- Page 1 FACTORY AUTOMATION ELECTRONIC MULTI-MEASURING INSTRUMENT ME96SS...
- Page 2 ME96 Super-S Series ME96 Super-S Series Electronic Indicating Instruments Electronic Indicating Instruments functions and optional units functions and optional units Highly appreciated ME96SS Series Electronic Multi-Measuring Instruments measuring functions and network capability has been released. ME96SSHB-MB (high-performance model) ME96SSHB-MB (high-performance model)
-
Page 3: Outline And Features
Outline and Features Compact size »Realized downsizing for ME96SSEB-MB. It contributes to space saving! 90.2mm (110.9mm) 36.0mm 20.7mm 13.0mm ME96SSEA-MB ME96SSEB-MB (Conventional type) (New type) Improved Measurement Functions »Added measurement function, reactive energy, apparent energy, reactive power and apparent power for ME96SSEB-MB. Model name Transmission/Option specifications Main measurement items... - Page 4 Data in more than one logging unit can be managed with one SD memory card. Note: Use the SD memory card (EMU4-SD2GB) made by Mitsubishi Electric. Use of any memory card other than our product (EMU4-SD2GB) is not covered by the warranty.
- Page 5 ME96 Super-S Series Ver.B Features Succeeded Display Functions Concurrent Display of 4 items The 4 measured values can be digitally confirmed on one screen. Bar graph display 4 lines of digital display 3 lines of digital display Conventional type New type »Concurrent Display of Each Phase Measured Values...
- Page 6 Impressive Monitoring Functions Advanced Alarm Display (1) A function to blink the backlight upon occurrence of an alarm is provided. The product has a setting function to blink the backlight upon occurrence of an alarm. (2) The automatic or manual alarm cancel mode can be selected. (3) Up to four points of upper and lower limits can be monitored.
- Page 7 ME96 Super-S Series Ver.B Features Variety of Complementary Features Password Function With the password function, the following items can be protected from an accidental execution. Password-protected item Password-protected item Shift to the setting mode Adjust the time limit of rolling demand Reset the max./min.
- Page 8 Test Function »A test function is provided to check the wiring for communication, alarm output/contact output, analog output and pulse output without input of voltage or current. »At the time of wiring test before shipment of the board and counter test for system validation on site, test signals can be output only by applying the auxiliary power. Note: Depending on the optional unit and settings, the test function may not be available (may not be displayed).
-
Page 9: Specifications
Specifications ‡ME96SSHB-MB Model name ME96SSHB-MB Phase wire system 3-phase 4-wire, 3-phase 3-wire (3CT, 2CT), 1-phase 3-wire, 1-phase 2-wire (common use) Current 5 A AC, 1 A AC (common use) 3-phase 4-wire: max 277/480 V AC 3-phase 3-wire: (DELTA) max 220 V AC, (STAR) max 440 V AC Rating Voltage 1-phase 3-wire: max 220/440 V AC... -
Page 10: Standards Compliance
‡Standards Compliance Electromagnetic Compatibility Emissions EN 61326-1 / EN 55011, CISPR 11 Radiated Emission FCC Part15 Subpart B Class A EN 61326-1 / EN 55011, CISPR 11 Conducted Emission FCC Part15 Subpart B Class A Harmonics Measurement EN 61000-3-2 Flicker Meter Measurement EN 61000-3-3 Immunity Electrostatic discharge Immunity... - Page 11 External Dimensions/Installation/Connections Dimensions ME96SSHB-MB, ME96SSRB-MB Optional Plug-in Module : ME-4210-SS96B, ME-0040C-SS96, ME-0052-SS96 88.8 81.2 25.2 Terminal screw M3 17.1 46.8 Optional Plug-in Module : ME-0000BU-SS96 88.8 81.2 25.2 96.0 ME96SSEB-MB 17.1 Optional Plug-in Module : ME-0000MT-SS96 Terminal screw M3 88.8 81.2 25.2 96.0...
- Page 12 Wiring 1 Applicable Cable Size Part Screw type Wire specifications Tightening torque The table on the right describes Product main body • Use of crimp-style terminals: the applicable wire size. (auxiliary power supply, AWG26 to 14 (2 wires can be connected.) voltage input, current input 0.6 to 0.8 N·m Applicable crimp-style terminal:...
- Page 13 External Dimensions/Installation/Connections Wiring Diagrams (Continued) Single phase 3-wire system Single phase 2-wire system: With VT MODBUS RTU MODBUS RTU T/R+ T/R+ Communication Communication T/R− T/R− qAuxiliary power supply: 100-240VAC or VDC MODBUS RTU wFuse: 0.5A Communication eWhen the MODBUS RTU unit at the destination does not have an SG terminal, it is unnecessary to connect qAuxiliary power supply:...
- Page 14 Wiring Diagrams (Continued) 1. Pulse output, alarm output, and contact input/output cables must not be in close proximity or bundled with power cables or high-voltage cables. When laid parallel, separate by the distance shown in the following table. Condition Distance Power lines of 600V or less 300mm or more Other power lines...
