Air Lift LoadLIFTER 5000 Installation Manual

Dodge freightliner sprinter 2500 srw
Hide thumbs Also See for LoadLIFTER 5000:

Advertisement

Quick Links

Kit 57147
Dodge Freightliner
Sprinter 2500 SRW
Cover illustration
may not depict
actual kit.
INSTALLATION GUIDE
For maximum effectiveness and safety,
please read these instructions completely
before proceeding with installation.
Failure to read these instructions can result in an
incorrect installation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LoadLIFTER 5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Air Lift LoadLIFTER 5000

  • Page 1 Kit 57147 Dodge Freightliner Sprinter 2500 SRW Cover illustration may not depict actual kit. INSTALLATION GUIDE For maximum effectiveness and safety, please read these instructions completely before proceeding with installation. Failure to read these instructions can result in an incorrect installation.
  • Page 3: Table Of Contents

    Tools List ............5 Installing the LoadLifter 5000 System . . . . . . . . . . . . . . 5 Assembling the Air Spring .
  • Page 4: Introduction

    Air Lift Company reserves the right to make changes and improvements to its products and publications at any time. For the latest version of this manual, contact Air Lift Company at (800) 248-0892 or visit our website at www.airliftcompany.com.
  • Page 5: Installation Diagrams

    LoadLifter 5000 Installation Diagram (2003-2006 Models) NOTE: Based on your load and stock spring condition, it may be necessary to use pressures well above the minimum for this application to function properly. Flange goes on the outside of the frame...
  • Page 6: Installation Diagram (2007 And Later Models)

    LoadLifter 5000 Installation Diagram (2007 and Later Models) NOTE: Based on your load and stock spring condition, it may be necessary to use pressures well above the minimum for this application to function properly. Flange goes on the inside of the frame fig.
  • Page 7: Hardware List

    3/8”-16 Nyloc nut.........2 *Not shown in fig. 1 and fig. 2 10551 Hose clip* ..........4 Missing or damaged parts? Call Air Lift customer STOP! service at (800) 248-0892 for a replacement part. TOOLS LIST Description ............Qty Description .
  • Page 8: Attaching The Air Spring Assembly

    LoadLifter 5000 3/8” Bolt (E) 3/8” Lock washer (F) 3/8” Flat washer (G) Upper bracket (B) fig. 3 3. Place the lower brackets (C) on the air springs. NOTE There are holes on the legs of one side of the bracket only. The holes should be on the side of the air spring opposite the installed air fitting.
  • Page 9: Attaching The Upper Bracket

    LoadLifter 5000 5. Insert the spacer (N) between the shock bracket and the lower bracket (fig. 5). 6. Attach the lower bracket to the shock bracket using a 3/8”-16 X 1¼” hex head cap screw (I), flat washer (J), and nyloc nut (K) (figs. 1 & 5 for ‘03-’06 models or figs. 2 & 5 for ‘07 and later models).
  • Page 10 LoadLifter 5000 3. Cut the air line assembly (AA) in two equal lengths. WHEN CUTTING OR TRIMMING THE AIR LINE, USE A HOSE CUTTER, A RAZOR BLADE CAUTION OR A SHARP KNIFE. A CLEAN, SQUARE CUT WILL ENSURE AGAINST LEAKS. DO NOT USE WIRE CUTTERS OR SCISSORS TO CUT THE AIR LINE.
  • Page 11: Installing The Heat Shield

    LoadLifter 5000 Option 1 Option 2 fig. 8 7. On the passenger side only, place the provided thermal sleeve (T) on the air line near the exhaust. 8. Cut off air line leaving approximately 12” of extra air line. A clean square cut will ensure against leaks (see fig.
  • Page 12: Fixing Leaks

    DO NOT CUT THE AIR LINE COMPLETELY OFF AS THIS WILL NICK THE BARB AND CAUTION RENDER THE FITTING USELESS. 3. If the preceding steps have not resolved the problem, call Air Lift customer service at (800) 248-0892 for assistance. Before Operating...
  • Page 13: Post-Installation Checklist

    LoadLifter 5000 POST-INSTALLATION CHECKLIST (To be completed by owner)  Overnight leakdown test — Recheck air pressure after vehicle has been used for 24 hours. If pressure has dropped more than 5 PSI, check for leaks and fix accordingly following the instructions on page 8 or return to the installer for service.
  • Page 14: Warranty And Return Policy

    Air Lift 1000 ....Lifetime Limited Load Controller (I) ... . 2 Year Limited RideControl .
  • Page 15: Product Use

    No. Adding air springs will not change the weight ratings (GAWR, GCWR and/or GVWR) of a vehicle. Exceeding the GWVR is dangerous and voids the Air Lift warranty. Q . Is it necessary to keep air in the air springs at all times and how much pressure will they need? The minimum air pressure should be maintained at all times.
  • Page 16: Guidelines For Adding Air

    Unlevel Replacement Information If you need replacement parts, contact the local dealer or call Air Lift customer service at (800) 248-0892. Most parts are immediately available and can be shipped the same day. Contact Air Lift Company customer service at (800) 248-0892 first if: •...
  • Page 20: Need Help

    Thank you for purchasing Air Lift products — the professional installer’s choice! Air Lift Company • 2727 Snow Road • Lansing, MI 48917 or PO Box 80167 • Lansing, MI 48908-0167 Toll Free (800) 248-0892 • Local (517) 322-2144 • Fax (517) 322-0240 • www.airliftcompany.com...
