Page 2
Congratulations on your purchase of a TruGolf simulator! We are cords, power supplies before use. If the product is damaged DO NOT thrilled to have you as part of our team. Throughout the years, TruGolf’s USE and contact TruGolf. simulators have been used in country clubs, training facilities, sports •...
Page 3
ANY DAMAGE OR INJURY CAUSED BY FAILURE TO FOLLOW THESE or lack of experience and knowledge, without supervision GUIDELINES. IN NO EVENT WILL TRUGOLF BE LIABLE FOR ANY and instruction concerning use of the simulator by a person SPECIAL, INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES responsible for their safety.
We suggest you watch a few videos before or during setup to help you assemble your Vista 8 Golf Simulator. Setup Assistance..................1 Frame Diagram ..................2 Visit: https://trugolf.com/vista-setup Assemble Frame ..................4 Enclosure ....................8 Wiring ....................13 Computer Components Diagram ............16 Overhead Light Instructions ............18 Clone Displays ...................19...
TRUGOLF VISTA 8 ASSEMBLE FRAME STEP 4 | TOP CORNER PIECES Assemble the top portion of the frame. Connect corners to the sides, then insert the top frame pieces between the corners as shown below. Tighten STEP 1 | CORNER PIECES elbow pieces using the supplied allen wrench.
Page 7
TRUGOLF VISTA 8 STEP 7 | SIDES AND TOP Assemble the walls as shown below. Tighten elbow pieces using the supplied allen wrench. Attach the remaining bungee cord to the frame. Start from the center moving out to the corners. Stretch bungee cord up and onto the INSIDE KNOBS to create a zigzag pattern.
TRUGOLF VISTA 8 ENCLOSURE STEP 2 | TOP BUNGEES Once the top sides have been attached, continue securing the enclosure back edge to the frame using the integrated bungee system. STEP 1 | TOP TIP: This is done in a similar fashion used to attach the screen.
Page 9
STEP 3 | AWNING Attach the BRIM and the TRUGOLF BANNER to the top front edge of the simulator using the integrated Velcro. Start at the middle of the banner, attaching it around the LIGHT BAR [27], then move towards the sides.
TRUGOLF VISTA 8 WIRING STEP 4 | SIDE BAFFLES & NETS Attach the SCREEN BAFFLES to the SIDE WALLS using the integrated Velcro. Next, attach the SIDE NETS to the front outside edge of the SIDE WALLS. STEP 1 | CABLES Fill WEIGHT BAGS with heavy material and connect to SIDE NETS.
Page 11
STEP 5 | PROJECTOR COVER Plug COVER FANS into POWER STRIP. Place COVER over projector. NOTE: Do Not scratch projector lens with projector cover. TruGolf will not replace projectors with scratched lens. STEP 3 | HITTING MAT Connect the RIBBON CABLE on the HITTING MAT to the TRUTRACK CONTROL BOX.
TRUGOLF VISTA 8 COMPUTER COMPONENTS DIAGRAM Connect USB Devices to any available USB PORT. Connect MONITOR • Mouse to COMPUTER using • Keyboard both a USB and DVI CONNECTION TO CLONE IMAGE ON DISPLAYS SEE PG 19 Connect COMPUTER to PROJECTOR using HDMI or other available CONNECTION.
TRUGOLF VISTA 8 OVERHEAD LIGHT INSTRUCTIONS CLONE DISPLAYS There are two methods to set up multiple monitors in Windows 7. Make INSTALLATION sure that you connect the external monitors to your laptop or your desktop 1. Push the top portion of the head adapter into the slot of the track computer first.
TRUGOLF VISTA 8 BALL PLACEMENT: FULL SHOTS TROUBLESHOOTING DRIVER, WOODS, HYBRIDS & IRONS ERROR MESSAGE “No TruTrack system was found. Please ensure the system is plugged in.” Do the following: 1. Check all connections on TruTrack Hitting Mat. 2. Check that the TruTrack Power and Ground Cables are plugged in.
TRUGOLF VISTA 8 DIAGNOSTICS ACOUSTIC SENSORS There are three acoustic ball impact sensors (see page 13). Tap each sensor To run Diagnostics: to verify each one is connected correctly. A sensor may be unresponsive if: 1. Open E6 CONNECT. 1. Microphone is not connected to the cable.
