1 Technical Specifications for Vented / Condenser Dryer
2 Terra Electronic Clothes Dryer Project
3 Terra Condenser Dryer Working Principle
4 Terra Vented Dryer Working Principle
5 Dryer Programme Tables
5.1
Terra (Base) Timed Vented Dryer
5.2
Terra Vented dryer
5.3
Terra (Base) Timed Condenser Dryer
5.4
Terra Condenser Dryer with Senso
6 Door reversebility
1. Technical Specifications for Vented / Condenser Dryer:
1.1.
Product Definitions :
1.1.1. Producer
1.1.2 Model
Dryers Type CONTROL
Air Vented
Sensor
Base / Timed 866A0
Terra Condenser & Air Vented Dryers
Technical Specifications
Contents
: Arçelik A.Ş.
Tuzla - İstanbul / TÜRKİYE
:Terra Air Vented VDE Codes :
VDE
Codes Customer
876A1
BEKO DEUTSCHLAND
BEKO FRANCE
BEKO PLC
CIS-E.EUROPE-SPAIN
FAGOR BRANDT
ISRAEL
WEST EUROPE /
DENMARK
W. EUROPE / BELGIUM
BEKO SPAIN
MEA
W. EUROPE
ARÇELİK PAZARLAMA
WEST EUROPE
BEKO DEUTSCHLAND
BEKO DEUTSCHLAND -
EBREGENZ
BEKO FRANCE
CIS-E. EUROPE SPAIN
FAGOR BRANDT
ISRAEL
BEKO SPAIN
MEA
FAR EAST
CHINA
BEKO PAZARLAMA
Type 866A0
Type 876A1
Type 866C01
Type 876C11/876C 12 (TankUp)
Customer
Brand
Code :
BEKO
DV 1560
BEKO
DV 1560 X
BEKO
DRVS 62 W
BEKO
DRVS 62 S
FLAVEL
TDF 162 W
FLAVEL
TDF 162 S
BEKO
DV 1560
EDESA
SE 60 E
FAGOR
SFF 62
BEKO
DV 1560 X
BEKO
DV 1560
BEKO
DV 1560 X
SAIVOD
STE 6
ECRON
EV 1960
SINGER
SD 5500
FRIAC DE LUXE DK 6116E
ARÇELİK
1660 KT
BEKO
DV 1160
SMEG
AS61E
ALTUS
TA 1000
BEKO
DV 1160
BEKO
DV 1160
BEKO
DV 1160
EDESA
SE 60 T
FAGOR
SFE 60
BEKO
DV 1161 X
ANSONIC
SA 6
SINGER
SD 5400
EUROPA
ED 116
BEKO
DV 1160
BEKO
D 60KB
1
Advertisement
Table of Contents
Related Manuals for arcelik 866A0
Summary of Contents for arcelik 866A0
- Page 1 DV 1560 X BEKO SPAIN SAIVOD STE 6 ECRON EV 1960 SINGER SD 5500 W. EUROPE FRIAC DE LUXE DK 6116E Base / Timed 866A0 ARÇELİK PAZARLAMA ARÇELİK 1660 KT WEST EUROPE BEKO DV 1160 SMEG AS61E BEKO DEUTSCHLAND ALTUS...
- Page 2 Terra Condenser & Air Vented Dryers Technical Specifications :Terra Condenser VDE Codes Condenser Sensor 876C11 ARÇELİK PAZARLAMA ARÇELİK 2760 KT BEKO DEUTSCHLAND ALTUS TK 1201 BEKO PLC BEKO DRCS66W FLAVEL TDF 166 W FLAVEL TDF 166 S BEKO DRCS66S CARREFOUR BLUESKY BSLE 06 BEKO...
- Page 3 Terra Condenser & Air Vented Dryers Technical Specifications 1.2.4. Venting hose :Vented model 1.2.4.1. Diameter(mm) :100 1.2.4.2. Length (cm) :200 1.2.5. Draining hose : Condenser Model 1.2.5.1. Diameter Outer/Inner (mm) : 13 / 9 1.2.5.2. Length (cm) : 122 1.3. Packaging 1.3.1.1.
- Page 4 Terra Condenser & Air Vented Dryers Technical Specifications 1.4.2.1. With Packaging (kg) : 31 Vented 1.4.2.2. Without Packaging (kg) : 29 Vented 1.5. Ambient Conditions 1.5.1. Temperature: Min. : 5° C Max. : 35° C 1.5.2. Humidity : %95 RH 1.6.
- Page 5 Terra Condenser & Air Vented Dryers Technical Specifications 1.10. Heater 1.10.1. Type : Open flat wire 1.10.2. Nominal Power&Voltage ( W ) : at 230V 2000 ± %5 1.10.3. Resistance (ohm) : 1400 W 1.level (86,44 ohm± %5) : 600 W 2.level (37,04 ohm± %5) Safety Note: If the one thermostat or Heater NTC is defective, also please check the motor is running, fan is not broken and V-belt is Ok ,and filter is clean;...
- Page 6 Due to the safety regulations it is better to design all the product range with Electronic. 5 different types of dryer will be launched with this Terra Electronic Clothes Dryer project. Production Code VDE Code 1160 866A0 Terra Time based Air Vented Clothes Dryer 1560 876A1 Terra Air Vented Clothes Dryer with sensor...
- Page 7 Terra Condenser & Air Vented Dryers Technical Specifications This type of dryer permits to dry laundry without having humid air in the room. The Dryer machine is configured to operate at 230V AC. Voltage and current requirements are specified on the rating plate located upper side of the door opening. Condenser Condenser Motor...
-
Page 8: Technical Specifications / Energy Consumption
Terra Condenser & Air Vented Dryers Technical Specifications 3 Installation, Programme's and User Manual The proper location For drying the appliance requires a sufficient supply of clean, cool room air. Operate the appliance only in well ventilated, low dust rooms. Do not block or cover the appliance's vent slots. Do not operate appliance in locations where there is a danger of freezing. -
Page 9: Changing The Program
Terra Condenser & Air Vented Dryers Technical Specifications • Adjust feet until the appliance is level and does ended at any time. not rock. Checking with a spirit level is 1. Set the On/Of button off position. recommended. 2. Open door, remove laundry, check tumble for foreign objects. -
Page 10: Important Safety Information
Terra Condenser & Air Vented Dryers Technical Specifications The Programme times are described below: The Programme times for the Air Vented type Spun at 800-900 1000-1200 White/colored cottons Programme Load 6 kg 130’ 110’ Linen cupboard dry 3 kg 80’-110’ 60’- 80’... -
Page 11: Installation
Terra Condenser & Air Vented Dryers Technical Specifications • Cushion, quilts and similar stuffed items (These regulations in your country and those set by your items accumulate heat) local • Items containing the rubber foam or materials Electricity Board. similar to rubber foam. •The power cable plug must be accessible after •... - Page 12 Terra Condenser & Air Vented Dryers Technical Specifications unstable, loosen the plastic screw or unscrew the adjustable foot until the machine is leveled perfectly. Air Vented Models Only: Your machine comes with single (100 mm diameter and 2 meter long flexible air ventilation hose. Connect the flexible air ventilation hose, using the given adaptors.
-
Page 13: Standard Programme's
Terra Condenser & Air Vented Dryers Technical Specifications Condenser Models Only: Condensed water container When drying, water is separated from airstreams of the moist laundry (“condensate”). This water is collected in the condensed water container. The condensed water container needs emptying –... -
Page 14: Optional Functions
Terra Condenser & Air Vented Dryers Technical Specifications Buzzer Cancel(Only sensor models) Remained Terra Base / Timed Condenser moisture % At programme end and Initial throughout the anti-crease Dryness moisture stage (see above) a buzzer Level Load Duration min. max. amount % sounds. -
Page 15: Before Calling Service / Trouble Shooting
Terra Condenser & Air Vented Dryers Technical Specifications Single Sheet 350 g 1 lb 2 oz The right amount Double Sheet 500 g 12 oz • The maximum load capacity depends on the textile type and the corresponding drying programme. When operating tumble dryer the room Please note the information given in the “Programme temperature must be between +5 C and +35 C. - Page 16 Terra Condenser & Air Vented Dryers Technical Specifications Mechanical Parts (Dynamic System): The main motor is attached to the chassis with four special self threaded screws. In Order to drive drum a poly-v belt is used between the motor pulley and drum. There was used a elastic belt .
- Page 17 Terra Condenser & Air Vented Dryers Technical Specifications Door Micro switch : The main power is connected over the door switch to the motor and main board. When the door is open, the contacts of the motor are open, so the motor is stopped. or when the door is closed, but the dryer will not operate, according to the EN&IEC safety rules you have to press the Start button.
- Page 18 Terra Condenser & Air Vented Dryers Technical Specifications Main motor: The main motor is two pole Asynchronous motor which runs approx. 2750 rpm. and is equipped by run 8 mF capacitor. motor. It is controlled by a electronic card. Also the motor reverse directions are adjusted by the relay.
- Page 19 Terra Condenser & Air Vented Dryers Technical Specifications Dryer Programme Tables: 866A0 5.1 Terra Vented / Timed Base Dryers Programme Steps: Total Duration Programme Steps Steps No: Motor Profiles Heater Duration (sn) (sn) User selection Heating 1 3600 User selection...
- Page 20 Terra Condenser & Air Vented Dryers Technical Specifications 5.2 Terra VENTED (876A1) dryer with Sensor Program Steps : Drum Total Humidity Motor Heater Tempera Programmes Steps Time Limits Durations Control Profile Levels ture (minutes) limits Duration Step Duration Cotton Extra Dry Code (min) 0.
- Page 21 Terra Condenser & Air Vented Dryers Technical Specifications NO HEATING 1400 W HEATING 2000 W HEATING *Empty Drum logic , after max 2 minutes Dryer skip the steps and goes to the Airing phase. *Low heat-high heat button and buzzer cancel are optional. (depend on the models) . *Anti-Creasing mode duration is 2 hour’s.
- Page 22 Terra Condenser & Air Vented Dryers Technical Specifications User Selection Heating 2 Airing Anti-Crease 7200 Heating 1 Heating 2 Airing Airing Anti-Crease 7200 IS0 : Heater Off "User Selection" is set by Heater High/Low Auxiliary Button 5.4 Terra Condenser Sensor Dryer 876C11/876C 12 (TankUp) Heating Profile : IS0NO HEATER ISL1400 W HEATER...
- Page 23 Terra Condenser & Air Vented Dryers Technical Specifications Time programmes 40' / prog 7 0. Step Heating1 fazı Nem_m3 1. Step Heating2 fazı Nem_m3 2. Step Airing phase 3. Step Anti-Creasing phase Time programmes 20'/ prog 8 0. Step Heating1 fazı Nem_m3 1.
