Mounting Hubbed Drums or Rotors List of Standard Accessories Command Module - Machining Mode Pro-Cut International is dedicated to providing our customers with the most advanced, precise, Acceptance from Carrier Command Module - Set-Up Mode and profitable tools for brake repair. We have worked with, learned from and solved problems...
Page 5
This warranty extends to the original owner of the equipment. Pro-Cut International warranties this equip- You have just purchased what we feel is the finest bench brake lathe in the world. Your Pro-Cut B17 is a high ment against defects in materials or workmanship as follows.
Page 6
Lathe Overview COMPONENTS Emergency Stop 1” Arbor Spindle Start/Stop LED Task Lamp Spindle Speed Select Knob Spindle Ring Lamp (Hidden From View) Feed Start/Stop Tool Cabinet Base Feed Quality Select Knob Motor Disc/Drum Cutting Plate Lock Lever Draw Bar Cover Disc Cutting Head Way Covers Drum Boring Bar...
Page 7
STANDARD ACCESSORIES INCLUDED WITH THE B17 BENCH LATHE SPECIFICATIONS 1 Draw Bar with Hex Nut · 90-264VAC 50/60Hz 1ph Input · Spindle Speed RPM 100-140-180 2 Large Bell Clamp 2 Small Bell Clamp · Rotor Capacity 4-19.50” [101.6-495mm] · Feeds per Spindle Revolution 4 Centering Cones 3 Silencers ·...
Carefully inspect all items received in this shipment. If there is damage or evidence of mishandling in transit, determine the extent of damage and notify the transit company as well as Pro-Cut or your local Pro-Cut rep immediately. Although we SPECIAL PRECAUTIONS: The Pro-Cut B17 brake lathe was designed to machine the portions of the brake drum &...
Page 9
WORK AREA: Keep the floor around the machine clean and free of foreign materials. Pro-Cut recommends the use of NEVER STAND ON LATHE: Serious injury could occur if the lathe is tipped or if the cutting tool is unintentionally con- anti-skid floor strips where the operator normally stands, and that each machine has its own work area marked off.
Page 10
Lubricate ways by oiling felt wipers on the end of cross slide every week with Pro-Cut 50-376 way oil or equivalent. MISUSE: Do not use the machine for other than its intended use. If used for other purposes, Pro-Cut International, LLC, For other iron surfaces we recommend high quality rust prevention coating such as CRC brand 3-36 multi-purpose disclaims any expressed or implied warranty, and holds itself harmless for any injury or loss that may result.
Page 11
Fit work piece to arbor and clamp in place lower feed rate, and so take longer. The coarsest finish setting, when used with Pro-Cut inserts is designed to give a Choose disc or drum operation by rotating the cutter support plate to the desired location finish at or about 100 micro-inch / 2.54 micron Ra, the upper roughness limit allowed for many vehicles.
D. Slide the drum or rotor on the arbor and then mount the other bell clamp. been exceeded. Pro-Cut International recommends that each work piece be checked for size before mounting on the E. Add necessary spacers (double tapered radius adapters may be used as spacers), alignment washers lathe and after machining.
Page 13
UNTIL THE CLIP IS SECURED. DO NOT ATTEMPT TO MACHINE DRUMS WITHOUT USING THE SILENCER BAND. 6. Select feed speed between 5-8 and engage feed. Silencer should be nearest open side of drum. Pro-Cut disc silencers should also be used for rotor machining. PG / 800.543.6618...
Page 14
Always begin on the single dot corner and rotate clockwise to 2 dots, then 3 dots. On *premium plus cutting tips the first corner is the brand icon. *First side shows the Pro-Cut Brand Icon. DO NOT TURN THESE INSERTS OVER.
Page 15
SET-UP MODE SPINDLE MOTOR MUST BE OFF STATISTICS MODE SPINDLE MOTOR MUST BE OFF Set-up Mode: · Short Press < 3 seconds to enter Statistics mode. Set-up Mode: · Rotate to scroll through options and toggle · Long Press > 3 seconds to enter set-up mode. between choices between an option.
*Spherical Washer Set Sharp tools are vital to satisfactory operation. When ordering supplies or replacement parts for this machine, always give the model # and serial # of the machine. Use only Genuine Pro-Cut parts. PG / 800.543.6618 WWW.PROCUTUSA.COM PG /...
Page 17
50-4000 CABLES(NOT SHOWN) Bell Clamp PART ITEM NO. NUMBER 2.1/QTY. 50-4276 Arbor DISC INSTALLATION / Recommended Assembly 50-4025 36-4020 Spring 50-4218 Gooseneck LED power cable(Outside the E-box) 50-4009 Disc/Rotor 50-4059 Cone 37-4031 50-4277 50-4054 50-4275 50-4345 50-4099 50-4096 50-4063 50-1330 50-4279 Bell Clamp 50-4360...
Page 20
50-4360 ITEM PART QTY. NUMBER 50-4313 35-339 50-2154 50-2157 50-2159 37-4050 37-4034 50-4096 50-4325 35-4033 BOM Table 50-4194 ITEM NO. PART NUMBER QTY. Cables(Not Shown) 50-4097 50-4098 PART ITEM NO. DESCRIPTION QTY. NUMBER 35-4032 50-4200 Gooseneck LED power cable(Inside the E-box) 50-4205 20pin IDC cable 50-4206...
Page 21
50-4170 Cables(Not shown) item No. Part Number Description QTY. ITEM NO. PART NUMBER QTY. 50-4201 Rotary control cable 50-4171 50-4204 10pin to DB15 50-4274 50-2155 50-4221 Spindle start/stop button and cable 35-801 50-4222 Feed start/stop button and cable ITEM PART QTY.
Page 23
50-4279 Small Drum ITEM NO. PART NUMBER Capable/QTY. 50-4277 50-4005 50-4008 35-4020 50-4106 ITEM PART NUMBER QTY. 37-4024 50-4090 35-4006 37-4045 50-4024 50-4139 35-4026 36-4017 35-4057 37-4656 37-4655 PG / 800.543.6618 WWW.PROCUTUSA.COM PG /...
Page 24
SYSTEM ERROR MESSAGES SYSTEM ERROR MESSAGES TYPE / DESCRIPTION DISPLAY TEXT CAUSE CORRECTIVE ACTION TYPE / DESCRIPTION DISPLAY TEXT CAUSE CORRECTIVE ACTION Voltage measured from AC/DC power supply is Ensure adequate AC supply voltage. Feed Control PCB Drum feed motor drive IC Power cycle lathe.
Page 25
SYSTEM ERROR MESSAGES SYSTEM ERROR MESSAGES TYPE / DESCRIPTION DISPLAY TEXT CAUSE CORRECTIVE ACTION TYPE / DESCRIPTION DISPLAY TEXT CAUSE CORRECTIVE ACTION Plug in lathe and leave plugged in to charge Exception / Tcm Low/No For lathes equipped with a batter-backed disc this battery.
Page 26
SYSTEM ERROR MESSAGES NOTES DISPLAY TEXT CAUSE CORRECTIVE ACTION TYPE / DESCRIPTION Exception / Side Protective Door Operator has attempted to start feed motor Close side protective door then press feed side / door (repeats 3x) Warning while side protective door is not closed. start/stop button.
Page 27
MAINTENANCE SCHEDULE MAINTENANCE SCHEDULE DATE NOTES DRO READINGS DATE NOTES DRO READINGS MONTH / DAY / YEAR | HOURS | TOTAL DISCS | TOTAL DRUMS | MONTH / DAY / YEAR | HOURS | TOTAL DISCS | TOTAL DRUMS | PG / 800.543.6618 WWW.PROCUTUSA.COM...
