwashers. • Retrofits to replace old membrane controllers may be possible, enquire with Washtech along with model and serial if this is desired.
  • Page 10: Programs And User Settings

    1 – 30 sec W-detergent med 1 – 30 sec W-detergent hvy 1 – 30 sec Rinse fluid prime ON/OFF W-rinse fluid time 1 – 30 sec Auto Drain ON/OFF Auto Drain cycles 10 - 100 10/25/2024 Washtech WI200 Technical Manual...
  • Page 11: Operator Settings

    MORE > AUTO-DRAIN CYCLES Only available when AUTO-DRAIN is on. • When ON AUTO-DRAIN operates after a set number of cycles (Between 10 – 100). The machine will then AUTO-DRAIN and refill at that interval. 10/25/2024 Washtech WI200 Technical Manual...
  • Page 12: Technical Settings

    Adds extra drain time at the end of each cycle Extra time 0 – 240 sec For C Models, adds extra time on Condensor Fan Auto drain ON/OFF MORE > INTERLOCK TEMP Min Wash Temp 0, 40-55 10/25/2024 Washtech WI200 Technical Manual...
  • Page 13 Cycle Medium 0 – 720 sec Default setting corresponds to the program selected by the Program Selector switch Cycle Heavy 0 – 720 sec Default setting corresponds to the program selected by the Program Selector switch 10/25/2024 Washtech WI200 Technical Manual...
  • Page 14 Press each of the pump buttons to activate the relay and test the pump function. RINSE TIME • Allows for the rinse cycle time to be adjusted between 12 and 16 seconds. • Factory default for standard units is 12 seconds and 15 seconds for PWs 10/25/2024 Washtech WI200 Technical Manual...
  • Page 15 Program Selector rotary switch on the controller board. INTERLOCK TEMP This is the minimum wash temp before a cycle will start. If set to zero value then this will disable the interlock temp function. Range is 0 – 55. 10/25/2024 Washtech WI200 Technical Manual...
  • Page 16: Advanced Settings

    This set to ON. It is only used when the machine has three phase power. Turning this off, allows the Rinse and Wash elements to be on at the same time, allowing for a faster heating of the machine. A special code is needed to unlock the elements. 10/25/2024 Washtech WI200 Technical Manual...
  • Page 17: Error Messages

    • Should an error message be displayed, following are the details of the most likely causes of the error and standard solution to resolve this. • If in doubt or more information is required, please contact Washtech directly. • To reset the machine after an error message has been displayed, the customer can simply turn it OFF and then back ON again.
  • Page 18: Software Updates

    Washtech machines, the Touch screen requires a USB Memory stick. • The following instructions are valid on the basis that the device is uploaded with Washtech programs. If it is not or you are unsure, refer to the JTAG software uploading and setup guide on the next page.
  • Page 19 Information supplied in this manual is copyright. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical without the express permission of the author/publisher Manufactured in New Zealand by Washtech Ltd. 414 Rosebank Road Avondale Auckland 1026...
