Beko METPOINT BDL Compact Installation And Operating page 19

Daisychain setup
Modbus Modbus
Register Address
2107 2106
2108 2107
2109 2108
2110 2109
2111 2110
2112 2111
2113 2112
2114 2113
2115 2114
2116 2115
2117 2116
2118 2117
2119 2118
2120 2119
2121 2120
2122 2121
2123 2122
2124 2123
2125 2124
2126 2125
2127 2126
No.of Data
Description
Byte Type
2 word Channel A2
Value 7 Status
2 word Channel A2
Value 8 Status
2 word Channel B1
Value 5 Status
2 word Channel B1
Value 6 Status
2 word Channel B1
Value 7 Status
2 word Channel B1
Value 8 Status
2 word Channel B2
Value 5 Status
2 word Channel B2
Value 6 Status
2 word Channel B2
Value 7 Status
2 word Channel B2
Value 8 Status
2 word Channel V1
Value 5 Status
2 word Channel V1
Value 6 Status
2 word Channel V1
Value 7 Status
2 word Channel V1
Value 8 Status
2 word Channel A1
Value 1 Status
2 word Channel A1
Value 2 Status
2 word Channel A1
Value 3 Status
2 word Channel A1
Value 4 Status
2 word Channel A2
Value 1 Status
2 word Channel A2
Value 2 Status
2 word Channel A2
Value 3 Status
METPOINT
Default Read
Setting Write
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R
0 R/W
0 R/W
0 R/W
0 R
0 R
0 R
0 R
BDL Compact
®
Comment
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
Status *2)
19 | 32
