OHIOSTEEL 4624V2 Manual

24 cu ft lawn sweeper
Hide thumbs

Advertisement

Table of Contents

4624V2
24 cu ft LAWN SWEEPER
U.S. Patent No. 7,610,646
READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT
6004864- REV A 12/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4624V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OHIOSTEEL 4624V2

Summary of Contents for OHIOSTEEL 4624V2

  • Page 1 4624V2 24 cu ft LAWN SWEEPER U.S. Patent No. 7,610,646 READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6004864- REV A 12/21...

  • Page 2: Safety Rules

    Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this tractor attachment.

  • Page 3: Warranty

    Paint that is worn or faded due to normal use or exposure. To arrange for product repair visit ohiosteel.com/customer-support and fill out the warranty repair form. You can also call 1-800-652-2321, ext. 212 to speak to our Customer Service Team This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state.

  • Page 4: Tools Required For Assembly

    Carton Contents (x1) 6 (x2) 7 (x4) 10 (x4) 11 (x1) 8 (x4) 9 (x4) 12 & 49 (x7) 13 (x1) 14 (x1) 15 (x1) 38 (x1) 40 (x2) 39 (x2) 37 (x2) 41 (x2) 42 (x1) 43 (x1) 44 (x1) 45 (x2) 50 (x1) 48 (x2)
  • Page 5 Assembly Instructions Attach Hitch Mount Tubes (6) to Sweeper Assembly and tighten hardware. DO NOT OVERTIGHTEN. Attach Hitch Cross Tube Assembly (13) by depressing snap buttons and insterting into Hitch Mount Tubes (34). Install Hitch Assembly (14) using tethered quick release pins in desired position on Hitch Cross Tube Assembly (13).
  • Page 6 Assembly Instructions First remove factory hand tightened nuts from studs. Use nuts to attach Height Adjustment Handle (15) Using a 9/16" Open End Box Wrench. Shown Installed: Insert Bottom Frame Tubes (39) into Center Frame Tube (41) and snap into position.
  • Page 7 Assembly Instructions Unroll and flatten hopper bag (38) from shipping state. Then, slide Hopper Stop Bar (42) into pocket of Hopper Bag as shown. First, place bottom frame assembly into bottom of Hopper Bag (38). Second, Install Clevis Pins (46) through Hopper Bag (38), Hopper Stop Bar (42), and Bottom Frame Tubes (39) then secure with Hairpins(49).
  • Page 8 Assembly Instructions First, Place top frame assembly into Hopper Bag (38). Second, Install Clevis Pins (45) through Top Frame Tubes (40) and Bottom Frame Tubes (39) and secure with Hairpins (49). Snap Button Down Slide Hopper Pivot Rod (43) through Top Frame Tube (40) and Connecting Tube (37), then through pocket of Hopper Bag (38), and then through both Connecting Tube (37) and Top Frame Tube (40) on other side.
  • Page 9 Assembly Instructions Unscrew Thumb Screw from Tension Tube Assembly (44). Next, Hold Hopper Bag (38) open and carefully insert Tension Tube Assembly (44) through opening in Hopper Bag and into hole in bottom Center Frame Tube (41). Pull top Center Frame Tube over tension tube and align holes.
  • Page 10 Assembly Instructions Insert Connecting Tubes (37) into Hitch Mount Tubes (6) and secure with Quick-Release Pins (48). Install Hitch Pin (11) and secure with Hairpin(12). Tie Dump Rope (50) securely around exposed section of Center Frame Tube(41). Do NOT fasten rope to any part of your body or clothing.
  • Page 11 Operating Instructions Before Using Lawn Sweeper: Read all Safety Rules found on page 1. How to Sweep Lawn: Remove large debris from lawn. Do not sweep if conditions are too wet or muddy. Attach Lawn Sweeper to tractor using supplied hitch pin. The reversable hitch allows the Lawn Sweeper to accomodate varying tractor hitch heights by fliping over;...
  • Page 12 Operating Instructions How to Adjust Brush Height: Place one hand on adjustment lever and use other hand to pull outward on plunger. Move handle downwards to lower the brush height or upwards to raise the brush height. Align the plunger with the nearest hole and release to select height setting. Offset Sweeping: Remove both pins from drawbar.
  • Page 13 Operating Instructions Storing Lawn Sweeper: Empty hopper bag and thoroughly clean Lawn Sweeper before storing. Store Lawn Sweeper away from excessive heat to prevent damage. Brushes must not contact ground during storage to prevent damage. Remove quick-release pins to separate hopper bag from Lawn Sweeper. Carefully remove tension tube and collapse hopper bag for compact storage.

  • Page 14: Repair Parts

    6003957-B2 HEIGHT ADJ. HANDLE 3000539-ZC 1/4" -20 X 1-1/4" BOLT 307241 WHEEL CAP 6002314 46" SPIRAL BRUSH 300081-ZC COTTER PIN, 1/8" X 1-1/2" 6000222-ZC SNAP BUTTON 3000721-ZC WASHER, 3/4" SAE 3000618-ZB NYLOCK NUT, 3/8-16 UNC ohiosteel.com/partsstore OHIO STEEL INDUSTRIES 1-800-652-2321...
  • Page 15 CLEVIS PIN, 1/4" X 1-1/4" BOTTOM FRAME TUBE 3/8" USS FLAT WASHER 6004344 TOP FRAME TUBE QUICK-RELEASE PIN 6004287-B2 CENTER FRAME TUBE HAIRPIN TENSION TUBE ASSEMBLY 307361 DUMP ROPE 6002318-B2 HOPPER PIVOT ROD 6000208-ZC SNAP BUTTON 6002316-B2 HOPPER STOP BAR ohiosteel.com/partstore OHIO STEEL INDUSTRIES1-800-652-2321...
  • Page 16 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL #4624 V2 2575 Ferris Road Columbus, OH 43224 (800) 652-2321 www.OHIOSTEEL.com (800) 652-2321...
