11. IP55 Enclosed Drive

11.1.

Overview

GV
Optidrive Plus 3 is optionally available in an IP55 enclosed version for power ratings up to 4kW / 5HP. Un-switched versions have no built in
controls. Switched versions have built in local isolator, Potentiometer and control switch.
11.2.

Models and Ratings

200-240V ±10% - 1 Phase Input – 3 Phase Output
Model (kW) kW
ODP-12037-xx-I55 0.37
ODP-12075-xx-I55 0.75
ODP-12150-xx-I55 1.5
ODP-22150-xx-I55 1.5
ODP-22220-xx-I55 2.2
200-240V ±10% - 3 Phase Input – 3 Phase Output
Model kW
ODP3-22150-xx-I55 1.5
ODP3-22220-xx-I55 2.2
380-480V ±10% - 3 Phase Input – 3 Phase Output
Model kW
ODP-24075-xx-I55 0.75
ODP-24150-xx-I55 1.5
ODP-24220-xx-I55 2.2
ODP-24400-xx-I55
500-600V ±10% - 3 Phase Input – 3 Phase Output
Model (kW) kW
ODP-25075-xx-I55 0.75
ODP-25150-xx-I55 1.5
ODP-25220-xx-I55 2.2
ODP-25370-xx-I55 3.7
ODP-25550-xx-I55 5.5
For switched versions, an 'S' is added to the end of the part number, E.g. ODP12037-I55S
NOTE All other rating data is as per IP20 units, see table on page 27
xx = Country Specific Model Code
11.3.

Power and Motor Cable Installation

Some types of gland nut will require modification for correct installation. Remove one or more flanges as shown
until the nut will fit in the apertures.
Any Metal conduit used MUST be earth bonded by means of suitable earthing washer or gland adaptor.
Lock Off: On the switched models the main power isolator switch can be locked in the 'Off' position using a
20mm standard shackle padlock (not supplied).
Gland Hole Sizes:
Size 1
Size 2
Recommended Gland Type: SkinTop UL approved (UL94-V0) Type12/IP55 non-metallic cable gland or non-rigid
conduit
Size 1
Size 2
Optidrive Plus 3
Model (HP)
ODP-12005-USA-I55 0.5
ODP-12010-USA-I55
ODP-12020-USA-I55
ODP-22020-USA-I55
ODP-22030-USA-I55
Model
ODP3-22020-USA-I55
ODP-22030-USA-I55
Model
ODP-24010-USA-I55
ODP24020-USA-I55
ODP-24030-USA-I55
4 ODP-24050-USA-I55
Model (HP)
ODP-25010-USA-I55
ODP-25020-USA-I55
ODP-25030-USA-I55
ODP-25050-USA-I55
ODP-25075-USA-I55 7.5
www.invertek.co.uk
GV
User Guide
HP Frame Size Nominal Input Current
1
1 1
2 1
2 2
3 2
HP Frame Size Nominal Input Current
2 2
3 2
HP Frame Size Nominal Input Current
1 2
2 2
3 2
5 2
HP Frame Size Nominal Input Current
1 2
2 2
3 2
5 2
2
I/P & O/P Power (Φ) Centre Knockout (Φ)
(22mm)
(25mm)
I/P & O/P Power
PG13.5 / M20
PG16 / M25
Nominal Output Current
Amps Amps
6.7 2.3
12.5 4.3
19.3
19.3
28.8 10.5
Nominal Output Current
Amps Amps
9.2
13.7 10.5 (9)
Nominal Output Current
Amps Amps
2.9 2.2
5.4 4.1
7.6 5.8
12.4 9.5
Nominal Output Current
Amps Amps
2.2 1.7
4.1 3.1
5.4 4.1
7.6 6.1
11.7
Terminal Cover Knockout
(22mm)
(22mm)
Centre Knockout Terminal Cover Knockout
PG13.5 / M20
PG13.5 / M20
7
7
7
9
(Φ)
(17mm)
(17mm)
PG9 / M16
PG9 / M16
33
