Transcell Technology TI-1500 Series Setup & Operation Manual

Digital indicator
Hide thumbs Also See for TI-1500 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
TI-1500 Series
Digital Indicator
Setup / Operation Manual
Revision 1.6
March 15, 2005
© 1999-2005 Transcell Technology, Inc.
Contents subject to change without notice.
Transcell Technology, Inc.
975 Deerfield Parkway
Buffalo Grove, IL 60089
Tel (847) 419-9180
Fax (847) 419-1515
E-mail:
transcell@transcell.net
Web:
www.transcell.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TI-1500 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transcell Technology TI-1500 Series

Summary of Contents for Transcell Technology TI-1500 Series

  • Page 1 TI-1500 Series Digital Indicator Setup / Operation Manual Revision 1.6 March 15, 2005 © 1999-2005 Transcell Technology, Inc. Contents subject to change without notice. Transcell Technology, Inc. 975 Deerfield Parkway Buffalo Grove, IL 60089 Tel (847) 419-9180 Fax (847) 419-1515 E-mail: transcell@transcell.net...
  • Page 2 NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause harmful interference to radio com- munications.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Page Chapter 1: Introduction To The TI-1500 Series Indicators.............. 1-1 Chapter 2: Installation ........................2-1 ABS Enclosure (TI-1500) ....................2-1 2.1.1 Connecting the weigh platform................. 2-1 2.1.2 Connecting the serial printer, remote display or computer ......2-2 2.1.3...
  • Page 4 C hapter 5: User Menu Descriptions and Procedures ..............5-1 User Menu Descriptions....................5-1 User Menu Procedures ....................5-2 5.2.1 ID Number Entry (A5)..................5-2 5.2.2 Line Feeds Entry (A6) ..................5-3 5.2.3 Time Entry (A10) ....................5-3 5.2.4 Date Entry (A13)....................5-4 C hapter 6: Calibration ........................
  • Page 5 Cable Diagram for Indicator to Printer ..................B-3 Consolidated Controls Continuous Mode ................B-3 LIST OF TABLES TI-1500 Series Product Matrix ....................1-1 Invalid Setup Selections for commercial applications............. 4-3 Calibration Value Table......................6-2 TI-1500 Series Annunciator Definitions .................. 7-1...

  • Page 6: Chapter 1: Introduction To The Ti-1500 Series Indicators

    8-350Ω load cells. All setup parameters may be entered via the front panel keys, including calibration. If your Model TI-1500 Series Digital Indicator is part of a complete floor scale or has been in- stalled for you, you may skip to Chapter 7 for operating instructions. Prior to using the indicator, please read this chapter carefully and completely.

  • Page 7: Ti-1500 Front Panel

    GROSS TARE ZERO STABLE III / III L ⌧ ZERO TARE PRINT UNITS GROSS MODEL TI-1500 FIGURE 1-1: TI-1500 Front Panel Page 1-2...

  • Page 8: Chapter 2: Installation

    CHAPTER 2: INSTALLATION ABS ENCLOSURE (TI-1500) For indicators contained in the standard ABS enclosure, the rear panel contains all connectors necessary to make the appropriate connections to the weigh platform, printer, remote display and power supply. LOAD CELL DC Jack Port Serial Port...

  • Page 9: Connecting The Serial Printer, Remote Display Or Computer

    2.1.2 CONNECTING THE SERIAL PRINTER, REMOTE DISPLAY OR COMPUTER The TI-1500 series indicator comes standard with two serial ports, designated COM1 and COM2. COM1 is a full duplex, RS-232 port designed for connection to either a PC or a serial printer.

  • Page 10: Stainless Steel Enclosure (Ti-1520)

    STAINLESS STEEL ENCLOSURE (TI-1520) For indicators contained in a stainless steel enclosure, the rear cover must first be removed to make the appropriate connections to the weigh platform, printer, remote display and power supply. o remove the rear cover, simply remove the screws that secure it to the enclosure and set aside. NOTE: The rear cover must remain off to access the Setup Menu and calibration procedures.

  • Page 11: Connecting The Weigh Platform

    2.2.2 CONNECTING THE SERIAL PRINTER, REMOTE DISPLAY OR COMPUTER The TI-1500 series indicator comes standard with two serial ports, designated COM1 and COM2. COM1 is a full duplex, RS-232 port designed for connection to either a PC or a serial printer.

  • Page 12: Connecting The Power Supply

    2.2.3 CONNECTING THE POWER SUPPLY 1. The indicator ships standard with an internal AC to DC adapter. Simply plug the AC line cord into a standard wall outlet. 2. If the indicator was shipped with the optional external AC adapter, simply plug the AC adapter into the indicator’s DC Power Jack first, and then plug into a standard wall outlet.

  • Page 13: Chapter 3: Configuration

    CHAPTER 3: CONFIGURATION CONFIGURATION OVERVIEW The indicator contains two main setup menus: The Setup (“F”) menu which configures the indicator to your weigh platform and the User (“A”) menu which configures the serial communication port and enables some user options. The Setup and User menus consist of several menu selections, each with its own sub-menu of choices.

  • Page 14: Navigating In The Setup Menu

    3.2.3 NAVIGATING IN THE SETUP MENU Use the directional keys shown in Figure 3-1 to move around in the Setup Menu Chart shown in Figure 3-2 on the following page. To move to a new “F” heading, use the TARE (left) or PRINT (right) key to move right or left in the Setup Menu Chart.

  • Page 15: Notes On The Setup Menu

    3.2.4 NOTES ON THE SETUP MENU 1. There is an F21 sub-menu present that is for FACTORY USE ONLY! 2. Detailed descriptions of the setup menu parameters can be found in Chapter 4 of this manual. 3. The User (“A”) menu sub-menus appear when scrolling left or right from the “F” menu. 3.2.5 EXITING THE SETUP MENU –...

  • Page 16: User Menu Key Assignments

    To view the available selections for the current “A” heading, use the TARE (left) or PRINT (right) key to move through the selection field. To save a new selection, press the NET/GROSS (Set) key .To exit without saving, press the UNITS (up) key to return to the current “A” heading. Repeat Steps 2 through 5 until the User Menu is programmed.

  • Page 17: Notes On The User Menu

    3.3.3 NOTES ON THE USER MENU 1. Sub-menus A8 through A13 will not appear on older units unless you have the Time and Date option. 2. Detailed descriptions of the user menu parameters can be found in Chapter 5 of this manual. 3.3.4 EXITING THE USER MENU 1.

  • Page 18: Chapter 4: Setup Menu Descriptions And Procedures

    CHAPTER 4: SETUP MENU DESCRIPTIONS AND PROCEDURES SETUP MENU DESCRIPTIONS This section provides more detailed descriptions of the selections found in the Setup Menu Chart. Factory-set defaults are shown in bold with a checkmark (√). Table 4-1 shows the selections that are not allowed for “Legal-for-Trade” applications: NAME/CODE DESCRIPTION CODE/VALUE...
  • Page 19 NAME/CODE DESCRIPTION CODE/VALUE Determines the desired weight increments. Value should be consis- 1√ Display tent with legal requirements. Divisions Determines location of the decimal point. 0√ Decimal Pt. 0.00 0.000 0.0000 Actuates the function that allows you to enter a multiplier for the cus- Press ZERO key Custom Unit tom unit.

  • Page 20: Setup Menu Procedures

    SUB-MENU TITLE SELECTIONS Graduations 12,000 20,000 30,000 40,000 50,000 Zero Tracking Band (SAZSM) Zero Reset 100% (Canada Range Only) Motion Band Digital Filter Custom Unit Piece Count Table 4-1: Invalid Setup Menu selections for commercial applications SETUP MENU PROCEDURES This section provides instructions for all of the Setup Menu procedures with the exception of the Calibration procedures (F16 through F20) which can be found in Chapter 6.

  • Page 21: Setup Menu Key Assignments

    The display will momentarily show "SET", followed by a value with one flashing digit. This value will be the current multiplier value with the decimal point position pro- grammed above. Use the four directional keys (shown in Figure 4-1 below) to adjust the displayed value to the actual custom unit multiplier value.

  • Page 22: Chapter 5: User Menu Descriptions And Procedures

    CHAPTER 5: USER MENU DESCRIPTIONS AND PROCEDURES USER MENU DESCRIPTIONS This section provides more detailed descriptions of the selections found in the User Menu Chart. Factory-set defaults are shown in bold with a checkmark (√). NAME/CODE DESCRIPTION CODE/VALUE Selects the baud rate for data transmission through both serial ports 1200 2400 (COM1 and COM2).

  • Page 23: User Menu Procedures

    NAME/CODE DESCRIPTION CODE/VALUE Allows the date to be disabled in the Print Ticket mode. Valid only 0√ Date Enable when A3 is set to “1”. "0" = Disable the date printout "1" = Enable the date printout Selects the printed format for current date. Valid only when A3 is set 0√...

  • Page 24: Time Entry (A10)

    5.2.2 LF (Line Feeds) Number Entry (A6) While in the User Menu mode, scroll to "A 6", then scroll down once using the ZERO key to enter the Line Feeds menu. The display will momentarily show "LF", followed by the current line feeds value. Use the four directional keys (shown in Figure 5-1 above) to adjust the displayed value to the actual line feeds value.

  • Page 25: Date Entry (A13)

    5.2.4 Date Entry (A13) Your indicator will keep track of the current date for you, which can then be printed on the print ticket. Use this procedure to set the current date, which must be set in mm/dd/yy format. For example, for January 7, 1998, you would enter 010798. For November 30, 1998 you would enter 113098.

  • Page 26: Chapter 6: Calibration

    CHAPTER 6: CALIBRATION CALIBRATION OVERVIEW The indicator is calibrated by following the procedures embedded in F16 (Zero) and F17 (Span) of the Setup Menu. Each procedure enters a value into the indicator's non-volatile memory - F16 the zero value (deadweight) and F17 the span value (test weight). The minimum test weight that can be used is 1% of full-scale capacity.

  • Page 27: View Calibration Values (F18)

    4. After setting the exact value, press the NET/GROSS key to save the value. 5. If the calibration was successful, the display will show "EndC1" momentarily, then revert back up to F17. At this time it is suggested that the calibration values be recorded for future use (see Section 6.4).

  • Page 28: Key-In Span Calibration Value (F20)

    KEY-IN SPAN CALIBRATION VALUE (F20) Note: This procedure is intended for emergency use only in the case of non-volatile memory loss. A valid span calibration value, obtained from a successful F17 calibration procedure, must be used. 1. While in the Setup mode, scroll to "F 20", then scroll down once using the ZERO key. 2.

  • Page 29: Chapter 7: Operation

    Indicates the unit of the displayed weight. No unit means that the indicator is lb, kg, pcs displaying weight in the custom unit. STABLE This light is on whenever the scale is stable. TABLE 7-1: TI-1500 Series Annunciator Definitions Page 7-1...

  • Page 30: Keyboard

    7 .2 KEYBOARD The keyboard is composed of five function keys. Refer to Figure 7-2 for the overall layout and key locations. ZERO TARE PRINT UNITS GROSS FIGURE 7-2: Function Keys Layout 7.2.1 FUNCTION KEYS Units – This key toggles the indicator among the available weight units if enabled in the Setup (“F”) menu.

  • Page 31: Piece Counting

    3. Place the empty container on the scale’s platter and allow the weight indication to stabi- lize. 4. Press the TARE key. The display shows zero weight and turns the NET annunciator on. 5. Place the material to be weighed in the container and allow the weight indication to stabi- lize.

  • Page 32: Chapter 8: Legal For Trade Sealing

    CHAPTER 8: LEGAL FOR TRADE SEALING ABS ENCLOSURE The TI-1500 indicator in the ABS enclosure can be sealed for commercial (Legal for Trade) pplications as follows. 1. Power off the indicator by unplugging the power source. 2. On the back of the indicator, locate the Setup/Calibration Slide Switch Cover Plate (see illustration below).

  • Page 33: Appendix A: Specifications

    APPENDIX A: SPECIFICATIONS ANALOG SPECIFICATIONS Full Scale Input Signal 30mV, including dead load 0.4 μV / grad Minimum Sensitivity - Non H-44 1.0 μV / grad Minimum Sensitivity - H-44 Input Impedance 30MΩ, typical Internal Resolution Approximately 260,000 counts Display Resolution 50,000 display divisions max Measurement Rate 10 Meas/sec, nominal...

  • Page 34: Appendix B: Serial Port Information

    APPENDIX B: SERIAL PORT INFORMATION COM1 MODES B.1.1 FULL DUPLEX MODE The Full Duplex Mode for COM1 provides a Demand serial transmission mode. The Demand mode allows control from a host device, usually a PC, and can be activated by pressing the PRINT key on the indicator’s front panel.

  • Page 35: Recognized Host Commands

    B.1.1.1 RECOGNIZED HOST COMMANDS “P” - This command is sent to the indicator to print the indicated display. The indicator will not respond if the scale is in motion, positive overload or negative overload. “Z” - This command is sent to the indicator to zero the scale. The indicator will not respond if the scale is in motion, positive overload or negative overload.

  • Page 36: Com2 Mode

    INDICATOR PRINTER DATE 06/05/98 TIME 12:34 PM CTS 2 3 RXD 123456 TXD 3 20 DTR GROSS 25.00 lb S. GND 5 7 S. GND TARE 1.48 lb 23.52 lb 1234 0.019060 lb DSUB9 DSUB25 FIGURE B-3. Print Ticket FIGURE B-4. Cable Diagram for Indicator to Printer COM2 MODE B.2.1 SIMPLEX MODE The Simplex Mode provides a Continuous serial transmission mode.

  • Page 37: Appendix C: Determining Proper Span Gain (F2)

    APPENDIX C: DETERMINING PROPER SPAN GAIN (F2) SPAN GAIN OVERVIEW The Span Gain parameter found in F2 of the Setup Menu is directly related to the ADC (Analog to Digital Converter) integration time. This means that the lower the setting, the higher the number of measurements per second.
  • Page 38 # of External Full Scale Input Range (mV/V) Grads 1,000 1,500 2,000 2,500 3,000 4,000 5,000 – 6,000 – 8,000 – 10,000 – – 12,000 – – 15,000 – – – 20,000 – – – – 30,000 – – – –...

  • Page 39: Appendix D: Displayed Error Codes

    APPENDIX D: DISPLAYED ERROR CODES CODE MODE MEANING / POSSIBLE SOLUTION Normal Operating Gross Overload. A weight greater than the rated capacity has been Mode applied to the scale. Remove the weight from the platter or try re- calibrating the scale. Otherwise, check for a bad load cell connection or possible load cell damage due to overloading.
