- Page 1 S T A R T E R 1 0 Assembly Guide...
- Page 2 The Road to Better Golf Starts Here! In this guide, you will find everything you need to complete the assembly of your new STARTER 10 Simulator. You will also find a few helpful installation tips and tricks that will ensure that you have the best possible experience.
- Page 3 TABLE OF CONTENTS SPECS & SAFETY WHAT’S INCLUDED FRAME & ENCLOSURE ASSEMBLY 4-16 OVERHEAD MOUNTING...
- Page 4 SPECIFICATIONS Name Product Starter 10 Enclosure Enclosure (H) 8’4” x (W) 10’10” x (D) 13’7” sions Dimen A step-stool or ladder, as well as help from an additional Recommendations person, will be needed during assembly. 117 LBS. Weight Black Skins & Frame.
- Page 5 - When not in use, store neatly in a cool, dry location, that’s protected from weather elements and direct sunlight. - TruGolf is not responsible for any damage to property and/or any personal injury. - During assembly, check that all enclosure components are well fit and fastened to prevent loosening during use.
- Page 6 WHAT’S INCLUDED STARTER 10 ENCLOSURE (18) COLOR CODED SNAP-BUTTON POLES (1) STARTER 10 PREMIUM IMPACT SCREEN (1) BLACK NYLON SURROUND (4) FOAM PADDING STRIPS (2) L-SHAPED CONNECTORS (6) 3-WAY CONNECTORS (80) BALL BUNGEES...
- Page 7 FRAME ASSEMBLY Lay out poles and connectors. Organize by color. (4) PURPLE poles with a single stripe on one end and double stripes on the opposite end. (4) BLUE poles with single stripes on both ends. (3) YELLOW poles with single stripes on one end and double stripes on the opposite end.
- Page 8 FRAME ASSEMBLY (4) GREEN poles with single stripes on both ends. (3) ORANGE poles with single stripes on both ends. TIP: In the following steps, you will connect the GREEN single stripe end to the connector pieces. You will connect the ORANGE single stripe ends to the YELLOW double...
- Page 9 FRAME ASSEMBLY Assemble the back lower poles first. Attach a YELLOW pole to an ORANGE pole. After, attach a 3-way connector to each end. REMEMBER: Connect the double striped end of the YELLOW pole to the single striped end of the ORANGE pole.
- Page 10 FRAME ASSEMBLY Connect (4) BLUE poles to the corner connectors that will act as bottom uprights for the structure. TIP: At this point in the assembly, make sure button snaps are fully engaged in each fitting. Also, this would be a good time to place the structure near its final location due to the added weight of the screen and skin in future steps.
- Page 11 FRAME ASSEMBLY Connect (4) PURPLE poles to the BLUE uprights to complete the vertical assembly. Next, attach the (4) remaining 3-way connectors to the open ends of the PURPLE poles.
- Page 12 FRAME ASSEMBLY Starting with the back section, attach (1) ORANGE pole to the back-right 3-way connector. Then attach (1) YELLOW pole to the ORANGE pole and that YELLOW pole to the back-left 3-way connector. Repeat these same steps for the front facing upper section.
- Page 13 FRAME ASSEMBLY To complete the frame structure, attach the (2) remaining GREEN poles to the open 3-way connectors at the top.
- Page 14 ENCLOSURE ASSEMBLY In this section, you will attach the black skin and the white impact screen to the frame. You will need a ladder and an additional person to assist with the following steps. Unfold the black skin and position it around the outside of the frame.
- Page 15 ENCLOSURE ASSEMBLY Unfurl the black skin, bring it over the top of the GREEN pole, and hang the skin across the structure so it drapes over the opposite GREEN pole and down the opposite side of the frame. Once the black skin is in place, remove the velcro cover strips and begin wrapping the skin’s panels...
- Page 16 ENCLOSURE ASSEMBLY TIP: Connect the bottom flaps of the black skin first. Start by sliding the lowest inside flaps of the skin under the bottom poles and then folding them back up and fastening them in place to the velcro strip. Once the entire black skin has been fastened in place using the velcro strips, finish...
- Page 17 ENCLOSURE ASSEMBLY TIP: Before handling the impact screen, wash your hands thoroughly to avoid blemishes or stains on the white material. Make sure the floor is clean too! Begin by using (4) bungee balls to attach the screen to the four corners. Thread the bungee cords through the grommet holes in the screen, then wrap them around the pole.
- Page 18 ENCLOSURE ASSEMBLY The (4) foam pads can now be added to the enclosure. There are (2) long pads that attach to the velcro along the top and bottom of the screen, and (2) shorter pads that attach to the two vertical sides of the screen.
- Page 19 ENCLOSURE ASSEMBLY Your new Starter 10 Enclosure is now complete! Congratulations!
- Page 20 SHEET #: THESE DRAWINGS OR ANY PARTS THEREOF, AS INSTRUMENTS OF SERVICE, REMAIN THE PROPERTY OF TRUGOLF DESIGN GROUP AND MAY NOT BE REPRODUCED OR USED ON OTHER WORK WITHOUT WRITTEN CONSENT *For APOGEE mounting instructions please refer to the...
- Page 21 STARTER 10 ENCLOSURE PLAY, IMPROVE, ENJOY! We stand by all of our products, so if you’re not 100% satisfied, please contact our U.S. Based Support Team so that we can make it right. TRUGOLF.COM/SUPPORT Direct: (801) 677-1123 Toll-Free: (877) 711-6691...
- Page 24 TruGolf.com (877) 711-6691...
