- Page 3 Great Data Makes Golf, Easy. The LaunchBox is your new favorite go-anywhere, do-everything golf tool designed to make it easier than ever to Play, Improve, and Enjoy your game. LaunchBox is a photomatric launch monitor that uses high speed cameras to capture every aspect of every swing, so you can get all the data you need to play better, smarter golf - indoors and out.
-
Page 4: Table Of Contents
Contents Device Overview Connect LaunchBox Ready Zone 8-11 LaunchBox Placement Other Settings Power Status Tips For Use Device Specifications CONTACT CUSTOMER SUPPORT Monday-Friday 9:00 am - 5:00 pm MST Toll Free: 877-711-6691 Direct: 801-677-1123 http://trugolf.com/support... -
Page 5: Device Overview
Device Overview... -
Page 6: Led Status Display
Device Overview LED Status Display LED Color Status LaunchBox is in Processing/Setting Blue Light state. LaunchBox is waiting for a golf ball in the Red Light Ready Zone. LaunchBox detected a ball in the Ready Zone, Green Light ready for a shot. -
Page 7: Navigating Menus
Device Overview Powering Device On/Off To switch your LaunchBox on or off, press and hold the Power Button for 3 seconds. The LED will turn red. Navigating Menus 1. Turn on LaunchBox. 2. Press the Menu Button to switch between Settings Menus. -
Page 8: Modes Of Play
Device Overview Modes of Play Online Mode: Connect LaunchBox to PC or Mobile to dis- play shot information inside a chosen application. Offline Mode: Display shot information only on your LaunchBox screen. Select Your Play Mode Press the Menu Button to open the Settings Menu and navigate to Play Mode Settings. -
Page 9: Connect Launchbox
Connect LaunchBox Pair LaunchBox to your PC or Mobile Device in 2 ways. -Wi-Fi Direct Mode -Ethernet Dynamic Mode Note: LaunchBox must be set to Online Mode before connecting. Wi-Fi Direct Connection LaunchBox emits a private Wi-Fi Network that allows other devices to connect to it. - Page 10 Connect LaunchBox Ethernet Dynamic Mode Pair your LaunchBox with a PC or Mobile device by using an Ethernet cable to connect LaunchBox to a router. When LaunchBox is connected to your router, you will retain normal internet access with your PC or Mobile device.
- Page 11 Connect LaunchBox Using LaunchBox with E6 Once LaunchBox is successfully connected to your PC or Mobile Device, you can use LaunchBox with E6 Software for an enhanced golf simulation experience. Pairing Instructions: 1. Launch E6. 2. Enter the Settings Menu.
-
Page 12: Ready Zone
Club Mode Setting: Select a Club Type to change the valid Ball Placment Area accoringly. Position LaunchBox: For the best play experience, position your LaunchBox such that when you place a ball in the READY ZONE it is aligned with the center-point of your target. - Page 13 Before hitting a shot, the ball must be placed in a fixed zone called the READY ZONE: - Dimensions: 4” x 8” - For best results, position your ball approximately 17.5” from the front of the LaunchBox. Right Handed Golfer Left Handed Golfer...
- Page 14 Ready Zone All Club: Allows users to play every shot from anywhere inside the entire Ball Placement Area. Driver Club: Users must play their shots from a READY ZONE in the Ball Placement Area that is optimized for driver. Iron/Putter Club: Users must play their shots from a READY ZONE in the Ball Placement Area that is optimized for irons and putters.
- Page 15 Ready Zone READY ZONE Display LaunchBox is working to detect the ball in the READY ZONE. LaunchBox detected the ball in the READY ZONE, and is ready for a shot. The golf ball is outside of the READY ZONE. Move the ball into the valid Ball Placement Area.
-
Page 16: Launchbox Placement
LaunchBox Placement LaunchBox needs to be placed on a level surface in order to function properly. The display will warn you if the device is tilted. The height of the surface where LaunchBox is placed and the height of the mat must be equal.* * If there’s a large difference between the mat height and the height... -
Page 17: Other Settings
Spin Display: Choose your preferred Spin Parameters. Sound: Enable or disable sound when using the device. When sound is enabled, LaunchBox gives an auditory cue when the ball is detected in the READY ZONE, and again when a shot has been successfully registered. -
Page 18: Power Status
Power Status Icon Status 25% Charged 50% Charged 75% Charged 100% Charged Charging Fully Charged... -
Page 19: Tips For Use
3. Use a clean, white ball with a logo or a marked line. Set the ball up with the logo or line facing your LaunchBox to capture accurate spin data. 4. If for any reason your LaunchBox enters a stuck or unresponsive state, tilt the device until the screen displays “The Device is Tilted”. -
Page 20: Device Specifications
Device Specification Product Name: LaunchBox Sensor Type: Camera Screen: 4.2” E-ink Screen, 170 Viewing Angle Supported OS: iOS & Windows Connection Method: WiFi or Ethernet Dimensions: 9.53” x 7” x 5”, 2.7 lb Power Supply: 5V-4A Adapter Measured Parameters: Ball Speed, Launch Angle, Back... - Page 24 TruGolf.com...
