Summary of Contents for TUYA ZSS-S01-GWM-C
- Page 1 Instruction Manual Smart Door/Window Sensor Zigbee 3.0 English ZSS-S01-GWM-C-CG28...
- Page 2 Bitte scannen Sie den QR-Code, um das deutsche Handbuch, das Installationsvideo und die Funktion seinführung zu erhalten Escanee el código QR para obtener el manual en español, el video de instalación y la introducción de la función Veuillez scanner le code QR pour obtenir le manuel en français, la vidéo d'installation et l'introduction des fonctions Отсканируйте...
-
Page 3: Product Introduction
Product Introduction Smart Door/Window Sensor senses the opening and closing status of doors and windows by detecting the proximity and separation of magnets.Alarm information can be uploaded through Zigbee protocol in wireless IOT mode.Records can be uploaded to realise the security detection of the monitored objects. -
Page 4: Packing List
Packing List Door/Window Sensor *1 Battery *1 Product user manual *1 Double-sided sticker *2 Technical Parameters Model ZSS-S01-GWM-C Product Name Smart Door/Window Sensor Wireless Connection Zigbee Support Low Battery Alarm Operating Temperature -10°C ~ +50°C Alarm Trigger Distance 20±5mm Battery Specifications... -
Page 5: Installation Instructions
Installation Instructions The product can be applied to the door, window and other scenes, please install the host and the magnet separately on the fixed door frame or window, as shown in the following figure. Mounting position for reference only (Use Double-sided sticker for fixing) Do not install outdoors, on a weak foundation, or in a location subject to rain. -
Page 6: Preparation For Use
Preparation for Use 1.Download Smart Life APP Please scan the QR code or download Smart Life on App store 2.Register or Log in Download“Smart Life”Application Enter the Register/Login interface; tap “Register”to create an account by entering your phone number to Region get verification code and“Set Mobile number/e-mail address... -
Page 7: Add Device
Add device 1. 1. Slide the rear cover towards the direction of the arrow, remove the rear cover, then remove the insuation sheet and finally reinstall the rear cover. Insulation Sheet Remove insulation sheet to power on the sensor. English... - Page 8 2. Open the MOES APP, make sure the ZigBee gateway/multimode gateway is connected to the APP, enter the gateway and click “Add New Device". English...
- Page 9 3. Enter configuration mode ①Press and hold the “button" for more than 6 seconds until the white indicator light flashes quickly, and the sensor enters pairing mode. (Note: When configuring the network, please make the device as close as possible to the gateway.) ②If the network configuration fails, press and hold the device button again until the white light flashes quickly, and repeat the above operations.
- Page 10 4. Wait for 10-120 seconds. After adding the device successfully, you can edit the device name. English...
- Page 11 5.Now you can set “smart scene linkage" according to your needs and enjoy your smart home life. English...
- Page 12 Restriction of elements or element identification tables Toxic and hazardous substances or elements Dioxydiphenylether Hexavalent Lead Mercury Chromium motto diphenyl phenyl ether Part Name (Cr(VI)) (Hg) (Cd) (PBB) (Pb) (PBDE) Circuit Board Housings and other components This form has been prepared in accordance with the provisions of SJ/T 11364.
