METPOINT ® BDL Compact
4.2 Ethernet connection for Modbus/TCP
For easy Ethernet cable connection to your network an ordinary RJ45 Ethernet cable connection is provided.
Cable:
An Ethernet cable with category 5 or better is to be used.
5. Modbus RTU communication settings
Before communication with the client, baudrate, address, and framing must be defined
5.1 Accessing and changing Modbus settings
First step:
Main menu  Settings  Device settings  Modbus settings
The settings are all protected by a password!
Inputs and changes have to be confirmed by pressing
Enter Password
8 | 32
OK in general!
Factory settings for password at the time of delivery:
0000 (4 times zero).
If required, the password can be changed in the
Password settings.
The new password must be entered two times in a
row and in each case confirmed with OK.
If an incorrect password is entered there appears
Enter password or New password repeat
If you can't remember the password, please use
Master password in order to enter a new password.
Remark:
The Master password is supplied together with the
instrument's documentation.
Daisychain setup
in red font.
