User Manual
MUH44A-H2
4K 4x4 HDMI2.0 Matrix Switcher
All Rights Reserved
Version: MUH44A-H2_2016V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUH44A-H2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Woxcon MUH44A-H2

Summary of Contents for Woxcon MUH44A-H2

  • Page 1 User Manual MUH44A-H2 4K 4x4 HDMI2.0 Matrix Switcher All Rights Reserved Version: MUH44A-H2_2016V1.0...
  • Page 2 4K 4x4 HDMI2.0 Matrix Switcher Preface Read this user manual carefully before using the product. Pictures shown in this manual is for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction only. The functions described in this version are updated till December 11, 2016.
  • Page 3 4K 4x4 HDMI2.0 Matrix Switcher SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. l Unpack the equipment carefully and save the original box and packing material for possible future shipment l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.

  • Page 4: Table Of Contents

    4K 4x4 HDMI2.0 Matrix Switcher Contents 1. Introduction ........................1 1.1 Brief Introduction ....................1 1.2 Features ......................1 1.3 Package List ....................... 1 2. Panel Description ......................2 2.1 Front Panel ......................2 2.2 Rear Panel ......................3 3. System Connection ..................... 4 3.1 Usage Precautions .....................
  • Page 5 4K 4x4 HDMI2.0 Matrix Switcher 7.1 Control Modes ....................17 7.2 TCP/IP Communication Software Control ............18 7.3 Web-based GUI Control ................... 21 7.3.1 Scene Setting ..................22 7.3.2 I/O connection switching ................ 23 7.3.3 EDID Configuration ................25 7.3.4 Audio Out ....................26 7.3.5 Status Setting ..................

  • Page 6: Introduction

    4K 4x4 HDMI2.0 Matrix Switcher 1. Introduction 1.1 Brief Introduction This product is a professional 4K 4x4 HDMI2.0 Matrix Switcher with 4 HDMI inputs, 4 HDMI outputs, and 4 SPDIF audio outputs, which is designed for switching four HDMI2.0 and HDCP2.2 compliant signals. It also provides powerful EDID management to ensure reliable AV distribution and routing.

  • Page 7: Panel Description

    4K 4x4 HDMI2.0 Matrix Switcher 2. Panel Description 2.1 Front Panel INPUTS FIRMWARE OUTPUTS Figure 2- 1 Front Panel Name Description Firmware Micro USB port for updating firmware. ① Illuminates red when power on; Turns green in standby mode; Power Indicator ②...

  • Page 8: Rear Panel

    4K 4x4 HDMI2.0 Matrix Switcher 2.2 Rear Panel OUTPUTS CONTROL INPUTS SPDIF SPDIF SPDIF SPDIF 1 2 3 4 ON DIP 1 2 3 4 EDID R S232 IR IN TCP/IP DC 24V Figure 2- 2 Rear Panel Name Description HDMI input ports, 4 in total, connect with HDMI INPUTS ①...

  • Page 9: System Connection

    4K 4x4 HDMI2.0 Matrix Switcher 3. System Connection 3.1 Usage Precautions System should be installed in a clean environment with prop temperature and humidity. All of the power switches, plugs, sockets and power cords should be insulated. All devices should be connected before power on. 3.2 Connection Diagram HDMI: Audio:...

  • Page 10: System Applications

    4K 4x4 HDMI2.0 Matrix Switcher Switcher to enable TCP/IP control; Step7. Plug a 24VDC power adapter to the DC 24V power port. & When connecting to HDMI2.0 sources, make sure the HDMI cable is compliant with HDMI2.0 to ensure reliable transmission; Connect amplifiers that are capable to decode HDMI audio to the SPDIF ports, or there will be no output on the amplifiers.

  • Page 11: Panel Button Control

    4K 4x4 HDMI2.0 Matrix Switcher 4. Panel Button Control 4.1 I/O connection switching The front panel features four input selection buttons and four output selection buttons for switching I/O connection. To convert one input to an output: Example: Input 1 to Output 3 →...

  • Page 12: I/O Connection Inquiry

    4K 4x4 HDMI2.0 Matrix Switcher Enable Software EDID management 1111 mode: RS232 control or Web-based GUI control. 4.3 I/O connection Inquiry Press OUTPUTS button 1, 2, 3 or 4 to inquiry its corresponding input, and then the indicator of the input button will turn green.

  • Page 13: Ir Control

    4K 4x4 HDMI2.0 Matrix Switcher 5. IR Control The Matrix Switcher features one built-in IR receiver to receive IR signal from IR remote to enable IR control. If the external IR receiver or other IR control device need to be used, the IR IN port on rear panel can be connected.

  • Page 14: Rs232 Control

    4K 4x4 HDMI2.0 Matrix Switcher 6. RS232 Control 6.1 Installation/uninstallation of RS232 Control Software Installation Copy the control software file to the computer connected with the Matrix Switcher. Uninstallation Delete all the control software files in corresponding file path. 6.2 Basic Settings Firstly, connect the Matrix Switcher with necessary input devices and output devices.
  • Page 15 4K 4x4 HDMI2.0 Matrix Switcher CommWatch Figure 6- 2 Control Interface of...

  • Page 16: Rs232 Communication Commands

    4K 4x4 HDMI2.0 Matrix Switcher Set the parameters (baud rate, data bit, stop bit and parity bit) correctly to ensure reliable RS232 control. Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none 6.3 RS232 Communication Commands & “[“, “]”...

  • Page 17: Lock/Unlock Commands

    4K 4x4 HDMI2.0 Matrix Switcher Query the IP address. IP:XXX.XXX.X.XXX %9964. Reset to factory default. Factory Default %0911. 6.3.2 Lock/unlock Commands Command Function Feedback Example Lock the front panel buttons. System Locked! /%Lock; Unlock the front panel buttons. System Unlock! /%Unlock;...

  • Page 18: Scene Commands

    4K 4x4 HDMI2.0 Matrix Switcher Query the connection status of the 01 02 03 04 %9971. inputs. Connect Y Y Y Y Query the connection status of the Out 01 02 03 04 %9972. outputs. Connect Y Y Y Y Out 01 02 03 04 Query the I/O connection status.

  • Page 19: Edid Configuration

    4K 4x4 HDMI2.0 Matrix Switcher 6.3.6 EDID Configuration The DIP switcher status should be set as 1111 to enable Software EDID management mode: RS232 control or Web-based GUI control. Command Function Feedback Example Input port [y] learns the EDID from output port [x].
  • Page 20 4K 4x4 HDMI2.0 Matrix Switcher Get the EDID data of input [x], GetInPortEDID [x]=1~4 EDID RS232 GUI Get the DIP switcher status %9979. CONTROL 1111...

  • Page 21: Enable/Disable Digital Audio

    4K 4x4 HDMI2.0 Matrix Switcher 6.3.7 Enable/disable Digital Audio Feedback Command Function Example Enable SPDIF audio output port x. DigitAudio ON with DigitAudioON[ X=1, 2, 3, 4, enable the port x. [x]/ ALL Outputs X=5, enable all ports. Disable SPDIF audio output port x. DigitAudio OFF with DigitAudioOFF X=1, 2, 3, 4, disable the port x.

  • Page 22: Tcp/Ip Control

    4K 4x4 HDMI2.0 Matrix Switcher 7. TCP/IP Control 7.1 Control Modes TCP/IP default settings: IP is 192.168.0.178, Gateway is 192.168.0.1, and Serial Port is 4001. IP can be changed as you need, Serial Port cannot be changed. Controlled by single PC Connect a computer to the TCP/IP port of the Matrix Switcher, and set its network segment to the same as the default IP of the Matrix Switcher (192.168.0.178).

  • Page 23: Tcp/Ip Communication Software Control

    4K 4x4 HDMI2.0 Matrix Switcher Figure 7- 2 Connect to LAN Step1. Connect the TCP/IP port of the Matrix Switcher to Ethernet port of PC with twisted pair. Step2. Set the PC’s network segment to the same as the Matrix Switcher. Do please remember the PC’s original network segment.
  • Page 24 4K 4x4 HDMI2.0 Matrix Switcher Figure 7- 3 Connect to TCPUDP 2) Enter commands in designed area to control the Matrix Switcher, see as below:...
  • Page 25 4K 4x4 HDMI2.0 Matrix Switcher Enter your command here. Commands are the same with RS232 commands listed in 6.3 RS232 Communication Commands Here you will receive the feedback after a command is sent. Figure 7- 4 Control interface of TCPUDP...

  • Page 26: Web-Based Gui Control

    4K 4x4 HDMI2.0 Matrix Switcher 7.3 Web-based GUI Control The Matrix Switcher provides with built-in GUI for convenient TCP/IP control. GUI allows users to interact with the Matrix Switcher through graphical icons and visual indicators. Access GUI interface through any one of the following methods: Access through web browser: Type the default IP 192.168.0.178 in the browser at first login.

  • Page 27: Scene Setting

    4K 4x4 HDMI2.0 Matrix Switcher Type 192.168.0.178 in your browser, it will enter the log-in interface shown as below: Figure 7- 5 Login GUI This system divides into administrator and user mode. There are 2 selectable usernames – admin (default password: admin) and user (default password: user).

  • Page 28: I/O Connection Switching

    4K 4x4 HDMI2.0 Matrix Switcher Figure 7- 6 Scene Menu All ten scenes are shown in above interface. Select a scene and then click “Load” can invoke the selected scene. Click “Cancel” to cancel the current operation. 7.3.2 I/O connection switching Click to enter the following interface, it provide intuitive I/O connection switching.
  • Page 29 4K 4x4 HDMI2.0 Matrix Switcher Figure 7- 7 Control Menu The button matrix displays every possible connection between every input and output; users can carry on the connections by clicking corresponding button. Buttons 1~4 at the right-bottom corner provides quick saving and recall for overall connection status.

  • Page 30: Edid Configuration

    4K 4x4 HDMI2.0 Matrix Switcher 7.3.3 EDID Configuration Click setting button to enter the below interface: User can select EDID in accordance with actual needs. Figure 7- 8 Embedded EDID Select “EDID Copy” to enter the below interface: Figure 7- 9 Copy EDID...

  • Page 31: Audio Out

    4K 4x4 HDMI2.0 Matrix Switcher The EDID of INPUT device can be gained from OUTPUT devices. Step1: Select one OUTPUT device that you want to copy its EDID. Step2: Select one or more input devices that need to gain EDID. When select To All inputs, all input devices will copy the EDID from output device.

  • Page 32: Status Setting

    4K 4x4 HDMI2.0 Matrix Switcher 7.3.5 Status Setting Product Name& Model: Click “Status” to enter the following interface to modify the product name and its model, and then they will be display in LCD screen. Figure 7- 11 Status- LCD Button label: Select “Button”...

  • Page 33: Network Configuration

    4K 4x4 HDMI2.0 Matrix Switcher Scene name: Select “Scene” to enter the following interface to modify the name of scenes. Figure 7- 13 Status-Scene 7.3.6 Network Configuration Click “Network” to enter the below interface to inquire and configure network settings including MAC address, IP address, subnet mask, and Gateway.

  • Page 34: Password Modification

    4K 4x4 HDMI2.0 Matrix Switcher 7.3.7 Password Modification Click “Password” to enter the below interface to inquire and modify the admin or user password. Figure 7- 15 Password In the above interface, turn on the Front Panel to lock all buttons of machine, they cannot be operated.

  • Page 35: Gui Update

    4K 4x4 HDMI2.0 Matrix Switcher Figure 7- 16 TCP/IP Configuration 7.5 GUI Update GUI for the Matrix Switcher supports online update in http://192.168.0.178:100. Type the username and password (the same as the GUI log-in settings, modified password will be available only after rebooting) to log in the configuration interface. After that, click Administration at the source menu to get to Upload Program as shown below: Figure 7- 17 GUI Update...

  • Page 36: Firmware Upgrade Through Usb Port

    4K 4x4 HDMI2.0 Matrix Switcher 8. Firmware Upgrade through USB port The matrix switcher boasts a USB port for online firmware upgrade on the front panel. Follow these steps to upgrade firmware: Step1. Copy the upgrade software and the latest upgrade file (.bin) to PC. Step2.

  • Page 37: Specification

    4K 4x4 HDMI2.0 Matrix Switcher 9. Specification Input Signal 4 HDMI Input Connector Female Type-A HDMI Output Signal 4 HDMI; 4 SPDIF audio Output Connector Female Type-A HDMI; COAX connector Control Signal 1 IR IN; 1 TCP/IP; 1 RS232 3.5mm mini jack; female RJ45; 3-pin pluggable terminal Control Connector block Video Signal...

  • Page 38: Panel Drawing

    4K 4x4 HDMI2.0 Matrix Switcher 10. Panel Drawing 23 mm INPUTS FIRMWARE OUTPUTS 437 mm INPUTS OUTPUTS CONTROL SPDIF SPDIF SPDIF SPDIF 1 2 3 4 ON DIP 1 2 3 4 EDID R S232 IR IN TCP/IP DC 24V...

  • Page 39: Troubleshooting & Maintenance

    4K 4x4 HDMI2.0 Matrix Switcher 11. Troubleshooting & Maintenance Problems Potential Causes Solutions The connecting cables Check whether the cables may not be connected are connected correctly and correctly or it may be Color losing or no video in working condition. broken.
  • Page 40 4K 4x4 HDMI2.0 Matrix Switcher Power Indicator remains Fail or loose power Check whether the cables off when powered on connection are connected correctly. Change for another HDMI EDID management The HDMI cable is broken cable which is in good does not work normally at the output end.

  • Page 41: Customer Service

    4K 4x4 HDMI2.0 Matrix Switcher 12. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed 3 (three) years. 2) Scope These terms and conditions of Customer Service apply to the customer service provided for the products or any other items sold by authorized distributor only.
  • Page 42 4K 4x4 HDMI2.0 Matrix Switcher...
