Before Use - Flymo MULTI-TRIM 200 Important Information Manual

Safety Guard Assembly (A), (B) & (C)
• If you have a Multi Trim 200 your safety guard
will be fitted with a wire guard as shown in
figure J2.
(A4)
Please note: Depending on which model you
have purchased, your trimmer may be fitted with
one line or two lines.
• ENSURE THE SAFETY GUARD IS SECURELY IN
PLACE BY ATTEMPTING TO TWIST GUARD (fig C).
J1-a - Line Cutter, J2-a - Line Cutter, J2-b - Wire Guard
If you have a Multi Trim 200, it will be fitted with a
wire guard as shown in figure J2. The wire guard is
not shown throughout the remaining instructions.
How the automatic line feed works (J). Please note:
Depending on which model you have purchased,
your trimmer may be fitted with one line or two lines.
DO NOT BE ALARMED this is
quite normal.
WARNING
The use of eye protection is recommended. Do not
lean over the trimmer whilst trimming or edging,
objects may be thrown by the cutting line. Do not
allow cutting head to rest on the ground. Do not
overload your trimmer. Overloading can be avoided
by making sure the motor speed does not drop
unduly. Disconnect from the mains electricity supply
before attempting any maintenance or adjustment.

BEFORE USE

Make sure that the line is fed out (if 2 lines are
fitted, make sure both are fed out). Make sure
motor is up to full speed before trimming or edging.
How to trim
(M)
ENGLISH - 2
SAFETY PRECAUTIONS
ASSEMBLY INSTRUCTIONS
(A2)
(A3)
fig A
Fig B
AUTO LINE FEED SYSTEM
HOW TO TRIM AND EDGE
See Fig L
Maintenance and storage
Steady Handle Assembly (D), (E) & (F)
D1 - Bolt, D2 - Handle Knob, D3 - Nut (if applicable)
(A1)
Height Adjustment (if fitted)
G1 - Height Adjust Knob
If your trimmer is fitted with Height Adjust, follow
the procedure below.
• Make sure the motor is up to full speed before
trimming or edging.
How to edge
See Fig N.
P .
Please note: Depending on which model you have
purchased, your trimmer may be fitted with a roller
or a skid plate.
D.
E
(fig G)
(fig H)
O
F
