- Page 1 USER MANUAL Fixed FHD 4x4 HDMI Matrix Switcher with VW, seamless switch WX-SEMX44-AED Version: V24.07...
-
Page 2: Safety Reminder
Safety Reminder To protect the device and operating personnel from electrostatic discharge, you need to check and ensure that the device is grounding well before the device is powered on. Please observe the following when you install, use, maintain this equipment. Make sure the device ground connection. - Page 3 Warnings of FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 4: Table Of Contents
Contents 1. Product Introduction ..........................3 2. Features ..............................3 3. Specification ............................3 4. Connection Diagram ..........................4 5. Packing ..............................4 6. Panel description ........................... 4 Front panel ............................4 7. Matrix Switcher control ......................... 5 7.1 Remote Control ........................5 Channel switching: ........................ -
Page 5: Product Introduction
Product Introduction This is a the SVM-MANAGER series 1080P HDMI Matrix switchers with the seamless switch, Video Wall function, WEB GUI and EDID management, audio embedded and de-ebmedded and the resolution can up to 1080p60Hz with scaling function and all ports are HDCP compliant. With the friendly user control methods: IR remote control, push buttons with background blue light, APP/WEB GUI/TCPIP/RS232/IR remote control, supports the WEB smart EDID management, this matrix switcher can work with the Blu-Ray Players, Set-Top boxes, Home Theater, and game... -
Page 6: Connection Diagram
RJ45 for the TCP/IP control Power Power adapter 24V/3A Consumption Size 440*279*44 (mm) for the 4x4 and 8x8 Other Weight Working temp 0℃~50℃ Storage temp -20℃~ 60℃ Working Humdity 20%-90% 4. Connection Diagram(*here takes the 8x8 as example) Packing(*here takes the 8x8 as example) Name Unit Matrix switcher... -
Page 7: Panel Description
6.Panel description (*here takes the 8x8 as example) (*here takes the 8x8 as example) Front panel A: LCD screen for the switching, EDID, IP etc information display. B: IR light for the IR remote control C: Power indicator D: Inputs buttons E: Output buttons E: Control buttons (*here takes the 8x8 as example) -
Page 8: Matrix Switcher Control
7.Matrix Switcher control This Matrix switcher can support IR remote, WEB GUI browser, TCP/IP/RS232 control, or the front push-buttons control. 7.1 Remote Control Users also can control this matrix switcher with the remote control. Channel switching: Press the input from number “1~8”, first press the input number 1-8), and then press the output number 1-8 to switch Eg. - Page 9 On the input and output buttons, users also can view the active ports by the button color, 2 steps for the switching Function button: Save, Recall, Closed, ToAll Save and Recall: It will take 2 steps to Save or Recall the scenes, select the scene number first, and then click “Save”...
-
Page 10: Video Wall
ToAll: Select the input firstly, and then click the “ToAll” button: 7.2.2 Video Wall: users can setup the VW wall, adjust the bezel, or save/recall the VW scenes, Step1: Configure the VW size by slecet the “X screen size” and “Y screen size” Step2: Slecet the input you want Step3: Slecet the output for the video wall. -
Page 11: Edid Management
7.2.3 EDID Management: Switch: Selecet the output, and then click the input, then will copy the EDID of input to output. Recall: Selecet the EDID in the system, and then select the input, it’s mean copy the EDID in the system to input. -
Page 12: System Setting
Save: Selecet the output, and then slecet the system, then will save the output EDID to system. 7.2.4 System Setting: General/Network setting Serial Settings: User can change the band rate, data bit... - Page 13 Input Audio Settings: User can slecet the Internal HDMI or Extenal 3.5mm audio for the 8 input Output Settings: User can ON or OFF the auto switch, slecet the out format, slecet the resolution and brightness, saturation and contrast. Auto switch: Usre can slecte Auto mode and Last mode or off Auto mode: that means when the input source are disconnected, the matrix will auto switch the input 1 to the screen, if input 1 also have not source connected, the matrix will auto switch input 2 to the screen, matrix will follow the principle from input 1 to input 8 based connect some input...
-
Page 14: Upgrade Settings
Resolution Setting: *Although it has the 4K30 resolution in the list, but recommend to select up to 1080P60 would be the most stable way to use. Rename: User can enter the name and save it for the input, output and sence. 7.3 Upgrade Settings: Connect to the matrix through the network assistant or serial port assistant to send commands: #BOOT... -
Page 15: Application Control
click OK to enter. 7.4 Application control The matrix can support APP control. iOS users can directly search for MCS in the Apple store to download the APP, and Android users can download and install it through the website. 1. TCP/IP/RS232 control: Support RS232, TCP (8080): connect to the control device through the RS232 serial cable Baud rate: 115200 (factory default), N, 8, 1 Use RS232 direct connection...
