2.4GHz RGBW LED Strip Controller Kit
Features
Product adopt the widely used 2.4GHz wireless
technology with the features of low power
consumption, long signal transmitting and strong
anti-interference, etc. Widely used on the
controlling of hotel lighting and home lighting.
16 Millions of
colors to choose
Dim brightness /
Saturation / White mode
Parameters
Remote
Operating Voltage:
3V(AAA*2PCS)
Standby power:
< 20 A
Transmit power：
6dBm
Control Signal:
2.4G Hz
Size:
100*52*20mm
Controller
Input Voltage:
DC12-24V
Output Current:
Max 6A/ Channel
Total Output
Max 10A
Output Power:
120-240W
Output Type:
Constant Voltage
Model No.: FUT028
Remote control
Control distance 30m
2.4G RF wireless
transmission technology
Control Signal:
Control Distance:
Size:
IP Rate:
Working Temp.:
EMC Standard (EMC):
Safety Standard （ LVD） :
Radio Equipment （RED） :
Certi cation:
Warranty:
Model No.: FUT028
2.4GHz RF
30M
85*45*23mm
IP20
-10~40°C
ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-3 V2.1.1
EN 61347-2-11 ： 2001+A1: 2019
EN 61347-1: 2015+A1:2018
ETSI EN 300 440 V2.2.1
CE, EMC, LVD, RED
5 Years
