- Page 1 ZUMA ZUMA USER / INSTALLER'S MANUAL v1.4 REV. 07/2024...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX This product is certified in accordance with European Community (EC) safety standards. 01. SAFETY INSTRUCTIONS This product complies with Directive 2011/65/EU of the European 02. AUTOMATISM Parliament and of the Council, of 8 June 2011, on the restriction TECHNICAL CHARACTERISTICS of the use of certain hazardous substances in electrical and INSTALLATION COMPONENTS... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can... -
Page 4: Warnings For Users
01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse. -
Page 5: Automatism
02. AUTOMATISM 02. AUTOMATISM TECHNICAL CHARACTERISTICS DIMENSIONS SPAT FIXO ZUMA is an electromechanical barrier developed to control vehicle access to private, industrial or • commercial areas. Automatism technical specifications: ZUMA 4 ZUMA 6 ZUMA 8 • Operating power 150W 200W •... - Page 6 02. AUTOMATISM DIMENSIONS ZUMA 4 / ZUMA 6 ZUMA 8 • • 220mm 132mm 450mm 416mm 370mm 370mm 300mm 270mm...
-
Page 7: Remove The Door 6A
02. AUTOMATISM 02. AUTOMATISM REMOVE THE DOOR MANUAL OPENING / CLOSING This barrier allows free access to the interior, to facilitate the installation and maintenance process of In case of an emergency or during the installation/adjustment phase of the barrier, it may be the product. -
Page 8: Installation
03. INSTALLATION 03. INSTALLATION INSTALLATION MAP FOUNDATION • CREATE FOUNDATION Make a hole 400mm (or greater) in depth and with the following measurements: ZUMA 4 | ZUMA 6: 370(A) x 470(B)mm; ZUMA 8: 400(A) x 550(B)mm. Fill with concrete and smooth the top. Apply the barrier to the foundation, with the fixing bolts in place, to ensure they are securely fixed (see page 8). -
Page 9: Automatism Installation
03. INSTALLATION AUTOMATISM INSTALLATION Assemble the nuts and bolts in the center of the holes in the base of the barrier as shown in the • ADJUST BARRIER POSITION drawing. *Once fixed to the ground, the ZUMA is prepared to allow a position adjustment of a few Check that the foundation is perfectly level millimeters. -
Page 10: Spring Position 9A
03. INSTALLATION 03. INSTALLATION SPRING POSITION AMOUNT OF SPRINGS • BOOM ON THE LEFT (SX) • BOOM ON THE RIGHT (DX) • ZUMA 8 (3 SPRINGS) • ZUMA 6 (2 SPRINGS) • ZUMA 4 (1 SPRING) ADJUSTMENT: ADJUSTMENT: ADJUSTMENT: • 2xM8 on top (joint bearing plate) •... -
Page 11: Installation Of Springs (Zuma 4 / Zuma 6)
03. INSTALLATION INSTALAÇÃO DAS MOLAS CHANGE FROM 2 TO 1 SPRING • If the springs are on the wrong side for the intended *If, due to the size of your boom, there is a need to remove boom direction (see diagram on page 9A), you must a spring, proceed as follows: reverse the position of the springs on the rotation lever. -
Page 12: Boom Assembly (Zuma 4 / Zuma 6)
03. INSTALLATION BOOM ASSEMBLY (ZUMA 4 / ZUMA 6) CHECK BOOM SUPPORT POSITION • A • Fit the boom support taking into account the information presented in the board on the left. B • Tighten the side screws to secure the support to the shaft. - Page 13 03. INSTALLATION 03. INSTALAÇÃO INSTALLATION OF SPRINGS (ZUMA 8) BOOM ASSEMBLY (ZUMA 8) Follow the instructions indicated on page 10 and making the association with the numbers in the Follow the instructions indicated on page 11 and making the association with the numbers in the drawing below, proceed with the installation of the springs in the ZUMA 8.
-
Page 14: Boom Mounting - S5 And S6
03. INSTALLATION 03. INSTALAÇÃO BOOM MOUNTING - S5 AND S6 BOOM MOUNTING - A5 AND A6 Apply the same steps from page: Apply the same steps from page: • 10 e 11 - to the ZUMA 4 and ZUMA 6 boom; •... -
Page 15: Fixing Boom Supports
03. INSTALLATION FIXING BOOM SUPPORTS • DEFINE EXTENDABLE BOOM LENGTH • ADJUST SUPPORT (FIXED) HEIGHT If the height of the support arm is not adjusted to the height of the boom, you will need to adjust the You must now establish the length of it so that you can then place the support, as shown in the height of the arm. -
Page 16: Adjustment Of The Booms
03. INSTALLATION ADJUSTMENT OF THE BOOMS • ADJUST A5 AND A6 MOBILE SPAT • ADJUST S5 AND S6 BOOM • ADJUST A5 AND A6 BOOM If the floor is uneven or you want to adjust the edge Turn the crank (highlighted below) if you want to Turn the crank (highlighted below) if you want to height, you will need to adjust the floor stopper. -
Page 17: Adjust The Springs
03. INSTALLATION ADJUST THE SPRINGS Before adjusting the springs, manually place the boom in the vertical position so that the springs are in Hold the threaded rod with a pliers so that the position of least tension (see page 6B). it does not rotate, and keep tightening the adjusting nut until each spring is stretched the distance mentioned in the table on page 17. -
Page 18: Adjustment Tables
03. INSTALLATION ADJUSTMENT TABLES • LEVER HOLES • Depending on the condition of the spring, there may be a tolerance of 5mm in relation to the values NOTE: For S5, A5, S6 e A6 models, you should use the values indicated in the table. -
Page 19: Test Spring Adjustment
03. INSTALLATION 03. INSTALLATION TEST SPRING ADJUSTMENT POWER SUPPLY CABLE *The power wiring from the ground must be connected directly to the fuse located at the The motor must remain unlocked to carry out the adjustment test. bottom of the barrier. Pass the power cables coming from the ground to the fuse. -
Page 20: Limit Switches Adjustment
03. INSTALLATION 03. INSTALLATION LIMIT SWITCHES ADJUSTMENT The stoppers present on the barrier are visible in the image below. The ZUMA rotation lever has limit switch micros that allow you to define the end of the opening and • They consist of 2 adjusting screws (one on each side of the barrier) fixed to the base as well as its 2 closing operations. -
Page 21: Connections
04. CONNECTIONS CONNECTION SCHEME (ZUMA 4 / ZUMA 6) • MC60 Control board (inside of the barrier) LAMP MOT1 • Safety edge (Optional) LAMP MOT1 BATT • Photocells • Transformer 230Vac/115Vac 120W Max. COM NC/ • MP105 Flashing light • Limit switches (Opcional) •... - Page 22 04. CONNECTIONS CONNECTION SCHEME - THTSIG15LEDN MODULE (ZUMA 8) • MC60 Control board (Inside of the barrier) • Module THTSIG15LEDN • Power supply 12V+ GI RGI LAMP MOT1 BATT • Transformer 230Vac/115Vac 120W Max. • Twilight sensor • Photocells • Fuse •...
- Page 23 04. CONNECTIONS CONNECTION SCHEME - MODULE MP106 (ZUMA 8) • MC60 Control board (inside of the barrier) • The battery must be removed from the RG B LAMP MOT1 equipment before disposal. BATT • The equipment must be disconnected • MP106 Module from the power supply when the battery is removed.
-
Page 24: Troubleshooting
05. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS / SPECIALIZED TECHNICIANS Anomaly Procedure Behavior Procedure II Find out the origin of the problem • Barrier • Make sure you have • Still not working • Consult a specialized 1 • Remove the frontal door from A) It has 24V: diagnosis and repair.
