Installation Instructions
0 to 50% Motorized Outside Air
Damper
Precedent™ Packaged Rooftop Units
6 to 25 Tons
Model Number:
Used With:
FIADMPR102*
T/YS*072-150
FIADMPR103*
T/YS*180-300, W/D/GS*150-300
Note: This accessory is not for use on units with Single Zone VAV or True VAV supply fan types (Digit 15 = 2,3,4,5).
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
August 2022
SAFETY WARNING
ACC-SVN231A-EN
Advertisement
Table of Contents
Related Manuals for Trane Precedent FIADMPR102 Series
Summary of Contents for Trane Precedent FIADMPR102 Series
- Page 1 Installation Instructions 0 to 50% Motorized Outside Air Damper Precedent™ Packaged Rooftop Units 6 to 25 Tons Model Number: Used With: FIADMPR102* T/YS*072-150 FIADMPR103* T/YS*180-300, W/D/GS*150-300 Note: This accessory is not for use on units with Single Zone VAV or True VAV supply fan types (Digit 15 = 2,3,4,5). SAFETY WARNING Only qualified personnel should install and service the equipment.
- Page 2 Practices requirements for arc flash protection, PRIOR to servicing the unit. NEVER PERFORM ANY Trane believes that responsible refrigerant practices are SWITCHING, DISCONNECTING, OR VOLTAGE important to the environment, our customers, and the air conditioning industry. All technicians who handle TESTING WITHOUT PROPER ELECTRICAL PPE AND ARC FLASH CLOTHING.
- Page 3 Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.
-
Page 4: Table Of Contents
Table of Contents General Information – FIADMPR102* ..5 Inspection ......5 Parts List . -
Page 5: General Information - Fiadmpr102
General Information – FIADMPR102* This instruction covers installation of FIADMPR102* for 6 to 12.5 tons, T/YS*072-150. Inspection 1. Unpack all components of the kit. 2. Check carefully for shipping damage. If any damage is found, report it immediately, and file a claim against the transportation company. -
Page 6: Installation - Fiadmpr102
Installation – FIADMPR102* Uncrate the damper and locate all parts shown in Figure Figure 2. Damper panel Each damper ships with items 1, 2 and 3 attached. Remove screws completely from items 1 and 2. Remove item 3 by Align (3) slots in panel loosening the three screws but do not remove them. -
Page 7: Factory Installed Damper Set-Up
Installation – FIADMPR102* Factory Installed Damper Set-Up Figure 5. Damper assembly operating position Downflow Configuration To position damper for downflow operation, complete the following steps: WARNING Hazardous Voltage! Failure to disconnect power before servicing could result in death or serious injury. Disconnect all electric power, including remote disconnects before servicing. -
Page 8: General Information - Fiadmpr103
General Information – FIADMPR103* This instruction covers installation of FIADMPR103* for 12.5 to 25 tons, T/YS*180-300, W/D/GS*150-300. Inspection 1. Unpack all components of the kit. 2. Check carefully for shipping damage. If any damage is found, report it immediately, and file a claim against the transportation company. -
Page 9: Installation - Fiadmpr103
Installation – FIADMPR103* Field Installed Damper 3. Attach blockoff (2) to unit by using four screws. Figure 3. Install blockoff 1. Uncrate the damper and locate all parts shown in Figure 1, p. Figure 1. Damper contents 4. Secure economizer assembly (1) to unit using ten screws. -
Page 10: Factory Installed Damper (Field Set-Up) Downflow Configuration
Installation – FIADMPR103* Figure 5. Reinstall end panel Figure 6. Remove lower screws Blockoff Angle Factory Installed Damper (Field Remove screws and lay blockoff angle aside. Do not discard. Set-Up) 3. Do not remove the screws in the upper row of the end Downflow Configuration panel. - Page 11 Installation – FIADMPR103* 7. Install the blockoff angle underneath the economizer. The blockoff angle is designed to close the opening created, between the economizer and the base, when the economizer assembly is in its operating position. a. Holding the blockoff angle with the holes at the bottom and the bottom angle outward, tilt the top forward and insert it into the opening between the economizer and the unit base.
-
Page 12: Minimum Position Setting - Fiadmpr102
Minimum Position Setting – FIADMPR102*/103* To adjust the minimum position setting and check out the economizer, the power must be connected. 1. Close the unit disconnect and place the zone sensor fan selector in the fan ON position and the heat/cool selector in the OFF position. -
Page 13: Wiring - Fiadmpr102*/103
Wiring – FIADMPR102*/103* 1. Using the supplied harness connect PPF87 to the 3. After installation is complete, Symbio™ 700 UC unit actuator connector. configuration will need to be updated to reflected installed option. 2. Route harness to fresh air options module located in the return section and connect to FAOM-J11. - Page 14 Notes ACC-SVN231A-EN...
- Page 15 Notes ACC-SVN231A-EN...
- Page 16 For more information, please visit trane.com or americanstandardair.com. Trane and American Standard have a policy of continuous product and product data improvement and reserve the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
