Features
• Control Distance: 30m
• 16 Millions of colors to choose
• Brightness and color temperature adjustable
• Switching 3 output mode via one button (RGB /
RGBW / RGB+CCT)
16 Millions of
colors to choose
Color temperature
adjustable
Dim brightness /
saturation
2.4G RF wireless
transmission technology
Parameters
Remote
Operating Voltage:
3V(AAA*2PCS)
Standby power:
< 20 A
Transmit power：
6dBm
Control Signal:
2.4G Hz
Modulation Method:
GFSK
Controller
Input Voltage:
DC12-24V
Output Current:
6A/ Channel
Total Output
Max 12A
Output Power:
144-288W
Output Type:
Constant Voltage
3 in 1 LED Controller Kits (2.4GHz)
Model No.: FUT037SA+
Remote control
Control distance 30m
Smartphone App control
(2.4GHz gateway is needed)
Support third party voice control
(2.4GHz gateway is needed)
Control Signal:
Control Distance:
IP Rate:
Working Temp.:
EMC Standard (EMC):
Safety Standard（LVD）:
Radio Equipment（RED）:
Certi cation:
Warranty:
2.4GHz RF
30M
IP20
-10~40°C
ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-3 V2.1.1
EN 61347-1：2015+A1: 2021
EN 61347-2-11: 2001+A1:2019
ETSI EN 300 440 V2.2.1
CE, EMC, LVD, RED
5 Years
Advertisement
Related Manuals for Miboxer FUT037SA+
Summary of Contents for Miboxer FUT037SA+
- Page 1 3 in 1 LED Controller Kits (2.4GHz) Model No.: FUT037SA+ Features • Control Distance: 30m • 16 Millions of colors to choose • Brightness and color temperature adjustable • Switching 3 output mode via one button (RGB / RGBW / RGB+CCT) 16 Millions of Remote control colors to choose...
- Page 2 Size Φ70mm 24mm 74.5mm Function Turn on lights / Dynamic mode / Link / Unlink RGB / Color temperature Brightness / Turn off lights Saturation Touch ring: brightness, saturation, color temperature, RGB use together. (It turns to adjust brightness by default if remote is not operated for 3 seconds) Remote Instruction Adjust RGB Short press...
-
Page 3: Connection Diagram
Install The Battery For Remote Note: 2*AAA Battery need to buy seperately 1. Open battery cover 2. Install battery correctly and behind remote. close battery cover. Connection Diagram Input: DC12V ~ 24V V- V+ RGB Mode V- V+ RGBW Mode V- V+ RGB+CCT Mode... - Page 4 Linking Code / Unlinking Code Instructions Attention: No need to match code since its already matched code in factory setting Linking Code Instructions Power Controller Link/Unlink Power Controller button Switch off light, after Short press " ON " button Lights blink 3 times 10 seconds then 3 times within 3 seconds slowly means linking...
- Page 5 Set up output mode Set up correct output mode based on the feature of lights Setting method: Press "SET" button continuously to switch output mode (attention: it will log out without operation within 3 seconds) Output mode sheet ( confirm output mode based on color of indicator) Indicator color Red Light Green Light...
- Page 6 Dynamic mode table 2 (need to switch manually) Number Dynamic Mode Brightness / Saturation / Speed Seven colors gradual change White light Gradual change RGB gradual change Seven colors jump to change Jump to change randomly Adjustable Red light gradual change +Flash 3 times Green light gradual change +Flash 3 times...
- Page 7 Auto transmitting & Synchronization (only for remote control) Remote signal auto transmitting One light can transmit the signals from the remote control to another light within 30m, as long as there is a light within 30m, the remote control distance can be limitless.
