Woxcon MUH44E-H2 KIT User Manual

4k 4x4 hdbaset matrix with 3 receivers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MUH44E-H2 KIT
4K 4x4 HDBaseT Matrix with 3 Receivers
All Rights Reserved
Version: MUH44E-H2 KIT_2019V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUH44E-H2 KIT and is the answer not in the manual?

Questions and answers

Related Manuals for Woxcon MUH44E-H2 KIT

Summary of Contents for Woxcon MUH44E-H2 KIT

  • Page 1 User Manual MUH44E-H2 KIT 4K 4x4 HDBaseT Matrix with 3 Receivers All Rights Reserved Version: MUH44E-H2 KIT_2019V1.1...
  • Page 2 4K 4x4 HDBaseT Matrix with 3 Receivers Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
  • Page 3 4K 4x4 HDBaseT Matrix with 3 Receivers SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.

  • Page 4: Table Of Contents

    4K 4x4 HDBaseT Matrix with 3 Receivers Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ....................... 2 2. Specification ........................ 3 2.1 MUH44E-H2 HDBaseT Matrix ................3 2.2 TPUH-BYE20R HDBaseT Receiver ..............4 3.
  • Page 5 4K 4x4 HDBaseT Matrix with 3 Receivers 7.6 Interface Tab ..................... 20 7.7 Network Tab ...................... 21 7.8 GUI Upgrade ....................22 8. RS232 Control ......................23 8.1 RS232 Control Software ................... 23 8.2 RS232 Communication Command ..............25 8.2.1 Device Control ..................25 8.2.2 Source Switching ...................

  • Page 6: Product Introduction

    4K 4x4 HDBaseT Matrix with 3 Receivers 1. Product Introduction Thanks for choosing this 4K 4x4 HDBaseT Matrix with 3 Receivers! It features 4 HDMI inputs, 1 HDMI output with audio breakout and 3 HDBaseT outputs. The de-embedded audio can be output from SPDIF and L/R connector. It supports video resolutions up to 4K@60Hz 4:4:4 and can transmit 4K video to distances up to 131 feet (40 meters) and 1080P video to distances up to 229 feet (70 meters) over a single CATx cable.

  • Page 7: Package List

    4K 4x4 HDBaseT Matrix with 3 Receivers 1.2 Package List 1x MUH44E-H2 4K 4x4 HDBaseT Matrix 2x Mounting Ears with 6 Screws 4x Plastic Cushions 1x IR Remote 4x IR Receivers HDBaseT Matrix 4x IR Emitters 1x RS232 Cable (3-pin to DB9) 1x 5-pin Terminal Block 1x Power Adaptor (24V DC 2.71A) 1x Power Cord...

  • Page 8: Specification

    4K 4x4 HDBaseT Matrix with 3 Receivers 2. Specification 2.1 MUH44E-H2 HDBaseT Matrix Video Video Input (4) HDMI Video Input Connector (4) Type-A female HDMI Video input Video Resolution Up to 4K@60Hz 4:4:4 Video Output (3) HDBaseT, (1) HDMI Video Output Connector (3) RJ45, (1) Type-A Female HDMI, HDMI: Up to 4K@60Hz 4:4:4 Video output Video Resolution...

  • Page 9: Tpuh-Bye20R Hdbaset Receiver

    4K 4x4 HDBaseT Matrix with 3 Receivers 4K@60Hz ≤ 131 feet (40 meters) Bandwidth 18Gbps Operation Temperature -5~ +55℃ Storage Temperature -25 ~ +70℃ Relative Humidity 10%-90% External Power Supply Input: AC 100~240V, 50/60Hz; Output: 24V DC 2.71A Maximum Power Consumption 58watts Dimension (W*H*D) 436.4mm x 44mm x 236.5mm...

  • Page 10: Panel Description

    4K 4x4 HDBaseT Matrix with 3 Receivers 3. Panel Description 3.1 Matrix Front Panel ① FIRMWARE: Micro-USB port for firmware upgrade. ② Power LED: The LED illuminates red when power is applied. ③ Signal Switching Zone: A. INPUT LEDs: A series of four LEDs, one of which illuminates blue to indicate which source is selected.

  • Page 11: Receiver Front And Rear Panel

    4K 4x4 HDBaseT Matrix with 3 Receivers ⑤ OUTPUTS: 1~3-HDBT: Three HDBaseT RJ45 outputs to connect the three HDBaseT receivers. 4-HDMI: One local HDMI port to connect a local display. SPDIF: A digital optical S/PDIF audio output. L/R: A stereo pair of analog RCA audio output jacks. ⑥...

  • Page 12: System Connection

    4K 4x4 HDBaseT Matrix with 3 Receivers 4. System Connection 4.1 Usage Precaution Make sure all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets, and power cords should be insulated and safe.

  • Page 13: Panel Control

    4K 4x4 HDBaseT Matrix with 3 Receivers 5. Panel Control 5.1 Signal Switching Repeatedly press the OUTPUT button on front panel to cycle through the various inputs for the corresponding output. Press and hold PRESET RECALL button 1~3 to save the current switching status to the corresponding preset 1~3.

  • Page 14: Ir Control

    4K 4x4 HDBaseT Matrix with 3 Receivers 6. IR Control 6.1 IR Remote Control Connect IR receiver to the IR EYE port, the matrix can be controlled by the below IR remote. Press the STANDBY (1) button to enter or exit standby mode.

  • Page 15: Ir Pass-Through Control

    4K 4x4 HDBaseT Matrix with 3 Receivers 6.2 IR Pass-through Control 6.2.1 Control Far-end Device locally Connect an IR receiver to IR IN port of the matrix; users can control far-end display via its IR remote from local. In that case, the IR signal is transferred via twisted pair. Only the corresponding IR OUT port can emit control signals to the remote display.
  • Page 16 4K 4x4 HDBaseT Matrix with 3 Receivers HDMI: INPUTS IR IN OUTPUTS CONTROL POWER AUDIO: IR EYE ON DIP RS232: 1 2 3 4 TCP/IP: HDMI 1 HDMI 2 HDMI 3 HDMI 4 IR OUT 1-HDBT 2-HDBT 3-HDBT 4-HDMI SPDIF TCP/IP RS232 EDID...
  • Page 17 4K 4x4 HDBaseT Matrix with 3 Receivers The IR signal can be sent by any three of IR remotes, then it is transferred to HDBaseT receiver, then to IR OUT 1 port and received by the local source device. Switching Operation: Sending command (reference to 8.2.2 Source Switching): Command Description...

  • Page 18: Gui Control

    4K 4x4 HDBaseT Matrix with 3 Receivers 7. GUI Control The matrix can be controlled via TCP/IP. The default IP settings are: IP Address: 192.168.0.178 Subnet Mask: 255.255.255.0 Gateway: 192.168.0.1 Type 192.168.0.178 in the internet browser, it will enter the below log-in webpage: Username: admin Password: admin Type the user name and password, and then click Login to enter the section for video...

  • Page 19: Switching Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.1 Switching Tab Use the 4x4 button grid on the left side to set which inputs are directed to which outputs. For example, clicking the buttons on the Input 1 row and Output 1,2,3,4 column, directs input 1 to all outputs.

  • Page 20: Audio Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.2 Audio Tab Turn on or turn off the analog audio output and digital audio output.

  • Page 21: Configuration Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.3 Configuration Tab 7.3.1 PoC Setting Turn on or off PoC for 1-HDBT, 2-HDBT and 3-HDBT output. 7.3.2 EDID Copy Copy the EDID of the selected output device to one or more input source device.

  • Page 22: Edid Setting

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.3.3 EDID Setting Select the compatible built-in EDID for the selected input source. Upload user-defined EDID by the below steps: 1) Prepare the EDID file (.bin) on the control PC. 2) Select the User-define. 3) Click the box , and then select the EDID file (.bin) according the tooltip.

  • Page 23: Rs232 Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.4 RS232 Tab Baud Rate: Supports 2400, 4800, 9600, 19200, 38400, 57600 or 115200. Command Ending: NULL, CR, LF or CR+LF can be chosen. Command: Type the command in this box to control the third-party device which is connected to the RS232 port of the matrix.

  • Page 24: Access Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.5 Access Tab Modify the login password. Lock or unlock the front panel buttons.

  • Page 25: Interface Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.6 Interface Tab Modify the title bar label. Modify the button labels.

  • Page 26: Network Tab

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.7 Network Tab Static IP or Dynamic Host Configuration Protocol (DHCP). Modify the static IP Address, Subnet Mask, and Gateway.

  • Page 27: Gui Upgrade

    4K 4x4 HDBaseT Matrix with 3 Receivers 7.8 GUI Upgrade Please visit at http://192.168.0.178:100 for GUI online upgrade. Type the username and password (the same as the GUI log-in setting, modified password will be available only after rebooting) to login the configuration interface. After that, click Administration in the source menu to get to Upload Firmware as shown below: Select the desired update file and press Apply, it will start upgrading then.

  • Page 28: Rs232 Control

    4K 4x4 HDBaseT Matrix with 3 Receivers 8. RS232 Control Connect the RS232 port to control device (e.g. PC) with RS232 cable. The matrix can be controlled by sending RS232 commands. 8.1 RS232 Control Software Installation: Copy the control software file to the control PC. Uninstallation: Delete all the control software files in corresponding file path.
  • Page 29 4K 4x4 HDBaseT Matrix with 3 Receivers The main view is shown as below: Parameter configuration area Monitoring area, show the commands and its feedback information. Command sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in command sending area.

  • Page 30: Rs232 Communication Command

    4K 4x4 HDBaseT Matrix with 3 Receivers 8.2 RS232 Communication Command Communication protocol: RS232 Communication Protocol Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Note: In the commands, “[”and “]” are symbols for easy reading and do not need to be typed in actual operation.

  • Page 31: Source Switching

    4K 4x4 HDBaseT Matrix with 3 Receivers Command Description Feedback Example GetGuiIP. Report GUI IP. GUI_IP:192.168.0.178! Example: SetGuiIP:xxx.xxx.xxx.x SetGuiIP:192.168.0.176. Set GUI IP to [xxx.xxx.xxx.xxx]. Feedback: SetGuiIP:192.168.0.176. PHDBT[x]:ON. Turn on PoC for HDBT output [x]. x=1~3. HDBT1 Power ON! PHDBT[x]:OFF. Turn off PoC for HDBT output [x]. x=1~3. HDBT1 Power OFF! 8.2.2 Source Switching Command...

  • Page 32: Audio Control

    4K 4x4 HDBaseT Matrix with 3 Receivers Preset2 Sta: Out1 In 02! PresetSta[x]. Report the preset [x]. x=1~ 6. Out2 In 02! Out3 In 02! Out4 In 02! 8.2.4 Audio Control Command Function Feedback Example Turn on the stereo analog L/R audio IIS Out ON! IISON.
  • Page 33 4K 4x4 HDBaseT Matrix with 3 Receivers Upgrade the EDID data of the input [x]. x=0~4, U. Definition Upgrade the EDID data of all HDMI input. Upgrade the EDID data of HDMI input 1~4. Upgrade the user-define EDID. Note that new EDID can not be automatically EDIDUpgrade[x].
  • Page 34 4K 4x4 HDBaseT Matrix with 3 Receivers Reset factory default EDID to all input All Input EDID Set Default EDIDMInit. ports. 1080P! EDIDSTA00. Report the EDID status of input [xx]. Input 01 EDID From 01 Internal Definition EDID! All input ports Input 02 EDID From 01 Internal EDIDSTA[xx].

  • Page 35: Hdcp Management

    4K 4x4 HDBaseT Matrix with 3 Receivers 8.2.6 HDCP Management HDCP00MAT. The HDCP content of output [xx] follows the HDCP version of display device. Definition OUT 01 HDCP MAT Display! All output ports HDCP[xx]MAT. OUT 02 HDCP MAT Display! HDMI output 1 OUT 03 HDCP MAT Display! HDMI output 2 OUT 04 HDCP MAT Display!

  • Page 36: Third-Party Device Control

    4K 4x4 HDBaseT Matrix with 3 Receivers 8.2.7 Third-party Device Control The matrix supports RS232 pass-through control, the third-party device which is connected to the RS232 port can be controlled by RS232 command, and the command format as shown below: Command Function Command Example...

  • Page 37: Panel Drawing

    4K 4x4 HDBaseT Matrix with 3 Receivers 9. Panel Drawing 436.40 mm MUH44E-H2 HDBaseT Matrix 74.0 mm TPUH-BYE20R HDBaseT Receiver...

  • Page 38: Troubleshooting And Maintenance

    4K 4x4 HDBaseT Matrix with 3 Receivers 10. Troubleshooting and Maintenance Problems Potential Causes Solutions The connecting cables may not Check whether the cables be connected correctly or it are connected correctly and Color losing or no may be broken. in working condition.
  • Page 39 4K 4x4 HDBaseT Matrix with 3 Receivers EDID management Change for another HDMI The HDMI cable is broken at does not work cable which is in good the output end. normally working condition. Switch again. Manage the EDID data There is a blank The display does not support manually to make the screen on the display...

  • Page 40: Customer Service

    4K 4x4 HDBaseT Matrix with 3 Receivers 11. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
