Installation Instructions
0 to 50% Motorized Outside Air
Damper
Precedent™ Packaged Rooftop Units
3 to 25 Tons
Model Numbers:
FIADMPR101*
FIADMPR102*
FIADMPR103*
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
September 2024
Used With:
Precedent A cabinet (Digit 39 = A)
Precedent B and C cabinet (Digit 39 = B, C)
Precedent D cabinet (Digit 39 = D)
ACC-SVN231C-EN
SAFETY WARNING
Advertisement
Related Manuals for Trane Precedent FIADMPR101
Summary of Contents for Trane Precedent FIADMPR101
- Page 1 Installation Instructions 0 to 50% Motorized Outside Air Damper Precedent™ Packaged Rooftop Units 3 to 25 Tons Model Numbers: Used With: FIADMPR101* Precedent A cabinet (Digit 39 = A) FIADMPR102* Precedent B and C cabinet (Digit 39 = B, C) FIADMPR103* Precedent D cabinet (Digit 39 = D) SAFETY WARNING...
-
Page 2: Warnings, Cautions, And Notices
When working with or around hazardous chemicals, these compounds have the same potential impact to the ALWAYS refer to the appropriate SDS and OSHA/GHS environment. Trane advocates the responsible handling of all (Global Harmonized System of Classification and refrigerants. Labeling of Chemicals) guidelines for information on... -
Page 3: Revision History
Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change. -
Page 4: Table Of Contents
Table of Contents General Information ..... . . 5 Inspection ......5 Parts List . -
Page 5: General Information
General Information Inspection 1. Unpack all components of the kit. 2. Check carefully for shipping damage. If any damage is found, report it immediately, and file a claim against the transportation company. Verify required options board (FIAOPTN002*) is installed. Parts List Table 1. -
Page 6: Installation - Fiadmpr101*/102
Installation – FIADMPR101*/102* Assembling End Panel Carefully review installation instructions for field-installed motorized damper. Figure • FIADMPR101* for A cabinet (Digit 39 = A) 1. Remove unit end damper panel (D), retain the screws • FIADMPR102* for B and C cabinet (Digit 39 = B, C) removed from the top and the bottom of panel for later use. -
Page 7: Factory Installed Damper Setup
Installation – FIADMPR101*/102* Factory Installed Damper Setup Figure 3. Installation of damper assembly This section covers setup of factory installed motorized damper in the rooftop unit. Figure Figure 5, and Figure 1. Remove filter access panel. 2. Remove the screw that holds bottom block-off (A) in place and remove bottom block-off (A), from its shipping location. -
Page 8: Installation - Fiadmpr103
Installation – FIADMPR103* Carefully review installation instructions for 3. Attach block-off (B) to unit by using four screws. FIADMPR103* - D cabinet (Digit 39 = D). Figure 9. Install block-off Field Installed Damper 1. Uncrate the damper and locate all parts shown in Figure Figure 7. -
Page 9: Factory Installed Damper (Field Setup)
Installation – FIADMPR103* Figure 11. Reinstall end panel Figure 12. Remove lower screws Factory Installed Damper (Field Setup) Blockoff Angle Downflow Configuration Remove screws and lay blockoff angle aside. Do not discard. To position damper for downflow operation, complete the 3. - Page 10 Installation – FIADMPR103* 7. Install the block-off angle underneath the economizer. The block-off angle is designed to close the opening created, between the economizer and the base, when the economizer assembly is in its operating position. a. Holding the block-off angle with the holes at the bottom and the bottom angle outward, tilt the top forward and insert it into the opening between the economizer and the unit base.
-
Page 11: Wiring - Fiadmpr101*/102*/103
Wiring – FIADMPR101*/102*/103* 1. Using the supplied harness connect PPF87 to the actuator connector. 2. Route harness to fresh air options module located in the return section and connect to blue connector to P11 and black connector to P8. See Figure 15 Figure 3. - Page 12 Wiring – FIADMPR101*/102*/103* Figure 17. Fresh air options module LEGEND REF DES DESCRIPTION LINE NO SWITCH - CLOGGED FILTER ACTUATOR - ECONOMIZER TO LINE 135 MODULE - FRESH AIR OPTIONS OPTIONAL RETURN AIR SMOKE DETECTOR SHEET 3 SENSOR - OUTDOOR AIR HUMIDITY UC-P4 PPM88 PPF88...
-
Page 13: Minimum Position Setting - Fiadmpr101*/102
Minimum Position Setting – FIADMPR101*/102*/103* To adjust the minimum position setting and check out the economizer, the power must be connected. 1. Close the unit disconnect and place the zone sensor fan selector in the fan ON position and the heat/cool selector in the OFF position. - Page 14 Notes ACC-SVN231C-EN...
- Page 15 Notes ACC-SVN231C-EN...
- Page 16 For more information, please visit trane.com or americanstandardair.com. Trane and American Standard have a policy of continuous product and product data improvement and reserve the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
