- Page 1 20寸五叶摇头壁扇 145X210MM OWNER'S MANUAL 20 IN. OSCILLATION WALL FAN 120V / 60Hz, 1.35A ITEM NO.: FAN-W20S READ & SAVE THESE INSTRUCTIONS Questions, problems, missing parts? Before returning the product, please e-mail our customer service by hicfm@outlook.com...
- Page 2 READ AND SAVE THESE INSTRUCTIONS To prevent serious injury or property damage, read and understand owner's manual before operating. SAFETY INFORMATION WARNING 1. Unplug the fan before moving it or performing maintenance. Don't operate the fan when your hands are wet. 2.
-
Page 3: Assembly Instruction
ASSEMBLY INSTRUCTION 1. Mark the desired hole's locations by using wall bracket, and then drill holes. The stop slot of wall bracket downward. Anchor Self-tapping screw Self-tapping screw Concrete Wall Wall Stud Stop Slot Downward 2. Take off the screw and nut from neck pipe and reserve for next process. Screw Neck Pipe Screw... - Page 4 ASSEMBLY INSTRUCTION 3. Insert the L pipe into neck pipe. Align their install holes together. Align two holes together 4. Fastening the neck pipe and L pipe by screw and nut from step 2.
- Page 5 ASSEMBLY INSTRUCTION 5. Install the fan head into wall bracket via its L pipe. L pipe Fasten the handing knob Wall bracket OPERATION INSTRUCTION Adjust the desired speed by this pull chain switch with 3 speeds control. 0 - stop 1 - low 2 - medium 3 - high...
-
Page 6: Care And Maintenance
OPERATION INSTRUCTION Tilt or down the fan head for changing air flow direction and tight the handing knob back. Handing knob CARE AND MAINTENANCE Unplug the appliance before cleaning. Don’t use any water for cleaning metal surfaces. Slightly moisten a cloth and then wipe off the surfaces of the fan. In order to remove dust from the grill, use a vacuum cleaner or remove the front grill by removing the securing screws on the edge of the grill. -
Page 7: Replacement Parts List
REPLACEMENT PARTS LIST Part # Part Description Blade FAN-W20S...
