Section 1 - General Information
ON/OFF
Press this button to turn the
unit on or off.
Power Receptor
Receptor for the supplied power
adapter.
D-Link DSL-540B ADSL+ 4-Port Router User Manual
Rear Panel View
LAN Ports (1-4)
Connect Ethernet devices such as
computers, switches, and hubs.
Reset
Pressing the Reset button restores the router to
its original factory default settings.
DSL Line
Connect to an active telephone
line (RJ-11).
6
