CLOSE COUPLE TOILET
Installation Manual
Cygnet Hygiene Rim Over-height Round
Cygnet Hygiene Rim Round
Bottom Inlet
The more
stars the more
water efficient
3.5
litres
average flush
4.5 L per full flush / 3 L per half flush
In accordance with AS/NZS 6400
Licence No. 0050
LIXIL (Thailand) Public Company Limited
x1
x1
x1
x1
-1-
x1
x1
Option
1
x1
x1
Option
2
Sep. 2022
M33185 Rev.03
Advertisement
Related Manuals for American Standard Cygnet
Summary of Contents for American Standard Cygnet
- Page 1 CLOSE COUPLE TOILET Installation Manual Cygnet Hygiene Rim Over-height Round Cygnet Hygiene Rim Round Bottom Inlet Option Option The more stars the more water efficient litres average flush 4.5 L per full flush / 3 L per half flush In accordance with AS/NZS 6400 Licence No.
- Page 2 Cygnet Hygiene Rim Over-height Round w/ normal S&C WATER WATER SUPPLY SUPPLY FINISHED FLOOR FINISHED FLOOR 140-260 Cygnet Hygiene Rim Round w/ normal S&C WATER WATER SUPPLY SUPPLY FINISHED FLOOR FINISHED FLOOR 140-260 Cygnet Hygiene Rim Over-height Round w/ Spalet E-bidet...
- Page 3 2.1 / 2.2 Ø10 Option 2: Spalet Installation 4.1 / 4.2 Ø22 POWER SUPPLY Option 2: Spalet Installation ROUGHING - IN CONNECTOR ROUGHING - IN CONNECTOR ROUGHING-IN CONNECTOR CUTOUT (B) CUTOUT (B) CUTOUT (B) 140-149 mm. 10 mm. 160-170 mm. 30 mm.
- Page 4 Ø22 12.1 / 12.2 1. Cistern is installed properly 2. All moving components operate freely 3. All couplings are tightened correctly 4. Check carefully for leaks 5. Test the cistern flushes May 2020...
