Jiajia JJ298 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
JJ298 Strandgutsammler
Elektrokinderauto
Mit Fernbedienung
Arten und Farben können variieren.
Produziert in China
Die Bedienungsanleitung enthält wichtige Sicherheitsinfor-
mationen, sowie Montage, Anwendung und Wartungsanwei-
sungen. Die Montage des Fahrzeugs muss von einem Er-
wachsenen übernommen werden. Bewahren Sie die Verpa-
Bedienungs- &
Montageanleitung

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JJ298 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jiajia JJ298

Summary of Contents for Jiajia JJ298

  • Page 1 JJ298 Strandgutsammler Elektrokinderauto Mit Fernbedienung Bedienungs- & Montageanleitung Arten und Farben können variieren. Produziert in China Die Bedienungsanleitung enthält wichtige Sicherheitsinfor- mationen, sowie Montage, Anwendung und Wartungsanwei- sungen. Die Montage des Fahrzeugs muss von einem Er- wachsenen übernommen werden. Bewahren Sie die Verpa-...
  • Page 2 MINI Beachcomber Children Electric Ride On manufactured by Zhejiang Jiajia Ride-On Co., Ltd. (Add: Xincang Industrial Zone, Pinghu City, Zhejiang Province, P.R.China). The MINI logo and the MINI word mark are trademarks of BMW AG and are used under license.

  • Page 3: Parts List

    Parts List │ 2 Q’ty (pcs) PART REMARKS PART NAME Gear box 1pc labeled “L”, and 1pc labeld “R” Driving wheel Ø12 washer Motorhood Front wheel Bushing Ø10 locknut Tool box Vehicle body Steering column Front axle Rear axle Seat Placed on the steering wheel Steering wheel M5x35 machines screw...

  • Page 4: Parts Diagram

    Parts Diagram │ 3 NOTE: Some parts shown are assembled on both sides of vehicle...

  • Page 5: Before You Begin Assembly

    Before You Begin Assembly │ 4 WARNING! FOR THE SAFETY OF YOUR CHILD, PLEASE READ ALL WARNINGS AND ASSEMBLY/USE INSTRUCTIONS. KEEP THIS GUIDE FOR FUTURE REFERENCE. • ADULT ASSEMBLY REQUIRED. The product contains small parts, which are for adult assembly only. Keep children away when assembling. •...
  • Page 6 Attach the Front Axle │ 5 1. Fit the front axle to the vehicle body. 2. Insert four Ø4x12 screws and tighten with a screwdriver. 3. Repeat for the other side.
  • Page 7 Attach the Rear Axle │ 6 Remove all the parts from the rear axle. 1. Insert the rear alxe into the hole in the vehicle body.

  • Page 8: Attach The Rear Wheels

    Attach the Rear Wheels │ 7 Driving wheels are more bigger than front wheels Rear axle 1. Slide the gear box onto the rear axle (Left Side). “R” labeled gear box should be fit to the “R” side of vehicle body; “L” labeled gear box should be fit to “L” side of vehicle body. 2.

  • Page 9: Attach The Front Wheels

    Attach the Front Wheels │ 8 Front axle Tools required: Spanner Remove all the parts from the front axle. 1. Slide a Ø10 washer onto the front axle. 2. Slide the bushing (ring end first) onto the front axle. 3. Slide the normal wheel (with wheel hubcap) onto the rear axle. and keep the normal wheel match with the bushing.
  • Page 10 Attach the Steering Column │ 9 Hole in the front axle linkage Steering Gear Box Turn the vehicle body on its side. Remove the M5x22 machine screw and Ø5 Turn the vehicle body on its side. from the R/C driver with a screwdriver. 1.

  • Page 11: Attach The Steering Wheel

    Attach the Steering Wheel │ 10 Follow the battery information on page 4. Add the Batteries (NON PROVIDED) of Steering Wheel 1. With a screwdriver remove the screw on the battery cover located in the center of the steering wheel. 2.

  • Page 12: Attach The Windshield

    Attach the Windshield │ 11 1. Fit the windshield assembly to the vehicle body. 2. Tighten two Ø4x12 screws through the windshield and into the vehicle body with a scewdriver.

  • Page 13: Connect The Power Supply

    Connect the Power Supply │ 12 Fuse box Vehicle connector Battery Motor connector 1. Plug the Vehicle Connector into the Motor Connector on body as shown above. Repeat for the other side. 2. Plug the Red fuse connector into the terminal on battery.
  • Page 14 Attach the Motor Hood │ 13 1. Fit the motor hood on the motor. 2. Tighten four Ø4x12 screws to secure it. Repeat the above step for the other Motor hood.

  • Page 15: Attach The Seat

    Attach the Seat │ 14 Tabs 1. Fit the tabs at back of the seat to the holes in the vehicle body. 2. Tighten two M5x16 machine screws with a screwdriver.
  • Page 16 Attach the Sport Bar │ 15 1. Fit the rear window to the sport bar. 2. Insert the two Ø4x12 screws through the rear window and into the the sport bar. tighten them with a screwdriver. 3. Insert the tabs on the rear windows into the slots in the vehicle, push until you hear it “click”...
  • Page 17 Attach the Toolbox │ 16 Fit the tool box to the rear end of the vehicle body.

  • Page 18: Rules For Safe Riding

    Saftely │ 17 WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
  • Page 19 Use Your Ride-on │ 18 IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gears and motor. 1. Power Switch: Turns the vehicle on and off. 2. Shift Lever: Changes the direction that vehicle moves from forward to reverse. ●...

  • Page 20: Operation

    Use the Remote Controller │ 19 WARNING: ADULT OPERATING REQUIRED! LEFT JOYSTICK INDICATOR LIGHT RIGHT JOYSTICK ON-OFF SWITCH ASSEMBLY 1. Insert the antenna into the controller by tweak the antenna clock- wisely; 2. Lift the battery compartment door on the back of the controller and insert two AA(LR6) batteries.
  • Page 21 Charging │ 20 Charging │ 19 ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion. - Do not use the battery or charger for any other product.
  • Page 22 Charging │ 20 Charging │ 21 1. Plug the charger port into the input socket. (the socket is below the seat) 2. Plug the charger plug into a wall outlet. The battery will begin charging. WARNING! This product with Charging Protection: when charging, all functions will be cut off! Only an adult can charge and recharge the battery!

  • Page 23: Battery Replacement And Disposal

    Battery Replacement & Fuse │ 21 Battery Replacement & Fuse │ 22 The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for five Minutes and then turned ON again.

  • Page 24: Troubleshooting Guide

    Troubleshooting Guide │ 23 Troubleshooting Guide │ 22 Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other.
  • Page 25 Maintaining Maintaining │ 23 │ 24 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge,cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.
  • Page 26 Our products are suitable for ASTM F963; GB6675; EN71 and EN62115 standard.
