Getting Started
Scan QR Code to:
View Installation Videos
Download Bullhorn Tools
Access Bullhorn Web Con guration Steps
Product Overview
The RM540 unit is designed to be installed on a test station
consisting of a 3 inch riser post and a test head with one or
two attached reference cells. The test station must be
connected to the pipeline structure, with structure
connections terminated to the test head's connection panel.
Included Components
Bullhorn RM540C or RM540S
RM540 wiring cable
Test head spacer
Security
RM540 units can be con gured with a unique security PIN.
Once set, the PIN is required to connect to the unit with the
Bullhorn Tools App. This security feature is NOT enabled by
default. Refer to the Bullhorn Web User Guide for details
about enabling the feature and setting a PIN.
© 2024 American Innovations, Ltd.
RM540 Installation & Con guration
Quick Reference Guide
Philips #s 1, 2, & 3 Screwdrivers
Flathead Screwdriver
Adjustable Wrench
Voltmeter
3/8" Hex Socket Wrench
Recommended Installation
Extra panel nuts
Extra washers (1/4-32)
Crimper (18-22 AWG)
Insulated spade terminals
1 of 4
Required Tools
7/16" Combo Wrench
3/8" Combo Wrench
Bluetooth Enabled Mobile
Device
Magnet (to activate Bluetooth)
Materials
14-16 gauge stranded wire
1/4-20bolts
#8 and 1/4" ring crimps
Wire stripper and wire cutter
Recommended Accessory
Sold Separately
Triton® Test Point
Test Station
Measurements:
 Single Structure Pipe-To-Soil
Sales@aiworldwide.com
800-229-3404
Part No. 122267-000, Rev. 5
