User Manual

Attached Warranty Card

CEAS7SR1-0100510H0

CEAS7SR1-0100510P0

● Thank you very much for select-

ing Pristine Star E-bidet from

our company. Please read the

manual carefully and use it cor-

rectly.

● The pictures in the manual are

for reference only, please refer

to actual samples.

Full functional w/remote controller

Safety Precautions

Usage Precautions

Precautions Before Installation

Components Name

Installation

 Installation of E-bidet

 Installation of E-bidet water supply hose

 Installation of body water supply hose (body side)

 Installation of remote controller

 Power on conﬁ rmation

 Test run

Operation Instruction

Preparation and Conﬁ rmation before Using

Basic Operation

 Deodorization function is activated when the unit is occupied (auto deodorization)

 Shower

Oscillating

 Spray strength adjustment

 Nozzle position

 Bidet

Oscillating

 Massage

 Warm air dryer

 Stop (Power ON/OFF)

Other Function Settings

 Resume to factory settings

 To prevent low temperature burn

 Power Saving

 Night light

 Remote controller signal settings when multiple units are installed side by side

Information to the User

Cleaning And Caring

Daily Cleaning and Care

Cleaning and care of seat, lid and other plastic parts



Cleaning and care of nozzle



Cleaning after Removing Lid

Cleaning of Blocked Part of E-bidet

Cleaning of Nozzle Shutter

Cleaning Maintenance of Deodorization Filter

When Cleaning Function Weakens

How To Prevent Freezing And Care During Not Using For A Long Period 31

Replacing Remote Controller Battery

General Trouble Shooting

After-Sales Service

Anti-Bacterial

Speciﬁ cation

Pristine Star E-bidet

Contents

Need help?

Do you have a question about the Pristine Star CEAS7SR1-0100510H0 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Standard Pristine Star CEAS7SR1-0100510H0

Page 1 Pristine Star E-bidet Full functional w/remote controller User Manual Contents Safety Precautions Usage Precautions Attached Warranty Card Precautions Before Installation Components Name Installation CEAS7SR1-0100510H0  Installation of E-bidet  Installation of E-bidet water supply hose CEAS7SR1-0100510P0  Installation of body water supply hose (body side) ...
Page 2 Safety Precautions Safety Precautions Please read the following “safety precautions” carefully before using so as to properly use the product. Failure to properly observe the following safety precautions may result in serious accidents. Please strictly observe the following content, which is closely related to your safety. Explanation of terms and marks WARNING …...
Page 3 WARNING WARNING ● In case of any problems (abnormal noises, abnormal smell, smoking, high temperature, breakage) with the main unit of E-bidet, power plug or power cord, please immediately unplug the power cord and contact the after-sales service.  Risk of electric shock or ﬁ re. ●...
Page 4 CAUTION CAUTION  ● When caring and cleaning the plastic part of the product, do not use unsuitable deter- gents (toilet cleaner, apartment cleaner, bleacher, benzene, painter thinner, decontami- nation powder, cresol, alcohol, etc.).  Risk of personal injury, electric shock or ﬁ re due to broken plastic parts. ...
Page 5 Usage Precautions Usage Precautions  Please strictly follow the following precautions to prevent any malfunction. In case of thunder and lightning nearby, please Keep heater or warmer, etc. away from the E- disconnect the power plug from the power socket. bidet.
Page 6 Precautions Before Installation Precautions Before Installation  Packing Material List E-bidet body Remote controller Manual Mounting plate Mounting bolt Water supply hose (w/ T-junction) Fixing block Clip Rubber expansion Plastic sleeve  Installation Tools Preparation Adjustable wrench (with 26 mm 23~26mm above of adjustable range) (Model of wrench varies...
Page 7  Power Supply and Water Supply  What kind of power socket should be used? ● Please use standard 3-hole power socket with AC220 V, 50 Hz and max. power 650W. ● Power cord length is 1.0 m. The power socket should be installed in a dry place within the length of the cord and higher than the ﬂ...
Page 8 COMPONENTS NAME COMPONENTS NAME  Integral Diagram Lid bumper Seat sensor (built-in) Water tank Water tank inlet pipe Nozzle shutter Power plug Nozzle Warm air dryer Seat Water supply valve E-bidet inlet pipe Remote control sig- nal sensor window Bowl Power saving indicator Power indicator ...
Page 9  Operation Massage Feminine ● Massage cleaning (only for posterior) ● For use in feminine cleaning. ● Press 2nd time for oscillating Power Saving function. ● Press the “Power Saving” button to enter power saving mode. Stop Spray strength adjustment ●...
Page 10 Installation Installation  Installation of E-bidet 1. Remove the old E-bidet Installation diagram (1) Remove 3I, 3J, 3K underneath of the bowl. (2) Take up 3G and remove it together with 3H. Body mounting bolt Fixing block Mounting plate Rubber expansion Ceramic mounting hole E-bidet body 2.
Page 11  Installation of E-bidet water supply hose 1. Remove 1 A after 1 D is closed. Installation diagram  There will be small amount of water leak- age during removal, so put a piece of cloth, Toilet water supply hose etc.
Page 12 4. Adjust the installing position of E-bidet to front, rear, left and right (1) Adjust the installing position to front, rear, left and right, so that 3F edge matches with ceramic edge curve of bowl. (2) Press locking handle (3L) on right side, slide 3F forward to remove it. Locking handle Adjust E-bidet to front and rear...
Page 13  Installation of remote controller Unit: mm Approximate reference range of installation position Installation Claw clip (locking part) Back cover Batteries If it is difficult to open the back cover, please remove it by pressing the claw clip (locking part) with such Remote controller body tools as minus screwdriver.
Page 14 [For plywood and plasterboard walls less than 5mm thick Drill a bottom hole with a diameter of 6mm. Plastic expansion tube (5mm for plasterboard) Lightly tap the attached plastic expansion tube in with such tools as hammer. Securely fix the bracket with wooden screws. Bracket During tightening, you will feel tightness at the beginning, followed by looseness for a short time,...
Page 15  Power on confirmation 1. Connect the power plug to power socket. 2. Conﬁ rm whether the power is on. (1) Conﬁ rm power indicators on product turn (2) To prevent dry burning of warm water tank, before the test run is done, press Power button to turn off all indicators.
Page 16 OPERATION INSTRUCTION OPERATION INSTRUCTION Preparation and Confirmation before Using If this is your ﬁ rst time to use E-bidet, the following steps must be conﬁ rmed.  Methods of turning on/off the water supply valve written in this manual may be different from the ac- tual circumstances.
Page 17 STEP Testing shower function. (1) Press the seat to enter sitting state (press force is more than 12 N). (2) Press Posterior button. (3) Cover the front of nozzle with left hand after nozzle is extended to block water ﬂ ow. If this is your ﬁ...
Page 18 Basic Operation Seat sensor is available to sense if there is anyone sitting on the toilet seat. Without sitting on, shower, bidet, deodorization or dryer function will not work.  Deodorization function is activated when the unit is occupied (auto deodorization) (1) Auto deodorization is activated when people sit on.
Page 19  Shower Oscillating  Bidet Oscillating Press Posterior button. Press Feminine button. Water sprays out from front of nozzle to clean Water sprays out from front of nozzle to clean feminine. posterior. Pressing again will enter front and rear oscillating sta- Pressing again will enter front and rear oscil- tus, and the oscillating range will be expanded.
Page 20  Warm air dryer 2. Press “Dryer” button again to 1. Press “Dryer” button. switch dry temperature. The indicator will be switched each time the Warm air is blown out to dry the wet parts due button is pressed, achieving appropriate tem- to shower, massage or bidet.
Page 21 Other Function Settings  Resume to factory settings Press and hold “+” and “-” button of Spray Strength simultaneously for more than 2 seconds. Front Rear Power  To prevent low temperature burn Press and hold “Seat Temp” and “Feminine” buttons for more than 2 seconds.
Page 22  Power Saving Power saving function is divided into one touch power saving (8 hrs) and high efficiency power saving (always). Using high efficiency power saving and one touch power saving (8 hrs) simultaneously, the power saving effect is more significant. The initial setting is "Close". One Touch Power Saving (8 hrs) If the product is not used during night time, etc., pressing POWER SAVING button will cut off power of both warm water and seat heater for up to 8 hours, so as to reduce unnecessary power consumption.
Page 23  Night light E-bidet is equipped with night light, which can be enabled when necessary. 1. To turn on night light, press [Night Light] button on the remote controller. 2. To turn off night light, press [Night Light] button on the remote controller. Front Rear Power...
Page 24 Information to the User Information to the User Water comes out from nozzles Abnormal smell in warm air at the very beginning When the seat is occupied or the cleaning func- When the product is used from the very begin- tions are activated, there may be water coming ning, there may be slight abnormal smell when out from nozzles.
Page 25 CLEANING AND CARING Daily Cleaning and Care  Cleaning and care of seat, lid and other plastic parts ● Use a soft damp cloth to clean. Stain will be hard to remove if it cannot be removed timely. Use water to clean stain. Cleaning the unit with water can prevent static electricity from occurring, which may result in attachment and nigrescence of stain.
Page 26 Cleaning after Removing Lid The lid can be easily removed, so that the lid and the blocked parts can be cleaned. Remove lid Install lid Align the pin hole on the left of the lid with the Press “POWER” button to turn off power pin on the left of the unit, and then insert.
Page 27 Cleaning of Blocked Part of E-bidet The product can be removed, so that the bowl and the internal parts of the product can be cleaned. 1. Removal Method of E-bidet 1. Unplug the power plug from the power socket. 2. Turn off water supply valve and stop water supplying.
Page 28 2. Cleaning Method 3. Installation Method of E-bidet ● When cleaning the E-bidet, please 1. Place the E-bidet on the bowl, aligning the middle of mop it by damp soft cloth. E-bidet and mounting plate. Arrow mark of mounting plate of E-bidet Please clean here Center of back of E-bidet...
Page 29 Cleaning of Nozzle Shutter After applying the neutral de- tergent on a soft cloth or sponge, clean it with cold water or warm water. [CAUTION] Removal of Nozzle Shutter Installation of Nozzle Shutter [Nozzle Cleaning] Front Rear Power [CAUTION]...
Page 30 Cleaning Maintenance of Deodorization Filter Cleaning Maintenance of Deodorization Filter Install the filter on base plate of product. Unplug the power plug from the power socket. Remove the E-bidet from bowl. Remove the filter from installation port of deodor- ization filter on left side of body undersurface. Install the E-bidet on bowl.
Page 31 When Cleaning Function Weakens When using the product for a long period, or feeling that spray strength of cleaning decreases, please clean the strainers of product in following order. (About once for two years) Cleaning Method of Strainer 1. Turn off water supply valve and stop water supplying. ...
Page 32 HOW TO PREVENT FREEZING AND CARE DURING NOT USING FOR A LONG PERIOD In cold winter, freezing of the water in water tank may cause E-bidet damage or water leakage. To avoid this issue, please make sure power plug is inserted into power socket and turn on power supply, and cancel power saving function.
Page 33 Replacing Remote Controller Battery If the “Battery Indicator” on the front side of remote controller flashes due to battery consumption, please replace the batteries of remote controller according to the following procedure. Battery indicator [ CAUTION ] terminal of battery as indicated on the remote controller. buttons of remote controller.
Page 34 General Trouble Shooting Some problems can be solved easily, before applying for repair, check the items listed below. If the problems cannot be solved with the help of following troubleshooting methods, please contact the store where you purchased the product, or contact customer service call center. For some problems, you may still need to pay the repair charges even your warranty is still valid, please conﬁ...
Page 35 Posterior, feminine Symptoms Probable causes Recommended action No reaction Seat sensor is not activated. Adjust sitting position, posture, etc. Water supply valve is off. Turn on the water supply valve. Mesh of ﬁ lter is blocked. Clean the ﬁ lter. Water pressure is too low, and Set spray strength to “HIGH”.
Page 36 5 The date you expect on-the-spot service Questions related to the product If you have questions regarding the product and its usage, please call: Service hotline of American Standard: 800-820-3191 (for users with ﬁ xed phone) 400-820-3191 (for users with mobile phone) Ofﬁ cial website: www.americanstandard.com.cn...
Page 37 ANTI-BACTERIAL Anti-bacterial: Toilet seat with antibacterial effect: KILAMIC antibacterial materials are used for toilet seat, which has passed the speciﬁ c certiﬁ cation by SIAA. KILAMIC antibacterial materials are effective for inhibiting the proliferation of bacteria on the surface of products.
Page 38 Speciﬁ cation CEAS7SR1-0100510H0 Model CEAS7SR1-0100510P0 Function description Full functional w/remote controller Rated voltage AC 220V 50Hz 1 Rated power 300W Water pressure range 0.06MPa (ﬂ ow pressure) - 0.75MPa (hydrostatic pressure) Ambient temperature range 0°C-40°C   Product size L535mm W436mm H173mm Water inlet type...
Page 40 Other conditions due to customers' intentional or negligent caused fault Thailand Indonesia Hotline : 02 102-2222 Hotline : 0-800-1-267823 Manufactory: LIXIL (Thailand) Public Co., Ltd. Manufactory: PT American Standard Indonesia Website : www.americanstandard.co.th Website : www.americanstandard.co.id Vietnam Philippines Hotline : 1900-54-54-60...
