Installation Instructions for model RV-QBR-A
convenient for filter replacement. t For cold water use only.
t After prolonged periods of non-use it is recommended
that the system be flushed thoroughly. Let water run for
2-3 minutes before using.
t The filter cartridge used with this system has a limited
service life. Changes in taste, odor, color, and/or flow of
the water being filtered indicate that the cartridge
should be replaced.
t In-line filter life depends upon the water volume used
and the substances present in the water source.
SHURflo recommends changing the filter every 6 to 12
months or when its capacity expires, whichever comes
first.
Mounting the Filter System:
1. Select a location where filter system is to be mounted.
⁄
1
NOTE: Allow 1 -inches [38 mm] clearance below
2
housing or 11-inches [279 mm] below filter head to
enable filter cartridge changes. CAUTION: Filter head
should be mounted securely to a solid stud or surface.
The mounting bracket will support the weight of the
filter and help prevent strain on the cold water line.
2. Filter head should be mounted in vertical position, use
the mounting bracket as a template to mark screw
locations. Mount filter head in marked location using the
screws provided in the hardware kit.
Mounting the Faucet:
1. Select a position on the bench to mount the faucet,
ensuring there is adequate space below to clamp down
faucet with washer and nut supplied.
2. Drill an appropriate size hole in bench in the location
you identified as above.
3. Mount the faucet in bench.
4. Fit 1/4-inch tap adaptor to bottom of faucet.
Connecting the Tubing and Fittings:
Pentair Water Australia (PWA) warrants this filtration kit to be free from material and workmanship defects under normal use and service for a
period of one (1) year from the date of purchase. In the absence of proof of purchase, the warranty is one (1) year from the date of
Replacement Cartridge
t Install in a location
Model RV-QDRF-A
Filter head is equipped with 1/4-inch quick connect
fittings. Other fittings included are:
12 mm Equal Tee (1)
12 mm Stem to 8 mm Tube Connector (1)
5/16-inch Stem to 1/4-inch Tube Connector (1)
1.5 m length of 1/4-inch Tube (1)
1/4-inch Tap Adaptor (1)
Faucet (1)
Use the appropriate fittings for your installation:
To adapt to a 12 mm tube cold water supply, follow these
instructions.
1. Reduce the branch of the 12 mm Equal tee down to
1/4-inch by firstly pushing in the 12 mm stem to 8 mm
Tube Connector into the 12 mm branch of the Equal
Tee, then push the 5/16-inch stem to 1/4-inch Tube
Connector into the 8 mm Tube Connector.
2. Cut the 12 mm tube to the cold water supply and
connect tubing to the in-line ends of the equal tee.
3. Cut the 1/4-inch tubing supplied to connect tube from
the 1/4-inch Tube Connector on the Tee to the inlet
side of the filter head.
4. Fit the 1/4-inch Tubing to the outlet side of the filter
head to the 1/4-inch Tap Adaptor on the faucet.
5. Make sure all connections are secure.
6. Turn on water and check for leaks.
7. Allow water to run approximately 2–3 minutes to flush
and saturate filter.
You are now ready to enjoy:
"Great-Tasting, Healthy, Clean Water"
NOTE: Do not use with water that is
microbiologically unsafe or of unknown quality
without adequate disinfection before or after the
unit.
LIMITED WARRANTY
