Fusion
™
3-Drive Mounting System for 2019 Mac Pro
Installation Instructions for Fusion Flex J3i
SATA Drive Compatibility
The Fusion Flex J3i 3-drive mounting system for 2019 Mac Pro supports any
standard 3.5-inch Serial ATA (SATA) hard disk drive, and any standard 2.5-inch
SATA SSD.
You Should Have
The following items should be included in your product package:
• Fusion Flex J3i bracket assembly (assembled), which includes:
– Primary bracket
– 3.5-inch drive mounting screws (x8)
– 2.5-inch SSD mounting plates (x2)
• 2-drive SATA data/power cable assembly
• USB 3.0 to SATA data/power adapter cable
• 2.5-inch SSD mounting screws (x13)
• Installation instructions
The following items are required for installation
• Medium Phillips screwdriver
• Torx T8 screwdriver or key
Computer Compatibility
• Mac Pro 7,1 (2019)
Contacting Customer Service
The Sonnet Web site located at www.sonnettech.com has the most current
support information and technical updates. Before contacting Customer
Service, please check our Web site for the latest updates and online support files,
and check these installation instructions for helpful information.
Email support requests generally receive the fastest responses, and are usually
processed within a 24-hour period during normal business hours, excluding
holidays. When you contact Customer Service, have the following information
available so the customer service staff can better assist you:
• Product name
• Drive model(s)
• Date and place of purchase
• Computer model
If further assistance is needed, please contact us at:
USA, Canada, or Mexico Customers
Please contact Sonnet Customer Service at:
E-mail: support@sonnettech.com
Tel: 1-949-472-2772
(Monday–Friday, 9 a.m.–5 p.m. Pacific Time)
For Customers Outside North America
For support on this product, contact your reseller or local distributor.
©2020 Sonnet Technologies, Inc. All rights reserved. Fusion, Sonnet and the Sonnet logotype are trademarks of Sonnet Technologies, Inc. Mac, the Mac logo, macOS and Mac Pro are
trademarks of Apple Inc., registered in the United States and other countries. Other product names are trademarks of their respective owners. Product specifications subject to change
without notice. QS-FUS-FLEX-J3-E-A-061420
3
Flex J
i
• Add Your Own SATA Drives
®
Visit Our Web Site
For the most current product information and online
support files, visit the Sonnet web site at https://www.
sonnettech.com. Remember to register your product
online at https://registration.sonnettech.com to be
informed of future upgrades and product releases.
Support Note:
at the time of printing. However, changes to the
hardware may have occurred since then. Please check
the Sonnet website for the latest documentation.
1. Go to www.sonnettech.com/support/kb/kb.php
2. Click the Accessories link.
3. Click the Fusion Flex J3i link, and then click the
Manual link.
4. Click the Fusion Flex J3i Installation Instructions
[English] link, and then check the Document Version
information. If the version listed is later than this
document (revision A), click the Download Now
button for the latest version.
This document was up to date
