KROHNE WATERFLUX 3000 Series Quick Start

Quick Start
WATERFLUX 3000
Electromagnetic flow sensor
Installation, assembly, start-up and maintenance may only be performed by appropriately trained personnel.
This instrument complies with requirements of Low Voltage Directive. Instruments must not be connected to power
supply before reading instructions described in the manual.
The responsibility as to the suitability, intended use and corrosion resistance of the used materials against the
measured fluid of this device rests solely with the operator.
This device cannot be used in Hazardous Locations or Explosive Gas Atmospheres!
To prevent damage to the Rilsan® coating, the WATERFLUX 3000 flow sensor must be installed carefully.
Take precautions during transport and installation to protect the in- and outlet of the flow sensor.
General
Check the device nameplate to
ensure that the device is delivered
according to your order.
Device version(s)
Compact version Remote version
QS- WATERFLUX 3000 - 04/2024 - 4009957401 -R09 en
Device nameplate (example)
Check for damage
Transport
- No special requirements
- Use the original packing of the device(s) when transporting
to the installation location.
For initial set up, we strongly recommend that you also refer to the relevant manual!
1 Installation
General installation requirements
Avoid vibration / Electromagnetic fields
3D Inlet length:
≥ 0 × ∅
≥ 0 × ∅
2D
Inlet length: Depends on 2D/3D bends
upstream
≥ 0 × ∅ ≥ 0 × ∅
≥ 0 × ∅
Check the manual for more details on installation options.
Use sunshade
Lmax - Lmin < 0.5 mm / 0.02"
Lmax
Lmin
