- Page 1 MOTIZA MOTIZA USER / INSTALLER'S MANUAL v1.0 REV. 05/2023...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. AUTOMATISM TECHNICAL CHARACTERISTICS This product complies with Directive 2011/65/EU of the COMPATIBLE COMPONENTS European Parliament and of the Council, of 8 June 2011, on LOCK / UNLOCK AUTOMATISM the restriction of the use of certain hazardous substances in electrical and electronic equipment and with Delegated... - Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
- Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
- Page 5 02. AUTOMATISM 02. AUTOMATISM TECHNICAL CHARACTERISTICS COMPATIBLE COMPONENTS Motiza is an electromechanical barrier, developed with the aim of controlling vehicle access • Control board to private, industrial or commercial areas. inside Automatism technical specifications: • MF30 Photocells MOTIZA 5 • Power 150W •...
-
Page 6: Installation
Unlock automatism Insert the unlocking key into the automatism, and turn it 180° in direction "D" to unlock it. 1 • MOTIZA 2 • Boom 3 • Boom Extension 4 • Photocell support column D • Motor Unlocked 5 •... -
Page 7: Automatism Installation
03. INSTALLATION AUTOMATISM INSTALLATION CREATE FOUNDATION • ADJUST BARRIER POSITION • Drill a hole of 350x460mm and 400mm *Once fixed to the ground, the barrier is prepared to allow a position adjustment of a few (or greater) deep to create the fixing degrees. -
Page 8: Boom Position
03. INSTALLATION 03. INSTALLATION BOOM POSITION INVERT BOOM POSITION BOOM ON THE LEFT BOOM ON THE RIGHT (Standard) * • • If the motor and spring are on the opposite side as intended, according to the diagrams on the left page, you should change the position of these components before placing the boom in the barrier. - Page 9 03. INSTALLATION INVERT BOOM POSITION INVERT MOTOR APPLY SPRINGS • • Unlock the motor (page 5B). Loosen the screw that secures the motor tip to the lever, as well as the washers and nuts. Retighten the motor tip to the lever in one of the holes on the other side with the same screw, washers and nut.
-
Page 10: Boom Mounting
03. INSTALLATION BOOM MOUNTING REVERSE BOOM SUPPORT • Fit the remaining pieces in the order shown in the picture. Fix the parts to the boom fixing plate with the screws provided in the package. STRETCHED MOTOR RETRACTED MOTOR • Vertical Plate •... -
Page 11: Fix Boom Support (Optional)
03. INSTALLATION FIX BOOM SUPPORT (OPTIONAL) SET EXTENDING BOOM LENGTH ADJUST SUPPORT (FIXED) HEIGHT • • If the height of the support arm is misaligned to the height of the boom you will have to adjust the arm Start by establishing the length of the boom so that you can then place the support, as visible in height. -
Page 12: Adjust The Springs
03. INSTALLATION ADJUST THE SPRING Before adjusting the spring, manually place the boom in the vertical position (motor extended) so that Hold the threaded rod with pliers to prevent it the spring is in the lowest tension position, and lock the motor in this position. from turning, and keep tightening the adjusting nut until the spring is stretched by the distance mentioned in the table on page 12A. -
Page 13: Adjusting Tables
03. INSTALLATION 03. INSTALLATION TESTING SPRING ADJUSTMENT ADJUSTING TABLES LEVER HOLES • The motor must remain unlocked to perform the tuning test. Hole 2 Hole 1 Hole 1 Hole 2 5000 4500 4000 3500 Hole: Hole 2 Hole 2 Hole 1 Hole 1 SPRING 23 mm... -
Page 14: Tuning Stoppers And Limit Switches
03. INSTALLATION TUNING STOPPERS AND LIMIT SWITCHES ADJUST THE MECHANICAL STOPPERS TUNE THE ELECTRICAL LIMIT SWITCHES • • The mechanical stoppers present in the barrier are visible in the image below. The electrical limit switches present on the barrier are visible in the image below. •... -
Page 15: Power Cable
03. INSTALLATION 04. CONNECTIONS POWER CABLE CONNECTION SCHEME *The barrier frame has a tube located on the inside so • Control board that it can conduct power wiring to the connectors (top (Barrier Interior) of the barrier). Pass the power cables coming from the ground through the pipe. -
Page 16: Troubleshooting
05. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS / SPECIALIZED TECHNICIANS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem 1 • Remove the barrier top cover; 2 • Measure the 24V output of the transformer to detect the fault location; •...
