Summary of Contents for TUYA WiFi Multi-function Door and Window Sensor

  • Page 1 WiFi Multi-function Door and Window Sensor...
  • Page 2 Meet the WiFi Multi-Function Door Sensor -seamlessly merging infrared sensing and real-time door/window status monitoring for complete home security coverage. With Alexa compatibility, effortlessly control the sensor via the app. It goes even further, supporting voice control and seamless integration with other Alexa devices for smart scene coordination.
  • Page 3 Aligning the magnet and sensor at the top Magnet Ensure that the two triangular arrows are on the same horizontal line Motion Sensor...

  • Page 4: Before You Start

    Before You Start 1. Activate Bluetooth 2. Connect to 2.4GHz WiFi: The device exclusively supports 2.4GHz WiFi networks.
  • Page 5 Download the“Smart Life”APP. Smart Life...
  • Page 6 Running the App: 1.Launch the "Smart Life" app from your smartphone's home screen. 2.Complete the registration and log in process. Note: Make sure to access your phone settings and enable notifications permission for the Smart Life app to receive notifications.
  • Page 7 Quick Setup Guide 1.Entering Configuration Mode: Press and hold the reset button for approximately 5 seconds until the infrared indicator on the device flashes red. Reset Button...

  • Page 8: Adding The Device

    2.Adding the Device: From the main page of the Smart Life app, tap on "Add Device" or the "+" icon to initiate the device addition process. Note: Make sure that Bluetooth is enabled during this step.
  • Page 9 3.Device Discovery and Connection: After your device is detected, tap on the "Add" button to start the connection process.
  • Page 10 Note: Ensure a stable network connection and that your network operates on the 2.4GHz frequency during the connection process.
  • Page 11 4.Successful Device Addition Upon successful connection, press the "Done" button to confirm the addition of the device.
  • Page 12 Upon successful connection, you can now view the status of the Multi-Function sensor and infrared components. Additionally, you can monitor the Multi-Function sensor's battery level and access the device's history records.
  • Page 13 5.Configuring Information Push Settings: To ensure you receive real-time alerts and updates, open the app's notification settings and configure them according to your preferences.
  • Page 14 Work with Alexa: Integrating Your Devices Step 1: Begin by downloading the Alexa app and navigating to the Devices section. Scroll to the bottom of this page to find "YOUR SMART HOME SKILLS" and click to enter.
  • Page 15 Step 2: Locate "Smart Life" and click "ENABLE TO USE."...
  • Page 16 Step 3: Access the Alexa and Smart Life account linking page. Click "Agree and link" to proceed.
  • Page 17 Step 4: Confirm the successful connection between your Alexa and Smart Life accounts.
  • Page 18 Step 5: Alexa will initiate the process of discovering and connecting to your Smart Life devices.
  • Page 19 Step 6: Alexa will identify two distinct components of the WiFi Multi-Function Door Sensor: the infrared and the door sensor.
  • Page 20 Step 7: Click on each component separately – the door sensor and the infrared – to add them and provide custom names.
  • Page 21 Step 8: All your devices are now successfully integrated into the Alexa app.
  • Page 22 The door/window sensor Keep track of real-time open and close states of the door.
  • Page 23 The infrared Monitor the latest detection records for each instance.
  • Page 24 Work with Alexa: Easy Smart Living After pairing Alexa and Smart Life, using the WiFi Multi-Function sensor becomes a breeze. Instant Access:Linked up, you can easily check door status, records, and control with taps or Alexa's voice commands. Hands-Free:Just ask Alexa for updates without lifting a finger.

  • Page 25: Installation

    Installation Follow these steps for a seamless setup: 1.Placement:Install the sensor on the door or window, and place the magnet on the door frame or window frame. Ensure that the gap between the sensor and magnet is less than 10mm when the door or window is closed.

  • Page 26: Safety Precautions

    Safety Precautions Prioritize safety during the installation of your sensor by being aware of potential risks and taking necessary precautions: Avoid Electrical Hazards: Turn off nearby electrical devices to prevent accidental shocks while working on the installation. Mind the Drilling: When drilling holes for installation, be cautious of potential hidden electrical wires, pipes, or gas lines within the walls.
  • Page 27 Scan QR Code to Activate Your Warranty...
