- Page 1 BATSEA320PROIP 3×20W LED Battery Powered WDMX IP65 Light ser manual...
-
Page 2: Technical Specification
TECHNICAL SPECIFICATION • 3 x 20W RGB + Lime Led • Optic 10° • 2300 Lux @5m / 10° • Wireless DMX • IR Remote control • DMX : 5/9/10ch • Auto / Static / WDMX/IRC Master-Slave /Audio/ • Dimensions : Ø x H: 120 x 155 mm •... - Page 3 YOKE + TOP HAT ACCESSORIES FILTER FRAME TOP HAT TOP TUBE (included) TOP BALL YOKE...
- Page 4 DISPLAY WIRELESS DMX RECEPTION INDICATOR RED Fixed: reception active Flashing: Waiting to receive CHARGING CONNECTOR ON / OFF SWITCH ADJUSTMENT SCREW...
- Page 5 WARNING! This is a product which has been developed for professional usage in event technology. It is not suitable as a houshold lighting. Don‘t use magnifiers or any other optical instrument to look at the be The effects of this device, expecially the stroboscope effect, can cause problems for sensitive people or may even cause epileptical seizures.
-
Page 6: Menu Structure
MENU STRUCTURE values are the default values DMX Address W-DMX Control Mode Auto01 Auto02 Auto03 Auto Mode Auto04 Auto05 Auto06 Auto07 Auto SP 000 > 100 - (50) Master Master/Slave Slave Sound 000 > 100% - (60) Operate Mode Dimmer 000-255 Strobe 000-255... -
Page 7: Dmx Address Menu
SoftwareV: 1.00 Green DMX Level Blue System info Lime Temp XX°C Operate T i me XXXH 00A6hXXXXX AFFICHEUR Menu : To exit active submenu. Enter : To enter the menu or confirm the active function or value. ˄ To scroll up in the menu or increase the value of the active function. ˅... -
Page 8: Channels Menu
˄ ˅ Choose the audio mode and adjust the audio sensitivity from 0 to 100 using the [ ] et [ ] keys then validate using the [ENTER] key. MASTER / SLAVE : • [MASTER] In this mode, The projector defines the W-DMX module as a transmitter and transmits the RGB Lime parameters to all the projectors connected to it. - Page 9 HOLD : ˄ ˅ Choose one of these two options to set the s behavior when losing the W-DMX signal using the [ ] et [ ] keys then validate using the [ENTER] key. • [ON] : keeps the last value in case of loss of the W-DMX signal •...
-
Page 10: White Balance Menu
• W-DMX SETTINGS ˄ ˅ using the [ ] et [ ] keys then validate using the Enter this submenu to configure Wireless DMX signal reception, [ENTER] key. • [LINK] Enter this submenu to pair the projector with the Wireless DMX transmitter. Switch the transmitter to pairing mode then activate the [LINK] mode on the projector by validating using the... - Page 11 DMX MAP 5 CHANNEL MODE DIMMER 000-255 000-255 GREEN 000-255 BLUE 000-255 LIME 000-255 9 CHANNEL MODE DIMMER 000-255 DIMMER FROM 0% TO 100% 000-005 NO STROBE 006-063 STROBE FROM SLOW TO FAST STROBE 064-191 STROBE LIGHTNING FROM SLOW TO FAST 192-255 RANDOM STROBE FROM SLOW TO FAST 000-005...
- Page 12 160-167 White 4500K 168-175 White 50 176-183 White 5600K 184-191 White 60 White 6500K 192-197 198-205 White 70 COLOR MACRO (CONTINUE) 206-213 White 7500 214-221 White 8000K 222-229 White 8500K 230-243 White 9000K 244-255 White 10000K 000-255 INTENSITY FROM 0% TO 100% GREEN 000-255 INTENSITY FROM 0% TO 100%...
- Page 13 160-167 White 4500K 168-175 White 50 176-183 White 5600K 184-191 White 60 White 6500K 192-197 198-205 White 70 COLOR MACRO (CONTINUE) 206-213 White 7500 214-221 White 8000K 222-229 White 8500K 230-243 White 9000K 244-255 White 10000K 000-255 INTENSITY FROM 0% TO 100% GREEN 000-255 INTENSITY FROM 0% TO 100%...
