Daisychain setup
Main menu  Settings  Device settings  Modbus settings
In case the BDL Compact is at the bus end (last server in the bus) then the Modbus have to be terminated.
This is done for the BDL Compact by SW by activation of the
Note:
It is recommended NOT to use the default address in a multi-server network. It is of great importance
to ensure at the time of the procedure of device addressing, that there is not two devices with the same
address. In such a case, an abnormal behavior of the whole serial bus can occur, the client being then in the
impossibility to communicate with all present s on the bus.
Here please define your communication parameters.
Modbus Id, Baudrate,Stopbits,Parity, Term and Bias
Enable the RTU Modbus by activation of the
Modbus button.
Confirm the changes by pressing the button Apply
Remark: Only in case of changes the button Apply
appears else to go back with button
By pressing the button Set to Default
values will be defined.
Default values:
Baudrate:
Parity:
Stopbits
Term and Bias Button
METPOINT BDL Compact
®
enable
Back
the default
19200 bps
even
1
