ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION
BOK EXTENDABLE DINING TABLE
CODE
DESCRIPTION
51487
OAK BOK EXTENDABLE DINING TABLE 120-180/90/76
OAK BOK EXTENDABLE DINING TABLE 140-220/90/76
51502
51503
OAK BOK EXTENDABLE DINING TABLE 160-240/90/76
51504
OAK BOK EXTENDABLE DINING TABLE 180-280/100/76
OAK BOK EXTENDABLE DINING TABLE 200-300/100/76
51494
51542
OAK BOK BLACK EXTENDABLE DINING TABLE 140-220/90/76
51543
OAK BOK BLACK EXTENDABLE DINING TABLE 160-240/90/76
OAK BOK BLACK EXTENDABLE DINING TABLE 180-280/100/76
51544
51541
OAK BOK BLACK EXTENDABLE DINING TABLE 200-300/100/76
51552
OAK BOK BROWN EXTENDABLE DINING TABLE 140-220/90/76
OAK BOK BROWN EXTENDABLE DINING TABLE 160-240/90/76
51553
51554
OAK BOK BROWN EXTENDABLE DINING TABLE 180-280/100/76
51540
OAK BOK BROWN EXTENDABLE DINING TABLE 200-300/100/76
1 / 6
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ethnicraft BOK 51487
Summary of Contents for Ethnicraft BOK 51487
- Page 1 1 / 6 ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION BOK EXTENDABLE DINING TABLE CODE DESCRIPTION 51487 OAK BOK EXTENDABLE DINING TABLE 120-180/90/76 OAK BOK EXTENDABLE DINING TABLE 140-220/90/76 51502 51503 OAK BOK EXTENDABLE DINING TABLE 160-240/90/76 51504 OAK BOK EXTENDABLE DINING TABLE 180-280/100/76 OAK BOK EXTENDABLE DINING TABLE 200-300/100/76 51494 51542...
-
Page 2: Code Description
TO AVOID DAMAGE. CHECK PACKAGE CONTENTS TO ASSURE ALL THE NECESSARY HARDWARE AND PARTS ARE RECEIVED UNDAMAGED. DO NOT USE DAMAGE OR DEFECTIVE PARTS/HARDWARE. CONTACT ETHNICRAFT FOR ANY MISSING PART AND/OR HARDWARE. READ ASSEMBLY INSTRUCTIONS BEFORE INSTALLATION, CAREFULLY FOLLOWING THE DIRECTIONS GIVEN. - Page 3 3 / 6 BOK EXTENDABLE DINING TABLE LE TRI ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION HARDWARE ENCLOSED H0689 H0849 H2069 H0383 SCREW WASHER SPAX SCREW SPAX SCREW M6x40 M6x80 M6x120 (6pcs) (8pcs) (4pcs) (4pcs) TOOLS (Included in package) H0745 H0893 ALLEN KEY TORX KEY (1pc)
- Page 4 4 / 6 BOK EXTENDABLE DINING TABLE LE TRI ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION INSTALLING LEGS TO TABLE TOP H0383 H0383 H0689 H0689 IMPORTANT : - USE WASHER M8 - USE SPAX SCREW M6x80 FOR THE FIXED LEGS - TIGHTEN FULLY INSTALLING LEG SET TO TABLE TOP H2069 H2069...
- Page 5 5 / 6 BOK EXTENDABLE DINING TABLE LE TRI ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION REMOVE WOODEN PACKAGING BRACES Position of wooden braces REMOVE ALL FOUR WOODEN BRACES BEFORE EXTENDING THE TABLE INSTALLING CENTRAL SCREWS TO INSIDE OF LEG SET Position of screws H2069 H2069...
- Page 6 6 / 6 BOK EXTENDABLE DINING TABLE LE TRI ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION EXTENDING NOTE : AFTER EXTENDING, LOCK IN PLACE ON UNDERSIDE OF TABLE TOP DISMANTLING NOTE : BEFORE DISMANTLING, UNLOCK ON UNDERSIDE OF TABLE...
