Jiajia JT5006 Owner's Manual

Children's toy motorcycle battery powered ride-on
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Children's Toy Motorcycle
BATTERY POWERED RIDE-ON
Owner's Manual
with Assembly Instructions
Styles and colo(u)rs may vary.
Made in China.
The owner's manual contains important safety information as well as assembly, use and
maintenance instructions.
The Ride-on Car must be assembled by an adult who has read and understands the
instructions in this manual.
Keep the package away from children and dispose of properly before use.
Keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JT5006 and is the answer not in the manual?

Questions and answers

Related Manuals for Jiajia JT5006

Summary of Contents for Jiajia JT5006

  • Page 1 Children’s Toy Motorcycle BATTERY POWERED RIDE-ON Owner’s Manual with Assembly Instructions Styles and colo(u)rs may vary. Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual.

  • Page 2: Specifications

    Please follow the recommendations in this manual, they are designed to improve the safety and operation of your ride-on car and it’s rider. Manufacturer: ZHEJIANG JIAJIA RIDE-ON CO., LTD Address: XINCANG INDUSTRIAL ZONE PINGHU CITY, ZHEJIANG PROVINCE, CHINA US IMPORTER: Company: JUSTALENT INTERNATIONAL INC.

  • Page 3: User Notice

    User Notice │ 2 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED. • Always remove protective material and poly bags and dispose before assembly.

  • Page 4: Parts Diagram

    Parts Diagram │ 3...

  • Page 5: Parts List

    Parts List │ 4 PART REMARKS PART NAME Q’ty (pcs) Vehicle body Seat Foot pedal Left and right Ø4x12 truss head screw Placed in the assembly package Motor hood Shock bolt Placed on the rear shock Shock washer Placed on the rear shock Shock sleeve nut Placed on the rear shock Ø10 lock nut...
  • Page 6 Attach the Foot Pedal & Side Wheel │ 5 Bottom View Bottom View Turn the vehicle body upside down. 1. Fit the foot pedal to the iron tube of the body. If the foot pedal does not seem to fit, change the other one and try again! 2.
  • Page 7 Attach the Rear Wheel Assembly │ 6 Rear View Shock Shock Shock Shock Shock Shock sleeve nut sleeve nut washer washer bolt bolt Ø10 Lock nut Ø10 Lock nut Side View x2 x2 Ø10 washer Ø10 washer Tools required: Ø10 spanner Ø10 Lock nut Ø10 Lock nut Middle axle...
  • Page 8 Attach the Motor Hoods │ 7 Rear View 1. Plug the connector on the motor into the connector from the vehicle body on each side. 2. Insert the tabs on the motor hood into the holes in the rear tube cover. R to R, L to L. Repeat for the other motor hood.
  • Page 9 Attach the Front Wheel Assembly & Faceagurd │ 8 Front Bottom View Ø8 spanner Ø8 spanner Top View 1-2. Remove thte M8x170 bolt and Ø8 lock nut from the front fork. Fit front fork to the vehicle body. Insert the M8x170 bolt through into the hole at the top of the front fork, the holes in the vehicle body, and out through the hole at the bottom of the front fork.

  • Page 10: Attach The Handle Bar

    Attach the Handle Bar │ 9 1. Remove M6x40 socket head screws*4, clamp M6 hex wrench M6 hex wrench covers*2, handle bar clamps*4 from the front fork with a M6 hex wrench. 2. Fit two handle bar clamps (Arch side down) to the M6x40 socket M6x40 socket head screw...

  • Page 11: Connect The Power Supply

    Connect the Power Supply │ 10 1. Use the cable tie to tie the plugged connectors to the right side tube of the front fork. Then cut off the excess part of the cable tie with scissors. 2. Plug the vehicle connector into the power connector on the battery.
  • Page 12 Use Your Ride-on │ 11 1. Power button: Turns the product on and off. 2. Throttle grip: ● Twist the throttle grip, the product moves forward. ● Release the throttle grip, slow down the product until it stops. 3. Volume knob: Turn the audio player on and off, +/- the volume. 4.

  • Page 13: Battery Disposal

    Charging │ 12 WARNING! • ONLY an adult is allowed charge and recharge the battery! • This product with Charging Protection: when charging, all functions will be cut off. • The POWER SWITCH must be turned in OFF position when charging. •...
  • Page 14 Charging │ 13 Charging Way II A: Use a screwdriver to loosen the screw on the top of the seat and remove the seat. B: Unplug the red connectors from each other. C. Loosen the four screws around the battery box with a screwdriver and lift the battery box up.

  • Page 15: Troubleshooting Guide

    Troubleshooting Guide │ 14 Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other. If wires are loose around the motor are loose contact your distributor please.
  • Page 16 Maintaining │ 15 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge, cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.
